- Page 1 Eternal Lighting CUBEecho RGBWA User Manual CUBEecho RGBWA Eternal Lighting February 2014...
- Page 2 Introduction: Thank you for your purchase. The CUBEecho RGBWA LED is a DMX intelligent LED par light. This LED par light is lightweight and compact which makes is ideal for Mobile Entertainers. Unpacking: Thank you for purchasing the CUBEecho RGBWA light fixture. Every CUBEecho RGBWA has been thoroughly tested and has been shipped in perfect operating condition.
- Page 3 The CUBEecho RGBWA will last up to 20 hours on a single full charge. It will depend on which LED colors How Long Does the Battery Last? and how many LED colors are being used at what intensity based on the (0-255) Scale. The (0-255) Scale you see on the push button display is directly related to the 0-255 scale you are using with a DMX controller or DMX software.
- Page 4 Battery Percentage Indicator Battery Capacity (90-100% is Fully Charged, 20-30% is Low to Depleted Battery) Note: Light will shut off around 20-30% left on Battery Capacity Full on LCD Display time 10s/11s/12s…60s IR INFA Enable/Disable CUBEecho RGBWA Eternal Lighting February 2014...
- Page 5 ID Code Selector colors, press the small clickable button next to the ID Code Selector. Choose a color, for example Blue (4), and do the same for all your CUBEecho RGBWA. Master/Slave- Have one fixture in Master Mode and the rest of the fixtures in Slave Mode. Turn on the Receiver button and put all fixtures on same ID Code Color.
- Page 6 The XT-Mitter PRO will start blinking RED (meaning transmitting signal) and all the Slave fixture(s) will start blinking GREEN (meaning receiving signal). You will have up to 300 feet, line of sight of communication with your XT-Mitter PRO and the CUBEecho RGBWA. Please reference the DMX chart below for information on the Channel Mode programs.
- Page 7 WHITE Color dimmer (0-255) 5CH Mode Value RGBWA 4*5in1 0-255 RED Color dimmer (0-255) 0-255 GREEN Color dimmer (0-255) 0-255 BLUE Color dimmer (0-255) 0-255 WHITE Color dimmer (0-255) 0-255 AMBER Color dimmer (0-255) CUBEecho RGBWA Eternal Lighting February 2014...
- Page 8 R, G, B,W, A STROBE from slow to fast (0-255) CH11 0-255 SOUND 1 (Off 0-15, ON 16-100 Color change, Fade and Strobe, ON 101-255 Color Change and Strobe, ON 101-255 Color Change For more information, please contact Support by email at support@eternallighting.com CUBEecho RGBWA Eternal Lighting February 2014...
