RLXIB-ICN ♦ 802.11n
Industrial Client
5

WirelessN Discovery Tool

In This Chapter

View the List of Detected Radios ........................................................... 82

View Radio Network Diagram(s) ........................................................... 83

Configure Radios ................................................................................... 83

Scan the Network .................................................................................. 84

Save and Load Snapshots .................................................................... 84

Event Log .............................................................................................. 85

Firewall Requirements ........................................................................... 85

Radio List .............................................................................................. 86

Topology View ....................................................................................... 87

Radio Detailed View .............................................................................. 93

Discovery Tool Menus and Toolbars ..................................................... 98
The WirelessN Discovery Tool allows you to manage and monitor supported
radios in a wireless network. This program uses proprietary discovery protocol
messages to display a network topology diagram and current detailed information
for each detected device. For each detected node you can set the IP address or
upgrade the device firmware, or launch the graphical management interface to
access more comprehensive status and configuration options.
The WirelessN Discovery Tool supports Microsoft Windows XP (all editions and
service packs) and Microsoft Vista (all editions) operating systems. Please
contact ProSoft Technology Inc. for questions relating to support for other
operating systems.
The WirelessN Discovery Tool supports the following network discovery and
monitoring activities:

Discover and view the list of radios in the network (page 82)

Display graphically the current network topology and display parent-child links
between various radios in the network (page 87)

Scan the network on demand (page 84)

Save and load network snapshots (page 84)

Upload and download configuration files to/from radio devices (page 90)

Upgrade Radio firmware (page 91)
