Indicators on LCD

Information are displayed
when the remote controller is
powered up.
All manuals and user guides at all-guides.com
Mode display
AU TO
HE AT
Displayed when data transmitted.
Displayed when remote controller is ON.
Battery display (low battery detection)
Not available for this unit
Displayed when TIMER ON time is set.
Displayed when TIMER OFF time is set.
Show set temperature or room temperature, or
time under TIMER setting.
Displayed in Sleep Mode operation.
Indicated that the air conditioner is operating in
Follow me mode
Not available for this unit
Not available for this unit
Fan speed indication
Note:
All indicators shown in the figure are for the purpose of
clear presentation. But during the actual operation only
the relative functional signs are shown on the display
window.
7
COOL DRY
FAN
Low speed
Medium speed
High speed
Auto fan speed
