Summary of Contents for XVision EVD4E-3
- Page 1 4CH STANDALONE DVR USER MANUAL 2008 APR. Ver 1.1 ALARM ALARM Remote...
- Page 2 空 白頁...
-
Page 3: Hdd Support List
4CH STANDALONE DVR HDD SUPPORT LIST Warning： Should you wish to install a new hard drive in this unit, a list of tested hard drives shown to be compatible can be found below. S A T A Brand Maxtor Seagate HITACHI 160GB 160GB... -
Page 4: Sata To Pata Convert Board
4CH STANDALONE DVR CONTENT 1、FEATURE 2、SPECIFICATIONS 3、INSTALLATION 4、FRONT PANEL 5、OPERATING MANUAL 6、VIEW CONTROL 7、PLAYBACK CONTROL 8、RECORD CONTROL 9、4 CHANNEL RECORDING HOURS 10、DVR Viewer User Guide 11、 CONTROL REMOTE GUIDE (Option) 12、SATA TO PATA CONVERT BOARD (Option) - Page 5 4CH STANDALONE DVR 1、FEATURE 1、Definitely Standalone. 2、Real Time Refresh Rate. 3、Display While Recording. 4、Frame Recording & Quad Recording. 5、Compatible of NTSC/PAL format. 6、Advanced MJPEG. 7、Manual / Motion / Programmed 8、 Systems records automatically while alarming. 9、Search by Time / Date. 10、Watch dog feature.
-
Page 6: Specifications
4CH STANDALONE DVR 2、SPECIFICATIONS ITEM DESCRIPTION Video Format NTSC/PAL System Embedded RTOS VGA OUTPUT D-SUB 15Pin VGA Video Input Channel 4CH (1Vp-p 75 Ω ) BNC Video Output Channel 1CH (Monitor Out) BNC Audio Input Channel 1CH RCA Audio Output Channel 1CH RCA 120 fields/s (4x30 fps) Display Frame... - Page 7 4CH STANDALONE DVR 3、INSTALLATION REAR PANEL TYPE A AUDIO IN DEFAULT DC12V VIDEO OUT VIDEO IN TYPE B AUDIO IN DEFAULT DC12V VIDEO OUT VIDEO IN TYPE C AUDIO IN DEFAULT DC12V VIDEO OUT VIDEO IN Option XGA Output (2) Video Output : Corresponding to Video Input. (3) Video IN : Cameras to Video Input.
-
Page 8: Front Panel
4CH STANDALONE DVR 4、FRONT PANEL ( 2 ) ( 9 ) (10) ( 4 ) ( 7 ) ( 5 ) ( 8 ) ( 6 ) ( 3 ) (11) (12) (1) USB PORT (2) Power Indicator (3) HDD Indicator (4) Move Up / Camera 1 Display (5) Move Left / Camera 2 Display (6) Move Down / Camera 3 Display... -
Page 9: System Setup
4CH STANDALONE DVR 5、OPERATING MANUAL (MAIN MENU) MAIN MENU SYSTEM SETUP CAMERA SETUP RECORD SETUP RECORD SCHEDULE MOTION SETUP HARD DRIVE SETUP (Option) XGA RESOLUTION : 1024 X 768 SYSTEM RESTORE ) : SELECT ( ) : SET ) : EXIT (Option) XGA RESOLUTION : 640X480, 800X600, 1024X768 ( default setting) -
Page 10: Time Setup
4CH STANDALONE DVR is:"1" is:"2" is:"3" is:"4” TIME SETUP Select this item to set up current time. TIME SET 2008/03/16 18:00:30 ): SELECT ):SET ):EXIT Press to select items, use to enter. Press to exit CAMERA SETUP CAMERA SETUP CAMERA : CH1 LIVE ON/OFF : ON... -
Page 11: Record Schedule
4CH STANDALONE DVR RECORD SCHEDULE RECORD SCHEDULE TTTTTTTTTTTTTTTTTTTTTTTT 15 18 21 Press to select items, use to enter. Press to exit (1)Range: 0-24 hrs. (2)Set ”T” for continuous recording. (3)Set “M” for motion recording. (4)Set up ”-” to disable the recording. MOTION SETUP MOTION SETUP MENU CHANNEL-1... -
Page 12: Playback Control
4CH STANDALONE DVR 7、PLAYBACK CONTROL (1)Press , and the system will play the latest event which you haven't seen before. (2)Press , and the system will enter the PLAYBACK EVENTS SEARCH MODE. (3)Each period is as four hour. SEARCH TIME HARD DRIVE : MASTER Selec t Start Date/ 08/03/16 02:47:56 - 08/03/18 02:47:56... - Page 13 4CH STANDALONE DVR 9、4CH RECORDING HOURS ON 80GB HARD DRIVE *Thereinafter a rough estimate a table for reference only, recording data quantity can follow an image a variation a rate somewhat different. Re cording Re sults in NT SC Forma t Video 30 fps 15 fps...
-
Page 14: Installation
4CH STANDALONE DVR 10、DVR PC Viewer User Guide Introduction This document is the Operation Manual for the 4 CH Stand Alone DVR PCViewer. The application will show you stream image stored in the Storage Device (HDD, CF card, USB Memory Stick, etc.), which was previously formatted and recorded by the DVR. If any DVR-formatted Storage Device is connected to your PC, the application will automatically detect the Storage Device and show the recorded stream. - Page 15 4CH STANDALONE DVR Execution Just double click the icon of PC Viewer. The application will try to detect physical storage devices installed at your PC and search for DVR storage device(s) among them. If there is DVR Storage Device, the application will automatically start playing. However, If the application fails to detect DVR Storage Device, which means that there is no DVR Storage Device installed to your system, it will show following error message and set the default working mode to MYS P layer (See Section.
- Page 16 4CH STANDALONE DVR (12) (11) (4) (5) (10) Screen PC Viewer Playback Control Positioning Slider Bar Capture Stream Button [MYS] Screen Capture Button [JPEG] MYS Player Button Audio Control DVR Storage Device Change Button (10) (11) Viewer Playback Mode DVR Storage Device Information (12) Stream Time Display Channel Selection...
- Page 17 4CH STANDALONE DVR iii. DVR Storage Device Information Button If you want to know how big is the DVR storage device is, or how much stream data is stored in the device, press this button. Fig.4 shows the DVR storage device information window. Fig.4.
- Page 18 4CH STANDALONE DVR vi. Capture Stream Button If you want to capture stream, follow the stream capture procedure listed below: * Using Positioning Slider Bar find the stream position you want. * Make sure that the playback is in PAUSE mode, and the Capture Stream Button is enabled. * Press the button, then the application will start capturing.
- Page 19 4CH STANDALONE DVR (10) Screen MYS file information MYS File Select Dialog MYS File Playback Control Positioning Slider Bar Screen Capture Button [JPEG] PC Viewer Button Audio Control File Open Button Playback Status (10) Fig.9. MYS File Player User Interface B.
-
Page 20: Application Setting
4CH STANDALONE DVR * Press button (or [<-] Key) to start fast reverse playback. By pressing this button again, you can adjust the speed. The maximum speed is 64 times faster than reverse playback. * Press button (or [<-] Key) to start reverse playback. * Press button (or [Space Bar]) to pause playback. - Page 21 4CH STANDALONE DVR 11、REMOTE CONTROL GUIDE (Option) CH2 display CH1 display Record CH3 display Quad display/ Sequence Switch CH4 display MUTE MENU Navigator Fast Reverse Fast Forward Play Stop record/ Stop playback Pause...
- Page 22 4CH STANDALONE DVR Foreword This is a SATA convert PATA interface PCB board, 12、SATA TO PATA CONVERT BOARD before using the product, please read this manual carefully for further recognizing for the product! (Option) I. Key Feature Convert SATA TO PATA interface Transfer rate max up to 66/100/133MB/sec No SATA HDD capacity limited LED indicators for Power(green) &...
- Page 23 4CH STANDALONE DVR One PATA cable with one SATA HDD, Jumper set to Master ( Jumper off ) One PATA cable with two SATA HDD, Jumper one set to Master ( Jumper off ); another set to Slave(Jumper on) Using JBOD ( Big ) special function One PATA cable with two SATA HDD, Jumper one set to Master ( Jumper off );...
- Page 24 H12C420V03...
