HDMI
Dual Display
Gigabit Ethernet
Chipset
LAN LED
Disable LAN through BIOS
WOL
Boot from LAN
ASF
Audio
Codec
Chipset
Audio output header
Front IO Connector
SPDI/F
Amplifier
RS232 COM
LPC to COM
Super I/O
Chipset
Fan speed monitor & control
Temperature
Voltage
Buzzer
Onboard buzzer
WDT
Watchdog Timer
TPM
TPM
BIOS
BIOS Core
BIOS Flash
BIOS Flash
1 support HDMI 1.3a & 1080p up to 1920 x 1080
VGA+LVDS, VGA+HDMI, HDMI+LVDS
LAN1 RTL 8111DL Gigabit LAN
LAN2 RTL 8111DL Gigabit LAN
Left: Link (Off)/ Active (Flash Yellow)
Right: 1Gbps(Green) / 100Mbps (Orange) / 10Mbps (Off)
Yes
Yes
Yes
N/A
7.1 Channel HD Audio
Realtek ALC892
Yes, Front Audio Pin Header
Stack Phone Jack (Mic In, Line-out, Line-in)
Yes
TI TPA3005
2 COM for Rear I/O D-Sub
2 COM with headers
Winbond W83627DHG-P
FAN Speed Control by Thermal Sensor
Yes
3.3V, +5V, 5Vsb, +12V, -12V
Yes
Programmable 1~255 sec/min
Onboard TPM1.1/1.2 By Infineon SLB9635 (Optional)
AMI EFI
16Mb SPI
Data Modul AG - www.data-modul.com
User's Manual
EMX-A55E User‟s Manual 11
