Function buttons(continued)
TIMER OFF Button
13
Press this button to initiate the auto-off time
sequence. Each press will increase the
auto-timed setting in 30 minutes increments.
When the setting time displays 10H, each
press will increase the auto-timed setting
60 minutes increments. To cancel the
auto-timed program, simply adjust the
1
auto-off time to 0.0
8
ON/OFF
LED/FOLLOW ME Button
14
9
TEMP
Disable/Active indoor screen Display. When
pushing more than 2 seconds, the FOLLOW
2
SHORT
MODE 10
CUT ME function will be activated, pushing more
than 2 seconds again to disable.
FAN
3
SWING
SPEED
11
LOCK Button
15
12 When you press the recessed LOCK button,
4 TIMER
DIRECT
ON
all current settings are locked in and the
remote controller does not accept any
13
SLEEP TIMER
5
OFF
FRESH operation except that of the LOCK. Press
again to cancel the LOCK mode.
TURBO
LED
14
6 SELF FOLLOW
CLEAN
ME
7
LOCK RESET
15
,
,
NOTE:
Buttons design might be slightly
different from the actual one you
purchased depending on individual
models.
All the functions described above
are accomplished by the indoor unit,
if the indoor unit has no this feature,
there is no corresponding operation
happened when press the relative
button on the remote controller.
7 7

Indicators on LCD

Transmission Indicator
This transmission indicator lights when remote
controller transmits signals to the indoor unit.
Mode display
Displays the current operation mode. Including
auto(
applicable to cooling only models), fan(
and back to auto(
Temp./Timer display
Displays the temperature setting(17C ~30C ). When
auto cool dry heat fan
you set the operating mode to FAN, no temperature
setting is displayed. And if in the TIMER mode, shows
the ON and OFF settings of the TIMER.
SET TEMP. TIMER ONOFF
Fan speed display
Displays the selected fan speed, AUTO(no display)
and three fan speed levels " " (LOW) "
" " (HIGH) can be indicated. The fan speed is AUTO
when the operating mode is either AUTO or DRY.
ON/OFF display
sleep follow me lock run
Displayed by pressing the ON/OFF button.
Press the ON/OFF button again to remove.
Lock Display
Displayed when LOCK mode is activated.
FOLLOW ME Display
Displayed when FOLLOW ME function is activated.
Sleep Display
Displayed under sleeping operation.
Press the SLEEP button again to remove.
Note:
All indicators shown in the figure are for the purpose
of clear presentation. But during the actual operation
only the relative functional signs are shown on the
display window.
), cool( ), dry( ), heat( ) (Not
)
).
O O
" (MED)
