4305P Powered Studio Monitor
Owner's Manual
Thank you for choosing JBL
For more than 75 years, JBL has been providing audio equipment for concert halls, recording studios, and movie theaters around
the world and has become the trusted choice of leading recording artists and sound engineers. The 4305P system is a new compact
powered bookshelf/monitor joining the JBL Studio Monitor family designed for home use. To get the best performance from you new
system, please read these instructions thoroughly.
1. Verify Box Contents
• 1 x Primary 4305P Speaker
• 1 x Secondary 4305P Speaker
• 1 x Safety Sheet
• 1 x Remote Control
• 4 x AC Power cords (quantity and type of plugs vary by regions)
• 1 x 10 feet CAT5e Shielded Cable
• 8 x Rubber bump-on feet
2. Front Panel Overview
Source LED Indicators & Source Icons
A
(Left to Right: Streaming, Bluetooth, USB Audio, Toslink/
Optical, Balanced, Analog)
B
Power Indicator
Volume Control / Mute
C
(Rotary encoder + Push Switch)
F
Power and Status LED
4305P OM | Part No: 950-0597-001 | Rev 1.0
© 2022 HARMAN International Industries, Incorporated. All rights reserved.
Primary Speaker
A
VOL/MUTE
B
C
Source Select + Bluetooth Pairing
D
(Rotary Encoder + Push Switch)
E
NET Status LED
Secondary Speaker
F
SRC/PAIR
D E
EN
www.jbl.com/specialtyaudio
Pg 1 of 11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4305P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for JBL 4305P

Summary of Contents for JBL 4305P

  • Page 1 For more than 75 years, JBL has been providing audio equipment for concert halls, recording studios, and movie theaters around the world and has become the trusted choice of leading recording artists and sound engineers. The 4305P system is a new compact powered bookshelf/monitor joining the JBL Studio Monitor family designed for home use.
  • Page 2 Toslink / Optical digital input Secondary Speaker Main Power switch USB-B Digital Direct PCM input Pg 2 of 11 4305P OM | Part No: 950-0597-001 | Rev 1.0 © 2022 HARMAN International Industries, Incorporated. All rights reserved.
  • Page 3 Yellow when tethered together. Wireless: Each pair of 4305P have been pre-paired for wireless connectivity at the factory. Maximum distance between speaker should be 30' (9m) or less. Maximum audio quality through wireless connection is 96kHz 24bit. Both speakers Power LEDs will illuminate solid White when connected wirelessly.

  • Page 4: Connecting To A Network

    Select the speaker called "4305P-XXXXXX (XXXXXX corresponds to a MAC address)". Select the network you want the 4305P to connect and press "Next". Follow the on-screen instructions to complete the 4305P setup as an AirPlay speaker system. Disabling & Enabling Network / Bluetooth Connectivity Network / Bluetooth functionality can be turned Off...

  • Page 5: Audio Source Connections

    Launch the streaming service app you wish to listen to on phone or tablet Press the Cast icon in that app (usually in upper right-hand corner of content app) Select the 4305P (Or name that you chose for the system) Start your streaming content...

  • Page 6: System Control

    • Press the Volume Control again will un-Mute, restoring volume to last setting. POWER VOLUME /MUTE SOURCE/PAIRING Pg 6 of 11 4305P OM | Part No: 950-0597-001 | Rev 1.0 © 2022 HARMAN International Industries, Incorporated. All rights reserved.
  • Page 7 An Audio signal is detected through the last source selected (except USB or Optical), this includes Streaming and Bluetooth Streaming as long as Network is On Remote Control Included with the 4305P system is a Bluetooth hand-held remote control allowing for easy control of the primary operations of the system from up to 40' (12m). •...

  • Page 8: Other Modes

    8. Other Modes Solid Protection Mode The 4305P system is provided with different levels of protection, in the rare event that the system Primary Speaker detects and internal malfunction, it will be represented by the selected Source icon to illuminate solid Red color.

  • Page 9: Specifications

    18.13" H x 23.5" W x 11.38" D (460.4mm x 596.9mm x 288.9mm) Dimensions: Gross Shipping Weight: 34.2 lbs (15.5 kg) AC Input Voltage: 100 - 240 VAC (+/-10%), 50/60Hz Pg 9 of 11 4305P OM | Part No: 950-0597-001 | Rev 1.0 © 2022 HARMAN International Industries, Incorporated. All rights reserved.

  • Page 10: Trademarks And Licenses

    ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Pg 10 of 11 4305P OM | Part No: 950-0597-001 | Rev 1.0 © 2022 HARMAN International Industries, Incorporated. All rights reserved.

  • Page 11: Wireless Specification

    This equipment complies with European Commission Regulation (EC) No1275/2008 and (EU) No 801/2013. • Networked standby (WIFI/BT/ETHERNET) : < 2.0 W Pg 11 of 11 4305P OM | Part No: 950-0597-001 | Rev 1.0 © 2022 HARMAN International Industries, Incorporated. All rights reserved.
  • Page 12 Manufacturer: Harman International Industries, Incorporated © 2022 HARMAN International Industries, Incorporated. All rights reserved. Address: 8500 Balboa Blvd, Northridge, CA 91329, UNITED STATES JBL is a trademark of HARMAN International Industries, Incorporated, registered in the United States and/or other countries. European Representative: Features, specifications and appearance are subject to change without notice.
