Installation
Instructions
BEFORE YOU BEGIN
STOP
Read these instructions completely
and carefully.
WARNING:
Before you begin disconnect power to the
refrigerator.
Turn off the water supply.
Do not operate the refrigerator until the
installation is complete.
TOOLS REQUIRED:
• #2 Phillips Screwdriver
KIT CONTAINS:
• 1 All-Freezer fill tube
• 1 SxS Non-Dispenser fill tube
• 1 wrap-type fill tube heater
• 1 grommet
• 1 connector adapter
• Installation Instructions
Monogram Refrigerators
FILL TUBE FREEZING KIT
WR49X10094
Built-in Side-by-Side Non-Dispenser Energy Models:
ZIS360N, ZISS360N, ZIS420N, ZISS420N,
ZIS480N, ZISS480N
All-Freezer Models: ZIFS36NLH, ZIFS36NRH,
ZIF36NMRH, ZIF36NMLH
This kit provides parts and Installation
Instructions to repair fill tube freezing and
leaking between the grommet and fill tube for
SxS non-dispenser and All-Freezer energy
models only. See Service Bulletin REF 04-04
for more information.
1 DETERMINE WHICH REPAIRS
ARE NEEDED
Note: Access to the back of the unit is required
to replace the grommet. GE recommends two
technicians move the refrigerator in order to
replace the fill tube grommet.
• The grommet must be replaced if one or both
of the following conditions exist:
– Water is leaking between the grommet and
fill tube
– The grommet does not seal tightly around
the tube.
• Replace fill tube when needed.
2 KIT INSTALLATION
INSTRUCTIONS
• Disassemble freezer components in order to
access the fill tube components.
• Use fill tube, heater and connector adapter
as needed.
• If the grommet must be replaced, replace
it at this point. Access to the back of the unit
is required to replace the grommet.
• Assemble fill tube with heater and grounding
plate into grommet. Make sure the tube is
pushed completely into the grommet.
• Finish assembling other components.
• Cycle icemaker and discard water to remove
grommet material particles that may have
scraped off during assembly
3
