PVC, machined to a natural, comfortable shape. Internal mechanical parts are machined aluminum. Only the T195 and UT195 transmitters are covered in this manual. Companion receivers are covered in separate manuals. The T195 will operate with any 195 Series Lectrosonics receiver on the same frequency.
Hand-held Transmitter GENERAL TECHNICAL DESCRIPTION The T195 / UT195 transmitter is comprised of a number of functional sub-systems as shown in the block diagram below. The T195 and UT195 utilize 75kHz deviation for compatibility with the 195 series receivers. The transmitter circuits are all regulated to allow full output power from the beginning (9 Volts) to the end (7 Volts) of battery life.
The 195 system utilizes a separate ultrasonic tone modulation of the basic carrier to operate the receiver squelch. A 32kHz tone is injected into the audio signal after the microphone preamp, just after the compandor. The supersonic pilot tone is filtered out of the audio signal immediately after the detector in the receiver so that it does not influence the compandor or various gain stages.
Page 5
Hand-held Transmitter EXTERNAL SWITCHES BYPASS This concealed slide switch defeats the external switches on the bottom panel for applications where it is best that the user not be able to operate the power and mute switches. EXTERNAL LED OFF This slide switch defeats the battery status LED on the bottom panel for applications where Bypass Switches the LED may be distracting.
Page 6
BASS FILTER In addition to the tone controls, the UT200 also has a built in bass filter. This filter is fixed and cannot be adjusted or defeated. Low frequency noise is much more of a problem with wireless microphones than with conventional micro phones.
Hand-held Transmitter BATTERY INSTALLATION The transmitter is powered by a standard alkaline 9 Volt battery. It is important that you use ONLY an ALKALINE battery for reliable operation. Alkaline batteries will provide about 4 hours of operation and lithium batteries will power the unit for 12 hours.
OPERATING INSTRUCTIONS 1) Install a fresh battery according to the instructions on page 5. Leave the battery cover off for further adjustment. 2) Set the internal bypass slide switches so that the battery status LED and the bottom panel switches will operate. 3) On the bottom panel, move the “A”...
Hand-held Transmitter TROUBLESHOOTING Before going through the following chart, be sure that you have a good battery in the transmitter. It is important that you follow these steps in the sequence listed. SYMPTOM POSSIBLE CAUSE TRANSMITTER BATTERY LED OFF 1) External LED is turned off. Check internal slide switch. 2) Battery is inserted backwards.
SPECIFICATIONS Operating Frequencies: 470 to 608 MHz RF Power Output: 50mW on VHF Pilot Tone: 32.768 kHz, ±2 Hz, 5kHz deviation Frequency Stability: ±0.002% Deviation: ± 75 kHz max Spurious Radiation: At least 50dB below carrier Equivalent Input Noise: –126 dBv Input Level: Maximum SPL depends on mic element used Input Compressor:...
There are no adjustments inside that will make a malfunctioning unit start working. LECTROSONICS service department is equipped and staffed to quickly repair your equipment. In-warranty repairs are made at no charge in accordance with the terms of the warranty. Out of warranty repairs are charged at a modest flat rate plus parts and shipping.
This warranty does not apply to used or demonstrator equipment. Should any defect develop, Lectrosonics, Inc. will, at our option, repair or replace any defective parts without charge for either parts or labor. If Lectrosonics, Inc. cannot correct the defect in your equipment, it will be replaced at no charge with a similar new item.
