  • Page 1 POWERVAR Grounding Technology Solutions Uninterruptible Power Manager For use with ABCEG251, ABCEG401, and ABCEG601...
  • Page 2 TABLE OF CONTENTS 1.0 - Introduction ..............5 2.0 - Safety Instructions............9 3.0 - Installation................ 12 4.0 - Operation ................16 5.0 - Maintenance ..............24 6.0 - Specifications ..............29 7.0 - Troubleshooting .............. 35 8.0 - Warranty ................. 37 GTS Series Uninterruptible Power Manager...
  • Page 3 Notwithstanding the stated warranty in Sections 1 and 8. POWERVAR’s standard warranty term does not apply in these cases and is supplanted by a 90 day warranty from time of shipment from POWERVAR.
  • Page 4 Danger- The danger symbol is used to indicate imminently hazardous situations, locations, and conditions which, if not avoided, WILL result in death, DANGER serious injury, and/or severe property damage. Caution- The caution symbol is used to indicate potentially hazardous situations and conditions which, if not avoided, may result in injury.
  • Page 5 POWERVAR power quality solution for your application. We understand that your decision was a careful one and that your purchase of a POWERVAR product is an expression of confidence in our company. We promise to always work our hardest to make certain that your confidence in our products and our company is well deserved.
  • Page 6 General The POWERVAR GTS Series UPM systems are the most advanced, line interactive, true sinewave UPS products available for your application. Each model is designed to provide total protection for your system from a complete range of power quality problems. GTS Series UPM systems will protect your installation from normal mode voltage impulses, electrical noise, sags and surges, brownouts, and blackouts.
  • Page 7 This type of activity results in unnecessary strain on the battery and may eventually shorten its life. POWERVAR’s GTS Series UPM products feature Voltage Manager – a circuit that constantly monitors the AC power source.
  • Page 8 If you want added functionality including; data and event logging, auto- run command files before shutdown, access to GTS configuration and integrated network agent for central monitoring via POWERVAR ManageUPS CIO Server software, download and use POWERVAR ®...

  • Page 9: Safety Instructions

    Always observe proper precautions. When replacing batteries, use the same quantity, rating and type of batteries used by POWERVAR. The batteries used in this UPM are sealed lead-acid and are maintenance free. Proper disposal of batteries is required.
  • Page 10 NOTE: • Do not disassemble the UPM. • Do not attempt to power the UPM from any receptacle except a properly grounded receptacle that matches the input plug provided with the UPM. • Do not place the UPM near water or in environments of excessive humidity. •...
  • Page 11 CAUTION Risk of Energy Hazard, 12 V, 8.5 Ampere-hour battery for ABCEG251 and ABCEG401. Before replacing batteries, remove conductive jewelry such as chains, wrist watches, and rings. High energy through conductive materials could cause severe burns. CAUTION Risk of Energy Hazard, 24 V, 8.5 Ampere-hour battery for ABCEG601.
  • Page 12 3.0 INSTALLATION This section explains: • Equipment inspection • Unpacking the unit • Checking the accessory kit • Cabinet installation • Initial startup Inspecting the Equipment If any equipment has been damaged during shipment, keep the shipping cartons and packing materials for the carrier or place of purchase and file a claim for shipping damage: 1.) File with the carrier within 15 days of receipt of the equipment.
  • Page 13 To unpack the unit and accessories: 1.) Open the outer carton and remove the accessories packaged with the unit. 2.) Carefully lift the unit out of the outer carton. 3.) Discard or recycle the packaging in a responsible manner, or store it for future use.
  • Page 14 Operational Tests Observe the front panel of the UPM. The following table shows how the front panel LED should appear upon start-up Load Voltage Over Temperature Indicator Monitor Manager Battery LED Fault LED LED’s Normal Status Flashing NOTE: Depending on the charge state of the battery, it is possible that the battery LED may be flashing (this is normal).
  • Page 15 UPM battery has had at least six hours to charge. • POWERVAR recommends that you do not plug laser printers into the UPM. Laser printers are known to draw large amounts of current when the fuser/heater assembly is energized.
  • Page 16 4.0 OPERATION NOTE: In order to operate the UPM, you must first plug the battery plug(s) into the battery socket(s) behind the front panel of the UPM. 250/400 VA 600VA GTS Series Uninterruptible Power Manager...
  • Page 17 On/Off Button The On/Off button is a dual function control: • When the UPM is off and AC power is present to the UPM input, pressing the On/Off button for more than 3 seconds will turn the UPM on. If battery enable plug(s) are installed, pressing the On/Off switch for 3 seconds or more will “cold-start”...
  • Page 18 Status Monitor The status monitor is a row of four individual LED’s that each indicate the status of a part of your UPM system. The first three LED’s work with the GTS Series Voltage Manager. All four LED’s are explained in the following table.
  • Page 19 UPM and will cause the Site Wiring Fault LED to illuminate. MopUPS Express Port POWERVAR GTS Series provides various communications modes to give you options for: • Protecting data on a computer powered by UPM when battery runs low •...
  • Page 20 HID Battery. You can use native power options/power management scheme (Windows, MacOS or Linux) to initiate automatic safe shutdown of your computer without adding software from Powervar. (See POWERVAR application Note 70 for assistance in using this option.) Use POWERVAR MopUPS Express Software, ®...
  • Page 21 If you need to use Legacy signaling, and need help designing a cable for your system, contact POWERVAR application engineering. There may be an hourly charge for consulting time to research, design and document custom cables for legacy interface applications.
  • Page 22 RJ11 Signal Polarity/Function Low (ON) when battery has less than 2 Low Battery (Out) minutes remaining run time AC Fail (Out) When unit is on battery No Connect No Connect Shutdown UPS (with 10 second delay) Shutdown when signal is High (present) for more Inverter than 3 seconds and UPS is on Battery Common...
  • Page 23 Start Manager When AC power is not available, such as in a new installation where wiring may be incomplete, you can still start the UPM to test its operation and the operation of your system using Start Manager. With the UPM off, follow these simple steps: 1.

  • Page 24: Important Information

    5.0 MAINTENANCE Storage The UPM may be stored for extended periods in an environment that does not subject the UPM to extremes of temperature or humidity. When storing for extended periods, the battery should be charged every six months. If the storage location is characterized by above normal temperature, the battery should be recharged every two months.
  • Page 25 • Do not open or mutilate the batteries. This may release electrolyte that is toxic to the environment and harmful to the skin and eyes. • Replacement batteries may be ordered from POWERVAR by phone or via our website at www.powervar.com. If purchasing batteries from another source, be sure to use the type and quantity of batteries.
  • Page 26 User Replaceable Battery NOTE: Changing the batteries in this UPM is designed to be a safe and simple procedure. Batteries may be replaced while the UPM is on and providing power to the connected load. You should remember that if a power outage occurs after the old batteries are disconnected and before the new batteries are installed, power will be lost to your connected system and components.
  • Page 27 CAUTION Do not dispose of batteries in a fire. The batteries may explode. CAUTION Do not open or mutilate batteries. Released material is harmful to the skin and eyes. It may be toxic. NOTE: If you have read and understood the cautions preceding this section, you may proceed with the following steps.
  • Page 28 Figure 2: 250/400 VA Figure 3: 600 VA GTS Series Uninterruptible Power Manager...

  • Page 29: Specifications

    6.0 Specifications REAR PANEL - 250 VA MODELS NORTH AMERICAN INTERNATIONAL GTS Series Uninterruptible Power Manager...
  • Page 30 REAR PANEL - 400 VA MODELS NORTH AMERICAN INTERNATIONAL GTS Series Uninterruptible Power Manager...
  • Page 31 REAR PANEL - 600 VA MODELS NORTH AMERICAN INTERNATIONAL GTS Series Uninterruptible Power Manager...
  • Page 32 North American Electrical Ratings Rated VA Rating/ Frequency Max Output Amps Model Number Voltage Watts (Hz) @ 120VAC (VAC) 250/200 ABCEG251-11 2.0/1.6 400/320 ABCEG401-11 3.3/2.6 600/480 ABCEG601-11 5.0/4.0 International Electrical Ratings Rated VA Rating/ Frequency Max Output Amps Model Number...

  • Page 33: Battery Charger

    • Output frequency – AC mode: Follows Input Inverter mode: • 50 Hz or 60 Hz. + 0.1 Hz. (determined by power line frequency prior to outage) • THD (inverter mode) = < 4% on battery • Backup time full load = > 5 min •...
  • Page 34 Noise Rejection and Isolation With unit under power and an ANSI/IEEE C62.41 Category A impulse applied either normal mode or common-mode at the input, the noise output voltage will be less than 10 volts normal mode and 0.5 volts common-mode in all four quadrants (CM-NM, NM-NM, CM-CM, NM-CM) Surge Voltage Withstand Tested under power to ANSI/IEEE C62.41 Category A &...

  • Page 35: Troubleshooting

    7.0 TROUBLESHOOTING Problem Possible Cause Action you should take 1. On/Off Button not pressed long enough 2. No incoming line 1. Press and hold the On/Off switch for 3 seconds. UPM does not power voltage or voltage too 2. Check wall socket and test for proper line voltage. up and has no audible high or too low 3.
  • Page 36 In North America, call toll free at (800) 369-7179. Our North American fax number is (847) 596-7100. In Europe, POWERVAR provides technical support between 8:00 and 17:00 GMT. Contact our European headquarters at +44 (0) 1793-553980 or visit our website at www.powervar.com for more locations.
  • Page 37 (known hereafter as the “product”) to be free from defects in materials or workmanship for a period of five years from the date of shipment. POWERVAR warrants the batteries used in the product to be free from defects in materials or workmanship for a period of two years from the date of shipment.
  • Page 38 Europe/Asia Address: Unit 5, Birch-Kembrey Park A01-00030 Rev A– 4/2013 - © 2013 Swindon, Wilts SN2 8UU UK POWERVAR, Inc. (P) +44 1793 553980 (F) +44 1793 535350 Mexico Address: Camino a la Montana No. 178-101 & PB4 Fracc.
