RLXIB-ICN ♦ 802.11n
Industrial Client
Parameter
Parent SSID
Parent Signal Strength
Available Parent Alternates
This table displays the list of available parents for this particular radio when it is
configured to be in a Repeater or Client role. Master role radios do not have
entries for this table. The following information is displayed:
Parameter
Name
SSID
Channel
RSSI
MAC ID
Last Heard
Access Points on this Card
This radio card can support up to 4 APs: one management (trunk) link and 3
virtual AP's which can have unique VLAN IDs. This section outlines the
properties of each configured AP.
Parameter
SSID
Name
Mode
Security
Attached Clients
ProSoft Technology, Inc.
July 25, 2013
Description
The SSID of the parent link, if applicable
For radios that are connected to upstream parents, the wireless signal
strength in dBm of the parent link is displayed here.
Description
The name of the available parent
The available parent's SSID; this defines the wireless network.
The broadcast channel used by the available parent and wireless
network in general.
The received signal strength indicator (in dBm) of the parent; it is an
indicator of signal strength between this device and the available
parent
The available parent's MAC address.
This is the time in seconds since this available parent was most
recently heard.
Description
The AP is identified by its SSID
The unique identifier of this AP
The mode of operation for this AP's role in the wireless network
Master (there can be only 1 per SSID-defined network), Repeater, or
Client.
the type of security used by this AP, e.g. WEP, WPA etc.
This table lists all connected clients, whether they are true wireless
clients or bridge devices in Repeater or Client mode. The client Name,
detected RSSI, MAC ID, and Last Heard data is available.
WirelessN Discovery Tool
User Manual
Page 95 of 129
