Operating Instructions

Selecting the Compatibility Mode

The UT Handheld Transmitter can be used with Lectrosonics 400 Series Digi-
tal Hybrid, 200 Series analog, 100 Series analog and some non-Lectrosonics
analog wireless receivers. Contact the factory for details on the non-Lectro-
sonics models that can be used. The transmitter must be set to the operating
mode of the matching receiver, which is done using the supplied screwdriver
and a battery.
NOTE: The unit is supplied from the factory in Hybrid mode.
1) Ensure the battery is good.
2)
Turn off the transmitter.
3)
With a small screwdriver (included), set the Frequency Select Switches to
CC. (for Change, Change).
4) Power up the unit briefly – just long enough for the LED's to light up and
then turn it off - about one second.
5)
Change the Frequency Select Switches to one of the following settings:
• To set Lectrosonics 100 Series mode:
• To set Lectrosonics 200 Series mode:
• To set Mode 3*:
• To set Lectrosonics Hybrid mode:
• To set IFB mode:
* contact the factory for details
6)
Turn the unit on, wait about one second and turn it off again.
7)
Change the Frequency Select Switches to 0,0.
8)
Turn on the transmitter to complete the operation.
The LEDS will blink to indicate the selected compatibility mode. Immedi-
ately after powerup, all LEDS will blink together red, then green, followed
by the audio level LEDs (-20 and -10) blinking to indicate the mode.
The -20 and -10 LEDs will blink:
• Once for 100 Series mode
• Two times for 200 Series mode
• Three times for Mode 3
• Four times for 400 mode
• Five times for IFB mode
At powerup the transmitter will confirm the current compatibility mode
with the number of blinks listed here. This setting will remain the same
until you reset it with the procedure listed above.

1,1
2,2
3,3
4,4
5,5
