Content Introduction......................3 Hardware Installation.................... 3 The Display Timing....................5 The Display Outline Dimensions................6 The Display Controls .................... 7 The Screen Adjustment ..................8 Troubleshooting Tips ..................10 Specification ......................11 Product Safety Precautions................12 Page 2... -
Page 3: Introduction
Introduction Welcome to enjoy the fantastic sightseeing world. This new technology will bring you the whole new feeling about the “monitor”. We show here some of the major advantages of the LCD monitor. You will really find some other advantages when you use it. Hardware Installation This chapter will guide you the correct installation procedures of your LCD monitor. - Page 4 The following picture provides the connection outline Video Input Pin Assignment This section describes the pin assignment of the LCD’ s video connector. It is called 15pin Mini D-sub connector. Pin No. Signal Connector Red Video Signal Green Video Signal Blue Video Signal N.C.
-
Page 5: The Display Timing
The Display Timing Applicable video timing The following table lists the better display quality modes that the LCD monitor provides. If the other video modes are input, the monitor will stop working or display unsatisfactory picture quality. VESA Modes Mode Resolution Total Nominal... -
Page 6: The Display Outline Dimensions
The Display Outline Dimensions Unit: mm Page 6... -
Page 8: The Screen Adjustment
The Screen Adjustment Main Menu You can adjust the brightness, contrast, display colors, the horizontal and vertical position of the display and OSD menu, etc. through the main menu display. The Down Key < and Up Key >are used to scroll through items within the menu. The selected item is highlighted as the scrolling move along. -
Page 9: Osd Control Key
The Screen Adjustment OSD Control Key Power key : Power ON/OFF. Menu key : Enter the main menu of the on-screen display (OSD). Down key : Decrease item number or item value when OSD is on. Decrease volume gain when OSD is off. Up key : Increase item number or value of the selected item when . -
Page 10: Osd Control Function List
The Screen Adjustment OSD Control Function List ¡ » OSD For PC input Page 10... -
Page 11: Main Menu
The Screen Adjustment Main Menu: Press “Up” or “Down” to locate the item you desire to change, then press “Select” to make the adjustment, press “Menu” again to go back to previous menu. This item can adjust Auto Adjust, Brightness, Contrast, Pixel Picture Adjust Clock, Phase, H-Position and V-Position for an optimal image. - Page 12 The Screen Adjustment Moves the display picture. Horizontal Position Press “Up” to the right or press “Down“ to the left. Moves the display picture. Vertical Position Press “Up” to the up or press “Down“ to the down. Color Select 9300 color temperature 9300K Press “Select”...
- Page 13 The Screen Adjustment Audio Adjust Volume gain Volume Press “Up” to increase or press “Down“ to decrease. Set Audio mute. Mute Press “Up” to execute mute or Press “Down“ to release mute. Adjust audio Treble . Treble Press “Up” to increase or press “Down“ to decrease. Adjust audio bass .
- Page 14 The Screen Adjustment This item can select sub source (Off, AV, S-Video, TV, and Sub Source Component) Press “Select” to execute.. Select audio come from Main Source or Sub Source. Audio Press “Up” to come form Main Source Press “Down” to come form Sub Source. Change the Sub Picture Size.
- Page 15 The Screen Adjustment Press “Up” to the up or press “Down“ to the down. Change the Sub Picture color setting. PIP Color Press “Select” to execute. Five items can be adjusted in PIP color function Brightness: Adjusts the sub picture brightness. Contrast: Adjusts the sub picture contrast.
- Page 16 The Screen Adjustment Adjusts the OSD position up or down OSD V-Position Press “Up” to up, press “Down“ to down. Adjusts the OSD transparency. OSD Transparence Press “Up” or “Down“ to adjust the parameter. Adjusts the OSD exit time. Off Time Press “Up”...
- Page 17 The Screen Adjustment This item can adjust video color as Brightness, Contrast, Image Adjust Saturation Hue, Sharpness. This item can adjust audio function. As Volume, Mute, Treble, Audio Base, Balance. This item can Select Source input (PC, AV, S-Video, TV, System Component.) and Recall System data.
- Page 18 The Screen Adjustment Page 18...
- Page 19 The Screen Adjustment Image Adjust, Audio, System and OSD are same as Video mode Select Air TV or Cable TV system AIR / CATV Press “Up” for Cable TV or press “Down” for Antenna TV Set Multi-Channel Television Sound. STEREO: A primary language and Hi-Fi system broadcast. SAP: A second language broadcast.
- Page 20 The Screen Adjustment Change the TV Channel . Channel Press “Up” to next channel or press “Down“ to previous channel. Channel memories or erase . CH Memory Press “Up” to add a new channel or press “Down“ to erase a channel. Auto Channel scan .
- Page 21 The Screen Adjustment . Remote Control Function List 1. POWER Power On/Off. 2. Input Source Select TV: Select TV video input. PC: Select PC-VGA input. AV: Select AV video input. S-VIDEO: Select S-VIDEO video input. COMP.: Select Component video input 3.
-
Page 22: Quick Installation
Quick Installation Please foll ow t he following descriptions stepby step. (The 7 diagrams can also be your references): Step 1 Step 2 Step 3 Step 4 Step 5 Ste p 6 Step 7 Step 1 Plug o ne terminal of the VGA cable to the sig nal conne ctor at th e rear of t he LCD M onitor. Step 2 Plug the other terminal o f the VGA cable to t he signal connecto r at the r e ar of PC. -
Page 23: Troubleshooting Tips
Troubleshooting Tips In the event that you experience trouble with your Display, check the following items before contacting the dealer from whom the Display was purchased. The most common problems usually involve an incorrectly an incorrect connection from the Video Card to the Display. We recommend that you also consult your Video Card User’... -
Page 25: Product Safety Precautions
Product Safety Precautions Follow all warnings and instructions marked on the product. Do not use this product near water. This display should be installed on a solid horizontal base. When cleaning, use only a neutral detergent cleaner with a soft damp cloth. Do not spray with liquid or aerosol cleaners.
