Summit Professional FF874 User Manual

Two-door frost-free
Hide thumbs Also See for FF874:
Table of Contents

Advertisement

Quick Links

Download this manual
TWO-DOOR FROST-FREE
REFRIGERATOR / FREEZER
Thank you for purchasing our SUMMIT
product. This easy-to-use manual will
guide you in getting the best use of your
refrigerator.
Please record the model and serial
numbers, which are found on a label
at the back of your appliance.
Staple your receipt to this manual. You will need it to obtain warranty service.
Models FF874
FF1074
FF1274
User's Manual
FELIX STORCH, INC.
770 Garrison Avenue
Bronx, New York 10474
www.summitappliance.com
_____________________________
Model number
_____________________________
Serial number
_____________________________
Date of purchase

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FF874 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Summit Professional FF874

Summary of Contents for Summit Professional FF874

  • Page 1 FELIX STORCH, INC. 770 Garrison Avenue Bronx, New York 10474 www.summitappliance.com TWO-DOOR FROST-FREE REFRIGERATOR / FREEZER Models FF874 FF1074 FF1274 User's Manual Thank you for purchasing our SUMMIT _____________________________ product. This easy-to-use manual will Model number guide you in getting the best use of your _____________________________ refrigerator.

  • Page 2: Important Safeguards

    IMPORTANT SAFEGUARDS This unit is not designed to operate in enclosed spaces. When placing your unit, make sure you allow adequate airflow on all sides. Read all of the instructions before using this appliance. When using this appliance, always exercise basic safety precautions, including the following: 1.
  • Page 3 10. This refrigerator should not be recessed or built into an enclosed cabinet. It is designed for freestanding installation only. 11. Do not operate your refrigerator in the presence of explosive fumes. DANGER! Risk of child entrapment! Before you throw away your old refrigerator or freezer, take off the doors.

  • Page 4: Table Of Contents

    Table of Contents Important Safeguards ..................1 Parts and Features ..................4 Installation ......................5 Unpacking Your Refrigerator ..............5 Adjusting Your Refrigerator ..............5 Proper Air Circulation ................5 Electrical Requirements ................5 Installation Limitations ................5 Door Alignment ..................6 Reversing the Door Swing ..............7 Refrigerator Features and Use ..............9 General Features ..................9 Refrigerator Interior Shelves ..............9 Crisper and Crisper Cover ..............10...

  • Page 5: Parts And Features

    Parts and Features 1. Ice cube tray 10. Freezer shelf 2. Full-width freezer door shelves 11. Gallon storage compartment 3. Door shelf 12. Can storage (not on all models) 4. Adjustable front leveling legs (not shown) 13. ½-width shelf storage compartment (not on all models) 5.

  • Page 6: Installation

    Installation Unpacking Your Refrigerator 1. Remove all packaging material. This includes the foam base and all adhesive tape holding the refrigerator accessories inside and out. Slide out and remove plastic or foam guard used to secure the compressor from shipping damage due to vibration and shock.

  • Page 7: Door Alignment

     Select a suitable location for the refrigerator on a hard, even surface away from direct sunlight or heat source, e.g., radiators, baseboard heaters, cooking appliances, etc. Any floor unevenness should be corrected with the leveling legs located on the front bottom corners of the refrigerator. Door Alignment Freezer Door: (see Fig.

  • Page 8: Reversing The Door Swing

    Reversing the Door Swing Left/right door opening method: This appliance allows you to reverse the door opening from left to right and back. You can select your preference of door opening by following the procedure to make the change. Dismantling: 1.
  • Page 9 Reinstallation: (See Figs. #4 and #5) 1. Remove the lower pivot pin from the bracket of the lower hinge by turning counter-clockwise. Move the pin to the opposite hole and tighten. 2. Loosen the screws holding the lower hinge bracket and remove the hinge. 3.

  • Page 10: Refrigerator Features And Use

    Refrigerator Features and Use General Features Adjustable temperature dial: Your refrigerator will automatically maintain the temperature level you select. The temperature control dial has seven (7) settings plus OFF. 1 is the warmest. 7 is the coldest. Turning the dial to OFF stops cooling in both the refrigeration and freezer sections.

  • Page 11: Crisper And Crisper Cover

    Crisper and Crisper Cover To remove and install the crisper: (See Fig. #7) 1. Grip the crisper firmly and slide out completely. 2. Replace the crisper by placing it properly in position and gently sliding it back into place. Removing or replacing the crisper cover: (See Fig. #8) 1.

  • Page 12: Food Storage Information

    Food Storage Information Fresh Food  When storing fresh food that is not prepackaged, be sure to wrap or store it in airtight and moisture-proof material unless otherwise noted. This will ensure proper shelf life and prevent the transfer of odors and tastes. ...

  • Page 13: Normal Operating Sounds

    Frozen Food  Proper freezer storage requires correct packaging. All foods must be in packages that do not allow the flow of air or moisture in or out. Improper storage will result in odor and taste transfer and will result in the drying out of the improperly packaged food.

  • Page 14: Proper Refrigerator Care And Cleaning

    Petroleum jelly applied lightly on the hinge side of gaskets will keep the gasket pliable and ensure a good seal. For refrigerator models FF874, FF1074 and FF1274, we recommend that you clean the rear of the refrigerator at least twice a year. Some operating environments may require more frequent cleaning.

  • Page 15: Light Bulb Replacement

    Light Bulb Replacement 1. Switch off power to refrigerator. 2. Remove the highest shelf. 3. Allow light bulb to cool before removing. 4. Pinch the plastic cover between fingers and thumb and gently pull to the left. 5. Remove the bulb by screwing it counter-clockwise. 6.

  • Page 16: Troubleshooting

    Troubleshooting Refrigerator does not operate  Check that thermostat control is not in the OFF position.  Check that refrigerator is plugged in.  Check if there is power at the AC outlet by inspecting the fuse or circuit breaker. Food temperature appears too warm ...

  • Page 17: Warranty Information

    Limited Warranty PARTS AND LABOR WARRANTY INFORMATION SUMMIT Appliances are manufactured to provide outstanding value, and your satisfaction is our goal on every product. All SUMMIT major appliances carry a one year limited warranty on both parts and labor. All refrigerators and freezers carry an additional four years on the compressor. Certain exclusions may apply.
  • Page 18  IMPROPER USE: Summit assumes no liability for parts or labor coverage for component failure or other damages resulting from improper usage or installation or failure to clean and/or maintain product as set forth in the warranty packet provided with the unit. ...
