- Page 1 VZ Series LCD Monitor User Manual...
-
Page 2: Copyright
Copyright Copyright © 2014 by BenQ Corporation. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of BenQ Corporation. -
Page 3: Benq Ecofacts
BenQ ecoFACTS BenQ has been dedicated to the design and development of greener product as part of its aspiration to realize the ideal of the “Bringing Enjoyment ‘N Quality to Life” corporate vision with the ultimate goal to achieve a low-carbon society. Besides meeting international regulatory requirement and... -
Page 4: Table Of Contents
Basic OSD menu operation ......................11 Power LED indicator ........................11 Menu introduction ....................12 Getting the most from your BenQ monitor ..........14 How to install the monitor on a new computer ..............15 How to upgrade the monitor on an existing computer............16 How to install on Windows 8 (8.1) system ................ -
Page 5: Box Contents
Box contents When unpacking please check you have the following items. If any are missing or damaged, please contact the place of purchase for a replacement. LCD Monitor Monitor Base CD-ROM Power Cable D-Sub Cable DVI Cable HDMI Cable • *: Optional accessory. •... -
Page 6: Installation
Installation • If the computer is turned on you must turn it off before continuing. Do not plug-in or turn-on the power to the monitor until instructed to do so. • The following illustrations are for your reference only. Available input and output jacks may vary depending on the purchased model. -
Page 7: Cleaning
Cleaning Please disconnect the power cord before cleaning the product. Clean the cabinet regularly with a cloth. You can use soft-detergent to wipe out the stain, instead of strong-detergent which will cauterize the product cabinet. When cleaning, make sure no detergent is leaked into the product. The cleaning cloth should not be too rough as it will scratch the screen surface. -
Page 8: Connecting The Monitor
Connecting the monitor VZ2250/VZ2350 VZ2350HM 2 3 4 5 Description AC power input jack HDMI socket DVI-D socket D-Sub socket Audio Line In 1. To protect equipment, always turn off the PC and LCD monitor before connecting. 2. Connect the plug of the D-Sub cable (at the end without the ferrite filter) to the monitor video socket. -
Page 9: Removing The Monitor Stand
Removing the monitor stand 1. Turn off the monitor and the power before unplugging the power cable. Turn off the computer before unplugging the monitor signal cable. 2. Protect the monitor and screen by clearing a flat open area on your desk and placing a soft item like a towel on the desk for padding, before laying the screen face down on a flat clean padded surface. -
Page 10: The Control Panel
The control panel VZ2250 / VZ2350 VZ2350HM Description Description Source / Auto / Exit Source / Auto / Exit ECO / - ECO / - 4:3 or wide / + Volume / + Menu / Enter Menu / Enter Power Power Source / Auto / Exit •... -
Page 11: Basic Osd Menu Operation
Basic OSD menu operation • Press the MENU button to activate the OSD menu. • Press - or + to navigate through the menu options. Once the desired option is highlighted, press the MENU key to confirm the selection. Press - or + to change the settings of the selected function. Press MENU key to save the new setting and exit the current function. -
Page 12: Menu Introduction
Menu introduction Available menu options may vary depending on the input sources, functions and settings. Menu options that are not available will become grayed out. And keys that are not available will be disabled and the corresponding OSD icons will disappear. Main menu Function Range... - Page 13 Main menu Function Range Color Warm Applies a warm tint to the image and is factory Temp. pre-set to the news print standard white color. Normal Allows video and still photographs to be viewed with natural coloring. Cool Applies a cool tint to the image and is factory pre-set to the PC industry standard white color.
-
Page 14: Getting The Most From Your Benq Monitor
Getting the most from your BenQ monitor To gain the most benefit from your new BenQ LCD monitor, you should install the custom BenQ LCD Monitor driver software as provided on the BenQ LCD Monitor CD-ROM. The circumstances under which you connect and install your BenQ LCD Monitor will determine which process you need to follow to successfully install the BenQ LCD Monitor driver software. -
Page 15: How To Install The Monitor On A New Computer
This instruction is only suitable for a computer which has never been used before, and for which the BenQ LCD Monitor is the first ever monitor to be connected to it. -
Page 16: How To Upgrade The Monitor On An Existing Computer
The BenQ LCD Monitor driver for your model may well function perfectly with other versions of Windows, however, as at the time of writing, BenQ has done no testing of this driver on other versions of Windows and cannot guarantee its operation on those systems. -
Page 17: How To Install On Windows 8 (8.1) System
4. Click Generic PnP Monitor, and then the Properties button. 5. Click the Driver tab and the Update Driver button. 6. Insert the BenQ LCD Monitor CD-ROM into a CD drive on the computer. 7. In the Update Driver Software window, select the option Browse my computer for driver software. -
Page 18: How To Install On Windows 7 System
4. Click Generic PnP Monitor, and then the Properties button. 5. Click the Driver tab and the Update Driver button. 6. Insert the BenQ LCD Monitor CD-ROM into a CD drive on the computer. 7. In the Update Driver Software window, select the option Browse my computer for driver software. -
Page 19: Troubleshooting
Troubleshooting The power LED indicator is not on. • Make the power cord is properly connected to a grounded power outlet and the monitor. • Make sure you have pressed the key. The image is blurred. • Read the instructions in "Preset display modes"... -
Page 20: Need More Help
• Check whether Line In is properly connected. • Increase the volume (volume may be muted or too low). Need more help? If your problems remain after checking this manual, please contact your place of purchase or e-mail us at: Support@BenQ.com. -
Page 21: Specification
Specification VZ2250 Model name VZ2250 Driving system TFT Color LCD Viewable Image Size 54.62cm diagonal Pixel pitch 0.08265*RGB (H) mm x 0.24795 (V) mm Panel Video R, G, B Analog lnterface Separate Sync. H/V TTL Display Color 16.7M Colors Dot Clock 165MHz Horizontal scan range 30 ~ 83kHz... -
Page 22: Vz2350
VZ2350 Model name VZ2350 Driving system TFT Color LCD Viewable Image Size 58.42cm diagonal Pixel pitch 0.0884*RGB (H) mm x 0.2652 (V) mm Panel Video R, G, B Analog lnterface Separate Sync. H/V TTL Display Color 16.7M Colors Dot Clock 165MHz Horizontal scan range 30 ~ 83kHz... -
Page 23: Vz2350Hm
VZ2350HM Model name VZ2350HM Driving system TFT Color LCD Viewable Image Size 58.42cm diagonal Pixel pitch 0.0884*RGB (H) mm x 0.2652 (V) mm Panel Video R, G, B Analog lnterface Separate Sync. H/V TTL Display Color 16.7M Colors Dot Clock 165MHz Horizontal scan range 30 ~ 83kHz... -
Page 24: Preset Display Modes
Preset display modes Mode Resolution H.Frequency V.Frequency 640×480@60Hz 31.469 59.940 640×480@72Hz 37.861 72.809 640×480@75Hz 37.500 75.00 800×600@56Hz 35.156 56.250 800×600@60Hz 37.879 60.317 SVGA 800×600@72Hz 48.077 72.188 800×600@75Hz 46.875 75.000 1024×768@60Hz 48.363 60.004 1024×768@70Hz 56.476 70.069 1024×768@75Hz 60.023 75.029 1280×1024@60Hz 63.981 60.020 SXGA 1280×1024@75Hz...
