TRP-C41
User's Manual
Ethernet To Fiber Media Converter
User's Manual
Printed Oct. 2013 Rev 1.2
Trycom Technology Co.,Ltd
No.35, Zhongxing Rd., Guishan Township, Taoyuan County 333, Taiwan.
Tel : 886-3-350-3351 Fax: 886-3-350-3352
Web:
www.trycom.com.tw
Copyright
Copyright Notice: The information in this manual is subject to change without notice to improve reliability, design and
function and
does not represent a commitment on the part manufacturer. No part of this manual may be
reproduced, copied, or transmitted in any form, without prior written permission by the manufacturer. Products
mentioned in this manual are mentioned for identification purposes only. In this manual, product names appearing
may or may not be registered trademarks of their respective companies or copyright.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Trycom Technology TRP-C41
Summary of Contents for Trycom Technology TRP-C41
- Page 1 TRP-C41 User’s Manual Ethernet To Fiber Media Converter User’s Manual Printed Oct. 2013 Rev 1.2 Trycom Technology Co.,Ltd No.35, Zhongxing Rd., Guishan Township, Taoyuan County 333, Taiwan. Tel : 886-3-350-3351 Fax: 886-3-350-3352 Web: www.trycom.com.tw Copyright Copyright Notice: The information in this manual is subject to change without notice to improve reliability, design and function and does not represent a commitment on the part manufacturer.
- Page 2 1. Introduction TRP-C41 is a device for Ethernet extension over fiber, it supports point-to-point and networked systems. The high fiber bandwidth connections solve problems with electrical noise and different ground potentials over long transmission lines. TRP-C41 supports 10/100Base-TX transmissions up to 100 meters and 100Base-FX transmissions up to 60KM. It is the perfect solution for wide distance connections with high immunity to electrical noise.
- Page 3 2. Hardware description 2-1. Panel layout 2-2. Block Diagram...
- Page 4 DC adapter, user may input power from either screw terminal block or DC adapter. 3-3. Ethernet Connection TRP-C41 support auto MDI/MDIX RJ-45 cable that mean user may use a straight-through or crossover cable connection between TRP-C41 and Ethernet hub, switch, or wall plate. And also can link directly to the NIC (Network Interface Card) on a PC or laptop.
- Page 5 TRP-C41 has a 100Mbps fiber port with single mode SC fiber connector, user may use standard 62.5/125um, 1310 nM wavelength fiber cable for TX and RX connection, when fiber cable is connected the F-Link, F-SD and F-FDX LED will light up.
