FEC -150 User Manual

Thermal printer
Hide thumbs
Table of Contents

Advertisement

Quick Links

User Manual
FEC-150
Thermal Printer
Rev. 1.00
http://www.Firich.com.tw

Advertisement

Table of Contents
loading

Related Manuals for FEC FEC-150

Summary of Contents for FEC FEC-150

  • Page 1 User Manual FEC-150 Thermal Printer Rev. 1.00 http://www.Firich.com.tw...

  • Page 2: Safety Warning

    FEC-150 ■ Safety Warning Proper use of this product can prevent hazardous or physical harm. Make sure all following instructions are followed when using this product. Warning Violation of following instructions may cause serious injure or risk of life. Please use the adapter provided.
  • Page 3 FEC-150 Caution Violation of following instructions may cause slight injure or damage to the product. Power off and take following actions immediately in Keep the drier out of reach of children. case of the product producing smoke, or strange • Eating the drier may result in serious harm to health.
  • Page 4 FEC-150 Copyright FIRICH (C) Copyright CIRICH Co., Ltd. All rights reserved Partial or total duplication, reproduction or translation of the User Manual and product or convert to any electronic media or readable form without prior written permission is prohibited. The errors related to printing or technology in the User Manual and product are subject to change without prior notice.
  • Page 5 (10) USB COMMUNICATION (10) Rear FEC-150P/R FEC-150U FEC-150P/R,FEC-150U The printer is a banking peripheral device and can be used with ECR, POS etc. Its main features are shown as follows: 1. High speed printing; 2. Thermal printing with low noise;...

  • Page 6: Table Of Contents

    1-3 Operation Panel ············································································································8 2. Connection ·····················································································································9 2-1 AC Adapter Connection ·································································································9 2-2 Interface Connection ···································································································10 2-2-1 FEC-150R Serial Interface ···················································································· 11 2-2-2 FEC-150P Parallel Interface··················································································12 2-2-3 FEC-150U USB Interface ······················································································12 2-2-4 Cash Drawer Cable Connection (Option) ······························································13 3. DIP Switch Setting ·······································································································14 3-1 Setting the DIP Switches ·····························································································15...

  • Page 7: Installation And Basic Operations

    FEC-150 1. Installation and basic operations 1-1 Unpacking Make sure all following items are available. Please contact the distributor immediately in case of loss or damage. Paper User Manual Printer Cable interface Power cord USB, Serial, parallel cable 1-2 Installation Site Keep the product away from the high temperature or direct sunlight.

  • Page 8: Operation Panel

    FEC-150 1-3 Operation Panel The Panel consists of one button and two indicators. Button FEED To print one paper, press the FEED button. To continuously print, press and hold the FEED button. Indicator The indicator indicates the state of the printer.

  • Page 9: Connection

    FEC-150 2. Connection 2-1 AC Adapter Connection It is required to used the power cord and adapter accompanied with the printer. ※ Warning Improper power unit may cause a fire or hazard. ※ Note 1. Operate the product in the following orders for safety and durability after power on.

  • Page 10: Interface Connection

    FEC-150 2-2 Interface Connection USB, serial or parallel interface cable is required for connecting the printer to the computer. - Make sure the power of the printer and computer is switched on, then connect the cable interface to the printer.

  • Page 11: Fec-150R Serial Interface

    FEC-150 2-2-1 FEC-150R Serial Interface Printer Case Main --------------------- --------------------- --------------------- --------------------- --------------------- --------------------- --------------------- Shield --------------------- Shield 9PIN MALE 9 PIN FEMALE - 11 - Rev. 1.00...

  • Page 12: Fec-150P Parallel Interface

    FEC-150 2-2-2 FEC-150P Parallel Interface Printer Case Main ---------------- nStrobe nStrobe ---------------- Data 0 (LSB) Data 0 (LSB) ---------------- Data 1 Data 1 ---------------- Data 2 Data 2 ---------------- Data 3 Data 3 ---------------- Data 4 Data 4 ---------------- Data 5...

  • Page 13: Cash Drawer Cable Connection (Option)

    FEC-150 2-2-4 Cash Drawer Cable Connection (Option) Pin No. Description Direction Frame GND Drawer Kick-Out Driver Signal #1 Output Drawer Open / Close Signal Input +12V Drawer Kick-Out Driver Signal #2 Output Signal GND - 13 - Rev. 1.00...

  • Page 14: Dip Switch Setting

    FEC-150 3. DIP Switch Setting ※ Note It is required to turn off the printer when setting the DIP switch to prevent electrical rejection and damage to the printer. Replacement of the contact device or the printing density can be set on the DIP switch.

  • Page 15: Setting The Dip Switches

    FEC-150 Refer to the following settings of the DIP switch. 3-1 Setting the DIP Switches 3-1-1 Setting the DIP switch (RS-232C Serial Interface) • DIP Switch Function Default Auto Cutter Disable Enable Reserved Baud Rate Refer to Table 1 • Table 1 – Baud rate (bps) Selection...
  • Page 16 FEC-150 MSW2 Switch Function Reserved Fixed to OFF Auto Cutter Function Full Cutting Partial Cutting Code Page Selection Refer to following Table MSW2-8 MSW2-7 MSW2-6 MSW2-5 MSW2-4 MSW2-3 Character Table Page 0 437 (USA,standard Europe) Page 1 Katakana Page 2...
  • Page 17 FEC-150 MSW9 Switch Function Language Selection Korean/Chinese Reserved Fixed to OFF International Character Set Refer to following Table Selection MSW9-8 MSW9-7 MSW9-6 MSW9-5 International Character Set 0. USA 1. France 2. Germany 3. UK 4. Denmark 5. Sweden 6. Italy 7.

  • Page 18: Paper Loading

    FEC-150 4. Paper Loading Please use the standard paper. ※ Note It is important to power off the printer in the process of paper loading. 1. Open the paper cover and take out all used paper. 2. Load the paper in the proper direction as the following shown in case of paper jam.

  • Page 19: Sample Test

    FEC-150 5. Sample Test 1. Sample Printing Test * Sample Test Start-up After loading paper and close the cover and the PAPER FEED button pressed and held, the sample test will start upon power on. The self-test will conduct printing according to the existing setting of the following information available.

  • Page 20: Hexadecimal Dumping

    FEC-150 6. Hexadecimal Dumping This function is designed for advanced user to send and receive the data accurately and identify the software problems. The Hexadecimal Dumping function is helpful for searching special terms because all data and command statements are printed in hexadecimal form.

  • Page 21: Specification

    FEC-150 7. Specification Printing Method Thermal printing Resolution 203Dpi (8 dot/mm) Printing Width 48mm Paper Width 58.0±0.5mm Strings Per Line 32 (Font A) (12x24) About 19 lines/sec Printing Speed Max. 65 mm/sec at 25℃/printing duty 12.5% Thickness: 0.062 ~ 0.075mm Roller size: Ø80mm...

  • Page 22: Windows Driver Setting

    8. WINDOWS Driver Setting 8-1 Serial (RS-232C) Interface Model Windows Driver Setting 1. After executing the proudct setting CD, go to Thermal Printer > FEC-150 > Drivers > Windows Driver > Drivers folder > exectute FEC-150_WIN_Vx.x.xx.exe 2. Select “Next” from the window at the initial setting.

  • Page 23: Parallel (Ieee1284) Interface Windows Driver Setting

    FEC-150 8-2 Parallel (IEEE1284) Interface Windows Driver Setting 1. After executing the proudct setting CD, go to Thermal Printer > FEC-150 > Drivers > Windows Driver > Drivers folder > exectute FEC-150_WIN_Vx.x.xx.exe 2. Select “Next” from the window at the initial setting.

  • Page 24: Control Command List

    FEC-150 9. Control Command List Command Name Horizontal tab To print and Line Feed To print and Carriage Return DLE EOT To send the real time status ESC SP To set the right side space of the characters ESC !

  • Page 25: Summary Of Control Command

    FEC-150 10. Summary of Control Command [Name] Horizontal Tab [Type] ASCII Decimal [Description] Set the horizontal tab if you want to use the print position. [Name] To print and line feed [Type] ASCII DECIMAL 10 [Description] To print the data in the printer buffer and feed one line.
  • Page 26 FEC-150 n = 1: Printer Status Off/On DECIMAL Function Not used. Fixed to Off Not used. Fixed to On Not used On-line Off-line Not used. Fixed to On Not defined Not used. Fixed to Off n = 2: Off-line Status...
  • Page 27 FEC-150 ESC SP n [Name] To set the right side space of the characters [Type] ASCII DECIMAL [Range] 0 ≤ n ≤ 255 [Description] To set the right side space of the characters ESC ! n [Name] To set the printer mode...
  • Page 28 FEC-150 ESC % n [Name] To select/cancel user defined character set [Type] ASCII DECIMAL 27 [Range] 0 ≤ n ≤ 255 [Description] To select/cancel user-defined character set. User-defined character set is cancelled when LBS of n is 0, User-defined character set is selected when LBS of n is 1.
  • Page 29 FEC-150 ESC – n [Name] To set/clear underline mode [Type] ASCII DECIMAL 27 [Range] 0 ≤ n ≤ 2, 48 ≤ n ≤ 50 [Description] Underline mode is set or cleared depending on the value of n. Function 0,48 Underline mode is cleared 1,49 Underline mode is selected (Dot thickness –...
  • Page 30 FEC-150 ESC ? n [Name] To cancel the user defined character set [Type] ASCII DECIMAL 27 [Range] 32 ≤ n ≤126 [Description] To cancel the user-defined character sets. ESC @ [Name] To initialize the printer [Type] ASCII DECIMAL 27 [Description] This function purges the data in the buffer when the power is on or recovers the printer mode.
  • Page 31 FEC-150 ESC R n [Name] To select multilanguage character sets [Type] ASCII DECIMAL 27 [Range] 0 ≤ n ≤ 10 [Description] To select the multilanguage character set with n. Chinese version is not supported. Character set Character set U.S.A. Italy...
  • Page 32 FEC-150 ESC V n [Name] To set/clear 90° clockwise rotated character sets [Type] ASCII DECIMAL 27 [Range] 0 ≤ n ≤ 1, 48 ≤ n ≤ 49 [Description] To set/clear 90° clockwise rotated character sets depending on the value of...
  • Page 33 FEC-150 ESC t n [Name] To select the character code table [Type] ASCII DECIMAL 27 [Range] 0 ≤ n ≤ 5, n = 11, 255 [Description] n is used to select the character code table as follows. Chinese version is not supported.
  • Page 34 FEC-150 FS q n [xL xH yH d1 …dk]1…[xL xH yL yH d1…dk]n [Name] To define NV image [Type] ASCII n [xL xH yH d1 …dk]1…[xL xH yL yH d1…dk]n 1C 71 n [xL xH yH d1 …dk]1…[xL xH yL yH d1…dk]n DECIMAL 28 113 n [xL xH yH d1 …dk]1…[xL xH yL yH d1…dk]n...
  • Page 35 FEC-150 GS ( E pL pH fn [parameter] [Name] To Customize NV memory area [Description] Customize the NV user memory area. The table below explains the functions available in this command. Executes commands related to the user setting mode by specifying the function code fn.
  • Page 36 FEC-150 printer clears the receive and print buffers, and resets all settings (user- defined character, downloaded bit images, macros, and the print mode) to the mode that was in effect at power on. ▪ This function code (fn=2) is enabled only in the user setting mode.
  • Page 37 FEC-150 <Function 4> GS ( E pL pH fn a (fn=4) [Format] ASCII pL pH fn a 1D 28 45 pL pH fn a Decimal 40 69 pL pH fn a [Range] (pL + pH x 256) = 2 (pL=2, pH=0)
  • Page 38 [Range] 1 ≤ n ≤ 3 , 49 ≤ n ≤ 51 [Description] To send the printer ID using n as shown below Printer ID Specifications ID (HEXaDECIMAL) FEC-150P / FEC150U / 1,49 Printer Model ID FEC-150 2,50 Type ID...
  • Page 39 FEC-150 GS L nL nH [Name] To set the left margin [Type] ASCII DECIMAL 29 [Range] 0 ≤ nL ≤ 255 0 ≤ nH ≤ 255 [Description] Left margin is determined by nL and nH. Left margin is set to [(nL + nH X 256) X (horizontal motion unit6)] inches...
  • Page 40 FEC-150 GS ^ r t m [Name] To run the macro [Type] ASCII DECIMAL 29 [Range] 0 ≤ r ≤ 255 , 0 ≤ t ≤ 255 , 0 ≤ m ≤ 1 [Description] To run the macro - r: Repetition frequency of macro execution.
  • Page 41 FEC-150 ① GS k m d1...dk NUL ② GS k m n d1...dn [Name] To printer barcode [Type] ① ASCII d1...dk d1...dk DECIMAL d1...dk ② ASCII d1...dn d1...dn DECIMAL d1...dn [Range] ① 0 ≤ m ≤ 6 (Values for k and d are determined by the barcode system.) ②...
  • Page 42 FEC-150 Control character Control character character character ASCII DECIMAL ASCII DECIMAL ■U ■P ■A ■Q ■B ■R ■C ■S ■D ■T ■E ■U ■F ■V ■G ■W ■H ■X ■I ■Y ■J ■Z ■K ■A ■L ■B ■M ■C ■N ■D...
  • Page 43 FEC-150 The following characters can be represented by the CODE128 barcode. * SHIFT characters In the code set A, the character right next to the SHIFT follows the process of code set B. SHIFT character cannot be used in code set C.
  • Page 44 FEC-150 GS v 0 m xL xH yL yH dl…dk [Name] To print raster bit image [Type] ASCII dl…dk dl…dk DECIMAL 29 dl…dk [Range] 0 ≤ m ≤ 3 , 48 ≤ m ( 51 0 ≤ xL ≤ 255 , 0 ≤ xH ≤ 255 , 0 ≤ yL ≤ 255...
