HIKVISION DS-8104 Quick Operation Manual

HIKVISION DS-8104 Quick Operation Manual

Ds-8100-st series
Hide thumbs Also See for DS-8104:
Table of Contents

Advertisement

Quick Links

See also: User Manual
DS-8100-ST Series DVR
Quick Operation Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-8104 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HIKVISION DS-8104

Summary of Contents for HIKVISION DS-8104

  • Page 1 DS-8100-ST Series DVR Quick Operation Guide...

  • Page 2: Verify Contents

    DS-8100-ST Series DVR Quick Operation Guide This manual is applicable to DS-8104/8108/8116HCI-ST (V1.1.0), DS-8104/8108AH (L) I-ST (V1.1.0) and DS-8104/8108AHF (L) I-ST (V3.2.0) series DVR. Verify Contents Verify that the package contents are correct by checking the items against the packing list.
  • Page 3 DS-8100-ST Series DVR Quick Operation Guide 3. Connect the HDD to the motherboard of the DVR with the included data cable. 4. Connect the power cable to the HDD. 5. Re-install the cover of the DVR and fasten screws. To install a HDD on DS-8100AH (F) (L) I-ST series DVR: 1.
  • Page 4 DS-8100-ST Series DVR Quick Operation Guide 3. Connect the HDD to the motherboard of the DVR with the included data cable. 4. Connect the power cable to the HDD. 5. Re-install the lid of the DVR and fasten screws.

  • Page 5: Front Panel

    DS-8100-ST Series DVR Quick Operation Guide Front Panel DS-8100HCI-ST Front Panel The controls on the front panel include: Power Button: Powers DVR on/off. IR Receiver: Receiver for IR remote. USB Ports: Universal Serial Bus (USB) ports for additional devices such as USB mouse and USB Hard Disk Drive (HDD).
  • Page 6 DS-8100-ST Series DVR Quick Operation Guide used to turn audio on/off in the Playback menu and auto scan in the PTZ Control menu. • ZOOM+ Button: The ZOOM+ button is used to zoom the PTZ camera in when in the PTZ Control menu.

  • Page 7: Ds-8100Ah(F) (L) I-St Front Panel

    DS-8100-ST Series DVR Quick Operation Guide DS-8100AH(F) (L) I-ST Front Panel The controls on the front panel include: LCD: Display local menu and preview. Note:   DS-8100AH (F) I-ST model is designed with no LCD. Status Indicators: Status indicators for different features of the DVR. •...
  • Page 8 DS-8100-ST Series DVR Quick Operation Guide character in front of the cursor. On checkbox fields, pressing the EDIT/IRIS+ button will tick the checkbox. In Playback mode, it can be used to generate video clips for backup. • 6MNO/PLAY: The 6MNO/PLAY button works as numeric [6] and letter [MNO]. It is used to enter the Playback menu.

  • Page 9: Rear Panel

    DS-8100-ST Series DVR Quick Operation Guide Rear Panel DS-8104HCI-ST Rear Panel Item Description VIDEO IN BNC connectors for analog video input. AUDIO IN BNC connectors for analog audio input. BNC connectors for main video out. If VGA is connected when the device is started up, this interface will be used as the Aux video output with live view and MAIN VIDEO OUT pop-up alarm picture operations.
  • Page 10 DS-8100-ST Series DVR Quick Operation Guide DS-8108/8116HCI-ST Rear Panel Note: DS-8108HCI-ST provides 8 video inputs and 8 audio inputs on rear panel. Item Description VIDEO IN BNC connectors for analog video input. AUDIO IN BNC connectors for analog audio input. SPOT VIDEO OUT BNC connector for monitor.

  • Page 11: Ds-8100Ah (F) (L) I-St Rear Panel

    DS-8100-ST Series DVR Quick Operation Guide DS-8100AH (F) (L) I-ST Rear Panel Item Description VIDEO IN BNC connectors for analog video input. AUDIO IN BNC connectors for analog audio input. BNC connector for video output. If VGA is connected, the interface will not function. VIDEO OUT If VGA is not connected, the interface is used as the main video output with local video display and menu operations.

  • Page 12: Connecting To Alarm Input / Output Device

    DS-8100-ST Series DVR Quick Operation Guide Connections Connecting to Alarm Input / Output Device Connections of DS-8100HCI-ST series DVR The alarm input/output interface of the DVR is shown below: DS-8104HCI-ST series DVR DS-8108/8116HCI-ST series DVR DS-8100AH (F) (L) I-ST series DVR The alarm input is an open/closed relay.

  • Page 13: Alarm Line Connection

    DS-8100-ST Series DVR Quick Operation Guide For DC load, JP4 can be used within the limit of 12V/1A safely. If the interface is connected to an AC load, JP4 should be left open. Use an external relay for safety (as shown in the figure above). There are 4 jumpers (JP4, JP5, JP6, and JP7) on the motherboard, each corresponding with one alarm output.

  • Page 14: Specifications

    DS-8100-ST Series DVR Quick Operation Guide Specifications Model DS-8104HCI-ST DS-8108HCI-ST DS-8116HCI-ST Analog video 4-ch 8-ch 16-ch input BNC connector (1.0Vp- 4-ch 8-ch 16-ch Video/Audio Audio input input BNC connector (2.0Vp- Voice talk input 1-ch, BNC connector (2.0Vp- 1-ch BNC connector (1.0Vp- CVBS output Resolution: PAL: 704×576, NTSC:704×480 Video/Audio...
  • Page 15 DS-8100-ST Series DVR Quick Operation Guide Model DS-8104AH(L)I-ST DS-8108AH(L)I-ST 4-ch 8-ch Analog video input BNC connector (1.0Vp- 4-ch 8-ch Video/Audio input Audio input BNC connector (2.0Vp- Voice talk input 1-ch, BNC connector (2.0 Vp- 1-ch, BNC connector (1.0 Vp- CVBS output Resolution: PAL: 704×576, NTSC:704×480 Video/Audio VGA output...
  • Page 16 DS-8100-ST Series DVR Quick Operation Guide Model DS-8104AHF(L)I-ST DS-8108AHF(L)I-ST 4-ch 8-ch Analog video input BNC connector (1.0Vp- 4-ch 8-ch Video/Audio input Audio input BNC connector (2.0Vp- Voice talk input 1-ch, BNC connector (2.0Vp-p, 1-ch, BNC connector (1.0Vp- CVBS output Resolution: PAL: 704×576, NTSC:704×480 Video/Audio VGA output 1-ch, resolution: 1024×768/60Hz...

  • Page 17: Hdd Storage Calculation Chart

    DS-8100HCI-ST Series DVR Quick Operation Guide HDD Storage Calculation Chart The following chart shows an estimation of storage space used based on recording at one channel for an hour at a fixed bit rate. Bit Rate Storage Used 128K 160K 192K 224K 256K...

  • Page 18: Menu Structure

    DS-8100HCI-ST Series DVR Quick Operation Guide Menu Structure The menu structure of the DS-8100-ST Series DVR is as followed: Startup and Shutdown Proper startup and shutdown procedures are crucial to expanding the life of your DVR. To start your DVR: 1.
  • Page 19 DS-8100HCI-ST Series DVR Quick Operation Guide 4. Click the Next button. This will take you to the General Settings dialog box. 5. Click the Enter button to enter the General Settings interface. 6. Select the language, output standard, VGA resolution and time zone here. If you do not need to input password whenever you enter the menu, you can disable password.

  • Page 20: Setting Date And Time

    DS-8100HCI-ST Series DVR Quick Operation Guide 15. To access Record Settings interface, click the Enter button. 16. Select the Schedule tab. 17. Click Edit button to enter a new recording schedule. 18. Check both the Enable Schedule and All Day checkbox. This will enable the recording schedule and make it record continuously all day.

  • Page 21: Live View

    DS-8100HCI-ST Series DVR Quick Operation Guide Live View Some icons are provided on screen in Live Preview mode to indicate different camera status. These icons include: Main Output Aux Output Event Alarm: Indicates video loss, video tampering, motion detection or relay alarm. Record: Indicates the current channel is recording.

  • Page 22: Preview Menu

    DS-8100HCI-ST Series DVR Quick Operation Guide Preview Menu Call Preset: Call a PTZ preset. Call Patrol: Call a PTZ patrol. Call Pattern: Call a PTZ pattern. Preset Settings: Enter PTZ preset configuration menu. Patrol Settings: Enter PTZ patrol configuration menu. Pattern Settings: Enter PTZ pattern configuration menu.

  • Page 23: Playback By System Log

    DS-8100HCI-ST Series DVR Quick Operation Guide Note:   You can search and playback video files by their card numbers. 3. Click the Play button to start playback of all the files found with the specified search criteria or click the Search button to bring up the list of search results.
  • Page 24 DS-8100HCI-ST Series DVR Quick Operation Guide Backup Recorded files can be backed up to various devices, such as USB flash drives, USB HDDs or a DVD writer. To export recorded files: 1. Enter the Export Video menu by clicking Menu > Video Search. 2.

This manual is also suitable for:

Ds-8108Ds-8108ah (l) i-stDs-8108ahf (l) i-stDs-8116hci-stDs-8104hci-stDs-8108hci-st
