You can view explanations of the operation of this watch by accessing the Citizen web
site and viewing the "Service & Support. "
URL: http://www.citizenwatch.jp/
U200_EN_final.indd 1
The combination watch
of the analog and digital
display
Solar-powered—no need
for battery replacement
(→ page 9)
World time—easy to see
the time and calendar
of 30 cities all over the
world (→ page 14)
World time alarm—sounds
at the time of the selected
city (→ page 26)
Chronograph function—
can display split time
(→ page 30)
Timer function—can be
set for up to 99 minutes
(→ page 32)
1
08.4.24 3:05:55 PM
Advertisement
Table of Contents
Related Manuals for Citizen U200
Summary of Contents for Citizen U200
- Page 1 30 cities all over the (→ page 32) world (→ page 14) You can view explanations of the operation of this watch by accessing the Citizen web site and viewing the “Service & Support. ” URL: http://www.citizenwatch.jp/ U200_EN_final.indd 1...
-
Page 2: Table Of Contents
Contents Before use ........4 Changing the mode ....12 Using the alarm [AL1]/[AL2] ..26 Resetting the watch ....36 Part names ..........4 Setting the alarm ......... 26 The initial settings ......37 World time function ....14 Checking the battery ......5 Activating/deactivating the alarm .. -
Page 3: Before Use
Before use 7 Part names 7 Checking the battery Confirm the movement of the second hand to check the battery. The second hand is moving at The second hand is moving at Button A Button B 1-second intervals. 2-second intervals or has stopped. Minute hand Hour hand Charge the battery. -
Page 4: Charging The Battery
Charging the battery 7 Charging the battery 7 When the battery becomes short of power—Insufficient charge warning function This watch has a battery which is charged by exposing the dial to light such as direct sunlight or fluorescent lamps. When the battery becomes short of power, the second hand moves once every two seconds—insufficient charge warning function. -
Page 5: Charging Time
Charging the battery 7 Charging time <After the battery is fully charged—Overcharge prevention function> Below are the approximate values for when exposing the dial to light continuously. After the battery is fully charged, charging automatically Use the table below only as a reference. stops to prevent overcharging, which may damage Illuminance Environment... -
Page 6: Power Saving Function
When the watch is not exposed to light for more than 30 minutes, all digital displays are automatically turned off to save the battery power. (Power saving function) While the function is activated... • All digital displays are turned off. •... -
Page 7: Changing The Mode
Changing the mode The digital section of this watch has 6 modes. To change the mode, press button M repeatedly Button M [TME] [CAL] [AL1]/[AL2] [CHR] [TMR] Set the alarm. Use the chronograph. Set the timer. • Displays the time. •... -
Page 8: World Time Function
World time function You can select one of 30 cities all over the world + UTC (Coordinated Universal Mode indicator Press button M repeatedly to change the Time)* and display its time/calendar. mode to [TME] or [CAL]. 7 Selecting the city Press button A or button B repeatedly to Select a city name as required when... -
Page 9: The Table Of City Names
World time function 7 The table of city names City Time City Time City Time City Time City name City name City name City name code difference code difference code difference code difference Coordinated Karachi Adelaide +9.5 Mexico City Universal Time ±0 –6 London... -
Page 10: Setting The Time
Setting the time 7 Setting the time of the digital section [TME] Press and hold button B until the daylight saving time indicator ( ) starts flashing. See page 22 to set the time of the You can adjust the time now. analog section of this watch. - Page 11 Setting the time Set the second/minute/hour Select 12-hour clock or 24-hour clock (1) Press button A (1) Press button A to select 12-hour clock (12H) or 24- Button B Button A repeatedly to set the hour clock (24H). flashing digit. •...
-
Page 12: Setting The Time Of The Analog Section
7 Setting the time of the analog section Turn the crown to the left or right to adjust the time. See page 18 to set the time of the digital section of this watch. Push in the crown to position 0 on the time tone on a radio, TV, etc. -
Page 13: Setting The Calendar [Cal]
Setting the calendar [CAL] Button B Button A Press button M repeatedly Set the month/day/year to change the mode to (1) Press button A repeatedly to set the flashing digit. [CAL]. • The digit changes continuously if you press and hold Press button A or B button A. -
Page 14: Using The Alarm [Al1]/[Al2]
Using the alarm [AL1]/[AL2] The way of setting the alarm are common to [AL1] and [AL2]. Select the city 7 Setting the alarm (1) Press button A repeatedly to select a city. Press button M repeatedly to Button B Button A •... -
Page 15: Activating/Deactivating The Alarm
Using the alarm [AL1]/[AL2] 7 Activating/deactivating the alarm Interrupting the alarm setting Press button M. Press button M repeatedly to change the mode to [AL1] or [AL2]. Button B Button A • The setting is interrupted in about 2 minutes without any operation. Adjustment before pressing button M is effective even when you interrupt the The current alarm setting is shown on digital display A and B. -
Page 16: Using The Chronograph [Chr]
Using the chronograph [CHR] You can measure times up to 23 hours 59 minutes 59 seconds 99, per 1/100 seconds. Press button A to start measurement. The measurement indicator ( ) appears. Button B Button A On measurement • When the measured time passes •... -
Page 17: Using The Timer [Tmr]
Using the timer [TMR] You can set the countdown timer from 1 minute up to 99 minutes per 1 minute. Press button A to start countdown. The timer indicator ( ) appears. Button B Button A Press button M • Each time you press button A, the countdown starts or stops. repeatedly to change the •... -
Page 18: Troubleshooting
Reset the watch. If the watch still does not work The watch does not work The digital displays seem unusual properly, contact the Citizen Service properly even if you have All indication on the displays Center or the store where you... -
Page 19: Resetting The Watch
Resetting the watch The watch may not work properly if it is affected by static electricity or shock. In this Push in the crown to position 0. case, reset the watch. The watch is reset. The confirmation tone sounds and all digital display indications are canceled. -
Page 20: Precautions
Precautions WARNINGS The unit “bar” is roughly equal to 1 atmosphere. “WATER RESIST(ANT) xx bar” may also be indicated as “W.R. xx bar. ” Water-resistance performance Before use, confirm the water-resistance level of your watch indicated on the dial and Examples of use case. - Page 21 This type of watch is resistant to minor exposure to water. For example, you may not become clear in a day, take the watch to your dealer or Citizen Service Center wear the watch while washing your face; however, it is not designed to be used for repair.
- Page 22 Precautions WARNINGS To avoid injury Handling the secondary battery • DO NOT wear the watch where the temperature becomes extremely high—such as in a sauna. Otherwise the watch may become hot and cause skin burn. • Do not remove the battery. When it is required, keep the battery out of the reach of children to prevent them from swallowing it.
-
Page 23: Maintenance
Your watch needs an inspection once every two or three years for safety and longer usage. To keep your watch water-resistant, the packing needs to be replaced regularly. Other parts need to be inspected and replaced if necessary. Ask for genuine Citizen parts upon replacement. U200_EN_final.indd 44-45 08.4.24 3:08:30 PM... -
Page 24: Specifications
Specifications Model U20* Additional • Power saving function (battery saving mode) functions • Overcharge prevention function Type Combination solar-powered watch • Insufficient charge warning function Timekeeping Within ±15 seconds per month on average (when • World time function accuracy worn at normal temperatures between +5˚C/41˚F and •... - Page 25 U200_EN_final.indd 48 08.4.24 3:08:30 PM...
