2 . S P E C I F I C A
2 . S P E C I F I C A
2-2-2 OUTDOOR FAN MOTOR
ELECTRIC PERFORMANCE
Motor model
Rated power source
Fan capacitor
Poles
Rated load output(W)
Ambient temperature(℃)
2-2-3. COMPRESSOR
ELECTRIC PERFORMANCE
Compressor model
Compressor type
Motor type.
Motor Starting type
Winding resistance（at 25℃）
Number of cylinder
Oil type
Oil charge (cc)
Input power(W)
Current (A)
Ambient temperature(℃)

2-3. Other component specifications

2-3-1. LOUVER MOTOR
ELECTRIC
PERFORMANCE
Stepper Motor model
Voltage(DC)
Number of phase
Drive mode
Resistance per phase
Relative humidity(RH)
Temperature range(℃)
T I O N S
T I O N S
PARAMETER
DG13Z1-39
208~240V 50Hz
1.5μF/450V
---
25W
-5℃～+43℃.
PARAMETER
39A23VPM&5JKE
Rotary
Direct current brushless motor
Direct current brushless inverter starting
U-V（or V-W）:2.550Ω±7%；W-U: 2.60Ω±7%
1
Zegles RB68EP or equivalent
370±10
910±5%
4.3
-5℃～+43℃.
PARAMETER
DG13B1-01
12V
4
1-2 phase excitation unipolar drive
200Ω±7%
45%～85%
-10℃～+40℃.
4
