Summary of Contents for IDS 1632
-
Page 2: Table Of Contents
Edit a Selected User Code - Option 2----------------------------------------------------17 14.4 View a User Code Slot Number - Option 3----------------------------------------------17 14.5 User Code Properties - Option 4----------------------------------------------------------17 14.5.1 Explanation of User Code Properties-----------------------------------------------------18 14.5.1.1 Master Code (Only Adjustable by the Installer)-----------------------------------------18 IDS 1632 User Manual 700-256-01I Issued March 2009... - Page 3 Viewing Trouble Conditions ------------------------------------------------------------ 23 Changing a Partition ---------------------------------------------------------------------- 24 Output Control via a Keypad ----------------------------------------------------------- 24 Remote Telephone Access ------------------------------------------------------------- 25 Controlling the IDS 1632 via Cellphone SMS ------------------------------------ 27 22.1 Checking the Airtime Balance--------------------------------------------------------------28 22.2 Recharging/Topping up Airtime------------------------------------------------------------28...
- Page 4 IDS 1632 User Manual 700-256-01I Issued March 2009...
- Page 5 IDS 1632 User Manual 700-256-01I Issued March 2009...
-
Page 6: Glossary
A partition is a group of zones which may be armed and disarmed independently without affecting zones or users assigned to other partitions. The IDS 1632 Alarm Panel may have been programmed by your installer to have up to 8 partitions. -
Page 7: Introduction To The Ids 1632
Introduction to the IDS 1632 The IDS 1632 is a versatile, microprocessor-based sixteen-zone Alarm Panel. There are eight partitions and the panel can be expanded to monitor thirty two burglary zones. Most features are optional and may be programmed directly through the keypad. -
Page 8: Understanding The Keypad Indicators
User Programming (Chime/Buzz/Stay zones) POWER Indicator (Red) Mains Power is Present Flashing Trouble Condition READY Indicator (Green) System is Ready to be Armed ZONE Indicators (Yellow) Zone Bypassed Zone Clear Flashing Zone Violated or Tampered IDS 1632 User Manual 700-256-01I Issued March 2009... -
Page 9: The Keypad Buzzer
Forced Arm Push to Arm Siren sound on Arm/Disarm (single toot – arm / double toot – disarm) Panic Alarm Fire Alarm Medical Alarm Chime zones IDS 1632 User Manual 700-256-01I Issued March 2009... -
Page 10: Arming The Control Panel
PROFILE 2 is used while watching television when all interior zones would be bypassed. (See How to Select a Stay Profile, under Stay zones) IDS 1632 User Manual 700-256-01I Issued March 2009... -
Page 11: How To Stay Arm
At the end of the exit delay the ARMED indicator will come on and the AWAY indicator will remain off. All stay zones will be bypassed. NOTE: Holding down the [6] key until the keypad buzzer sounds also ensures an Entry delay on entering the premises. IDS 1632 User Manual 700-256-01I Issued March 2009... -
Page 12: Key-Switch Or Remote Arming (If Fitted)
Ensure that the READY indicator is lit before leaving. Leave and close the door (remembering to lock!) Activate the remote or the key-switch. The panel will arm in the away mode. (An IDS remote receiver with matching TX unit can be used to Stay Arm or Away Arm.) NOTE: If a remote control is used it is advisable to have the siren toot on arm function enabled. -
Page 13: Bypassing Zones
If the [P] key is pressed until the keypad beeps (approximately 1 second) a PANIC ALARM condition will be activated. A PANIC ALARM may also be activated using any FIXED PANIC button or a REMOTE PANIC button (if installed). IDS 1632 User Manual 700-256-01I Issued March 2009... -
Page 14: Medical Alarms
Press 1 to return to violated zones. Note that the alarm memory is erased at the beginning of each arm cycle – so it should always be checked BEFORE re-arming, if necessary. IDS 1632 User Manual 700-256-01I Issued March 2009... -
Page 15: User Codes
User Codes The IDS 1632 Alarm Panel has 250 programmable user codes. By default user code 1 is the Master USER CODE which contains a pre-programmed 4 digit code of 1234. NOTE: User codes may be 4 (default) or 6 digits long (with default code of 123456). This is a programmable feature Check with your installer to verify which option has been programmed. -
Page 16: Explanation Of Programmable Options
User Names are displayed as the User Slot Number by default. Edit the User Number so that it reads the correct User Name. To confirm the entry press [*]. Repeat steps 3 to 4 until you have edited all the names you require and then press [#] to exit. IDS 1632 User Manual 700-256-01I Issued March 2009... -
Page 17: Edit A Selected User Code - Option 2
To select a user code property, press the key which corresponds to that property followed by the [*] key. The appropriate zone LED will come on. To deselect a property, press the corresponding key followed by the [*] key and the LED will be off. IDS 1632 User Manual 700-256-01I Issued March 2009... -
Page 18: Explanation Of User Code Properties
MAID‟S CODE as an invalid entry. Any valid user code will disarm the system if it has been armed with the MAID‟S CODE. IDS 1632 User Manual 700-256-01I Issued March 2009... -
Page 19: Group Arm Code
14.5.1.10 Report User Access Codes with this property enabled will cause the Alarm Panel to send a User Access Report Code to the Security Company every time these users enter their code. IDS 1632 User Manual 700-256-01I Issued March 2009... -
Page 20: Assign User Code To Partitions - Option 5
BOTH partitions 1 and 2. It is possible to program codes to arm/disarm a selection from any of the eight possible partitions in the IDS 1632. To select which partitions the USER CODE may arm or disarm, toggle zone LED‟s by entering the [ZONE LED NUMBER] followed by the [*] key. -
Page 21: Delete A User Code - Option 10 ("Slot" Known)
[2] [*] [PROFILE NUMBER] [*] Ensure that the Panel is disarmed. Press the [#] key to clear any previous entries. Hold [MODE] down for one second until the keypad beeps. IDS 1632 User Manual 700-256-01I Issued March 2009... -
Page 22: How To Program Stay Zones
Select the required stay profile (See Page 21) Hold down the [4] key until the keypad buzzer sounds. The AWAY indicator will flash indicating that the panel is in the Buzz zone programming mode. IDS 1632 User Manual 700-256-01I Issued March 2009... -
Page 23: Chime Zones
MODE after one minute. (Alternately to exit this mode press [#]). NOTE: Certain trouble conditions will only clear once the trouble condition has restored. To cancel the beeping without viewing the trouble conditions, press [#] key. IDS 1632 User Manual 700-256-01I Issued March 2009... -
Page 24: Changing A Partition
To toggle the output status, enter [OUTPUT NUMBER] followed by [*]. Press [#] to exit User Program Mode. Ensure that you have checked with your installer which outputs are used for radio reporting so as to prevent the triggering of false alarms. IDS 1632 User Manual 700-256-01I Issued March 2009... -
Page 25: Remote Telephone Access
Please note that this section only applies if programmed by your installer. The IDS 1632 Alarm Panel has a secure, remote telephone interface that allows a user to arm/disarm, to bypass/un-bypass zones and to set programmable outputs via a phone line. A user accesses the remote dial-in interface by dialling the Alarm Panel using a DTMF phone. -
Page 26: Table 4 Remote Telephone Operation
Will turn an output off Reports output status [9] [Output Number] [*] One beep = output on Two beeps = output off [0] [Door Number] [*] Opens the specified Door [#] [*] Ends the call IDS 1632 User Manual 700-256-01I Issued March 2009... -
Page 27: Controlling The Ids 1632 Via Cellphone Sms
This functionality is only available when an IDS GPRS module is installed with the IDS 1632 Alarm Panel. You can control your 1632 Alarm Panel on your premises from any part of the world with coverage that supports your cellphone. Each command you send must include the word “code” (without the quotes), followed by the user code and then the required instruction. -
Page 28: Checking The Airtime Balance
22.1 Checking the Airtime Balance Only applicable for users who have a pay as you go arrangement with an IDS GSM module fitted to their Alarm Panel. Hold down the [MODE] key until the beep, then press [7] … then wait a few seconds…... -
Page 29: Index
Exit Delay ............................6, 10, 11, 22 Fire..............................6, 7, 9, 13 Follower Zone...........................see "Zone" Forced Arming ..............................9 Instant Zone............................see "Zone" Key-switch ..............................10, 12 Maid‟s Code..............................18 Master User Code ..............................15 Medical ...............................6, 9, 14 IDS 1632 User Manual 700-256-01I Issued March 2009... - Page 30 User Codes..............6, 7, 10, 11, 12, 13, 14, 15, 16, 17, 18, 20, 21, 22, 25, 27 Zones Entry/Exit........................6, 10, 11, 12, 21, 22 Follower ..............................6, 9 Instant ................................6 Stay ........................6, 7, 8, 10, 11, 21, 22, 23 IDS 1632 User Manual 700-256-01I Issued March 2009...
- Page 31 8 = Box tamper 10 = Tamper on peripheral 11 = Comms failure to peripheral device 12 = Loss of power to peripheral device 14 = SIM PIN error 15 = Low Airtime IDS 1632 User Manual 700-256-01I Issued March 2009...
- Page 32 IDS 1632 User Manual 700-256-01I Issued March 2009...
