Control 42C:
Frequency Range (-10 dB)
Frequency Response (± 3 dB)
Power Capacity
Nominal Sensitivity (2.83V/1m)
Nominal Coverage Angle
Directivity Factor (Q)
Directivity Index (DI)
Rated Maximum SPL: 94 dB @ 1 m (3.3 ft) average, 100 dB peak
Rated Impedance: 16Ω
Input Connectors: Two removeable locking 2-pin connectors with screw-down terminals.
Safety Agency: Suitable for use in air handling spaces per UL1480, UL2043, CUL, NFPA90, NFPA70A, and in
Dimensions: Ø 127 mm (5.0 in)
Ceiling Thickness Range: Accommodates tiles / drywall up to 27 mm (1.06 inches)
Included Accessories:
Control 40CS/T:
Frequency Range (-10 dB)
Frequency Response (± 3 dB)
Power Capacity
Nominal Sensitivity (2.83V/1m)
Rated Maximum SPL: 109 dB @ 1 m (3.3 ft) average, 115 dB peak (center of ceiling)
Rated Impedance: 7 Ω (in bypass mode)
Transformer Taps: 80W 40W, 20W, (& 10W @ 70V)
Input Connectors: Six removeable locking 2-pin connectors with screw-down terminals.
Safety Agency: Suitable for use in air handling spaces per UL1480, UL2043, CUL, NFPA90, NFPA70A, and in
Dimensions: Ø 346 mm (13.6 in)
Ceiling Thickness Range: Accommodates tiles / drywall up
Included Accessories:
Optional Control 40 Series Accessories:
In half space (in ceiling)
1
IEC standard, full bandwidth pink noise with 6 dB crest factor
2
3 Average 1 kHz to 16 kHz
JBL continually engages in research related to product improvement. Changes introduced into existing products without notice are an expression of that philosophy.
440921-005
05/14
1
: 140 Hz - 20 kHz
1
: 180 Hz - 17 kHz
2
: 30 Watts Continuous Program Power
15 Watts Continuous Pink Noise
1
: 82 dB
3
: 160° conical coverage
3
: 6.6
3
: 6.8dB
Driver: 60mm (2.5 in) mid-high
Max wire 12 AWG (2.5 mm). Key: 1) + in, 2) - in, A) + loop thru, B) - loop thru
Knockouts: Two (top and side)
accordance with the requirements of IEC60849/EN60849
Cutout Size: 104 mm (4.1 in)
Net Weight: 0.7 kg (1.6 lbs)
Press-in grille, C-ring support backing plate, knockout strain relief, cutout template, paint shield
1
: 30 Hz - 300 Hz
1
: 50 Hz - 180 Hz
2
: 200 Watts Continuous Program Power
100 Watts Continuous Pink Noise
1
: 95 dB (near corner), 89 dB (center of ceiling)
Driver: 200mm (8 in) with polypropylene cone, butyl rubber surround,
copper-clad coil, vented aluminum former.
Max wire 12 AWG (2.5 mm). Key: 1) + in, 2) - in, A) + loop thru, B) - loop thru
Satellite Key: Sat 1 - Satellite 1, Sat 2 - Satellite 2, Sat 3 - Satellite 3, Sat 4 - Satellite 4,
Knockouts: Two (top and side)
accordance with the requirements of IEC60849/EN60849
Cutout Size: 307 mm (12.1 in)
Net Weight: 8.1 kg (17.9 lbs)
Press-in grille, C-ring support backing plate, 2 tile support rails, knockout strain relief,
cutout template, paint shield
MTC-RAIL Tile Rails, for use with Control 42C
MTC-42NC New Construction Bracket, for use with Control 42C
MTC-42MR Mud Ring Construction Bracket, for use with Control 42C
MTC-26NC New Construction Bracket, for use with Control 45C/T
MTC-26MR Mud Ring Construction Bracket, for use with Control 45C/T
MTC-47NC New Construction Bracket, for use with Control 47C/T & Control 47LP
MTC-47MR Mud Ring Construction Bracket, for use with Control 47C/T & Control 47LP
MTC-19NC New Construction Bracket, for use with Control 47HC & Control 40CS/T
MTC-19MR Mud Ring Construction Bracket, for use with Control 47HC & Control 40CS/T
Northridge, CA 91329 USA
Visit us online at www.jblpro.com
SPECIFICATIONS
diameter x 97 mm (3.8 in) mounting depth
diameter x 346 mm (13.6 in) mounting depth
to 70 mm (2.75 inches) thick
8500 Balboa Boulevard
thick
