RLXIB-ICN ♦ 802.11n
Industrial Client
Button
Manage
Download Settings
Upload Settings
Assign IP
Upgrade
Notification Bar
The status bar is located immediately below the main content screen. This bar is
displayed when a status message is present and these messages can highlight a
topology change, scan events, or other information gathered by the utility. Each
message has a timestamp, and if required the status bar can be closed with the
"x" icon on the right of the bar.
ProSoft Technology, Inc.
July 25, 2013
Description
Clicking this button will launch the graphical management interface for
the selected radio using your default web browser. The IP address of
the device is used to access the supported radio's management
interface.
this button will launch a dialog box that allows you to download the
radio's ASCII configuration file to your host. You must enter the radio's
username and password (same as the management interface
credentials) and also indicate the file name on your host to save the
downloaded file.
This button will launch a dialog box to upload a device configuration file
on your host to the radio. You must enter the radio's username and
password (same as the management interface credentials) and also
indicate the directory on your host where the configuration file to upload
is located.
This button will open a dialog box to let you set a static IP for the radio.
You can define the static IP address, subnet mask, and gateway for the
radio via this interface.
This button will launch a dialog box where you can upgrade the radio's
firmware. You must enter the radio's username and password (the
management interface access credentials) and then identify the
directory path and filename of the firmware to upgrade the radio.
WirelessN Discovery Tool
User Manual
