Control 47HC:
Frequency Range (-10 dB)
Frequency Response (± 3 dB)
Power Capacity
Nominal Sensitivity (2.83V/1m)
Nominal Coverage Angle
Directivity Factor (Q)
Directivity Index (DI)
Rated Maximum SPL: 112 dB @ 1 m (3.3 ft) average, 114 dB peak
Rated Impedance: 6.6Ω (in bypass mode)
Transformer Taps: 60W 30W, 15W, (& 7.5W @ 70V)
LF Driver: 165mm (6.5 in) with polypropylene cone, butyl rubber surround,
HF Driver: 25mm (1 in) soft dome w/ dampening, ferrofluid-cooled.
Input Connectors: Two removeable locking 2-pin connectors with screw-down terminals.
Knockouts: Two (top and side)
Safety Agency: Suitable for use in air handling spaces per UL1480, UL2043, CUL, NFPA90, NFPA70A, and in
Dimensions: Ø 346 mm (13.6 in)
Cutout Size: 307 mm (12.1 in)
Ceiling Thickness Range: Accommodates tiles / drywall up
Net Weight: 6.4 kg (14 lbs)
Included Accessories:
Control 45C/T:
1
Frequency Range (-10 dB)
1
Frequency Response (± 3 dB)
2
Power Capacity
1
Nominal Sensitivity (2.83V/1m)
3
Nominal Coverage Angle
3
Directivity Factor (Q)
3
Directivity Index (DI)
Rated Maximum SPL: 107 dB @ 1 m (3.3 ft) average, 113 dB peak
Rated Impedance: 8Ω (in bypass mode)
Transformer Taps: 60W 30W, 15W, (& 7.5W @ 70V)
Driver: 130mm
HF Driver: 20mm (0.75 in) soft dome w/ dampening, ferrofluid-cooled, aluminum former.
Input Connectors: Two removeable locking 2-pin connectors with screw-down terminals.
Knockouts: Two (top and side)
Safety Agency: Suitable for use in air handling spaces per UL1480, UL2043, CUL, NFPA90, NFPA70A, and in
Dimensions: Ø 250 mm (9.9 in) diameter x 239 mm (9.4 in) mounting depth
Cutout Size: 220 mm (8.8 in)
Ceiling Thickness Range: Accommodates tiles / drywall up
Net Weight: 3.9 kg (8.5lbs)
Included Accessories:
SPECIFICATIONS
1
: 55 Hz - 17 kHz
1
: 70 Hz - 14 kHz
2
: 150 Watts Continuous Program Power
75 Watts Continuous Pink Noise
1
: 93 dB
3
: 75° conical coverage
3
: 10.2
3
: 12.0dB
copper-clad coil, vented aluminum former.
Max wire 12 AWG (2.5 mm). Key: 1) + in, 2) - in, A) + loop thru, B) - loop thru
accordance with the requirements of IEC60849/EN60849
diameter x 353 mm (13.9 in) mounting depth
Press-in grille, C-ring support backing plate, 2 tile support rails, knockout strain relief,
cutout template, paint shield
: 55 Hz - 20 kHz
: 80 Hz - 17 kHz
: 150 Watts Continuous Program Power
75 Watts Continuous Pink Noise
: 88 dB
: 120° conical coverage
: 5.6
: 7.3 dB
(5.25 in) with polypropylene-coated paper cone, butyl rubber surround, 25 mm (1 in)
copper voice coil, vented fiberlgass resin former.
Max wire 12 AWG (2.5 mm). Key: 1) + in, 2) - in, A) + loop thru, B) - loop thru
accordance with the requirements of IEC60849/EN60849
Press-in grille, C-ring support backing plate, 2 tile support rails, knockout strain relief,
cutout template, paint shield
to 70 mm (2.75 inches) thick
to 70 mm (2.75 inches) thick
