- Page 1 DETAILED INSTRUCTIONS FOR USE OF UPRIGHT REFRIGERATOR AND FREEZER FFBF181ES FELIX STORCH, INC. Summit Appliance Division 770 Garrison Avenue Bronx, New York 10474 www.summitappliance.com...
- Page 2 We thank you for confidence you have shown by purchasing our appliance. We wish you much pleasure in its use. The appliance is intended solely for household use. Refrigerator freezer (hereinafter: the appliance) consists of two parts: the upper part is the refrigerator and the lower part is the freezer.
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION IMPORTANT NOTES AND WARNINGS ADVICE FOR SAVING POWER WITH REFRIGERATION APPLIANCES APPLIANCE APPLIANCE DESCRIPTION DESCRIPTION 10 INSTALLATION AND CONNECTION 12 CHANGING THE DIRECTION OF DOOR OPENING 14 OPERATING THE APPLIANCE 19 APPLIANCE INTERIOR EQUIPMENT 23 RECOMMENDED DISTRIBUTION OF FOOD IN THE APPLIANCE STORING AND 24 STORING FOOD IN THE REFRIGERATOR FREEZING FOOD... -
Page 4: Important Notes And Warnings
IMPORTANT NOTES AND WARNINGS This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or metal capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. - Page 5 Before connecting the appliance to the power mains, let the appliance rest in a vertical position for approximately 2 hours. This will reduce the possibility of operation faults due to the effect of transport on the cooling system. The appliance must be connected to the power line and grounded in compliance with the effective standards and regulations.
- Page 6 To protect the environment, take the obsolete appliance to an authorized home appliance collection center. Packaging is made of environmentally friendly materials that can be recycled, disposed of, or destroyed without any hazard to the environment. Rating plate can be found in the appliance interior. If the language on the rating plate is not the language of your choice or the language of your country, replace it with the one supplied.
- Page 7 The symbol on the product or its packaging indicates that the product should not be treated as normal household waste. The product should be taken to an authorized collection center for waste electric and electronic equipment processing. Correct disposal of the product will help prevent any negative effects on the environment and health of people which could occur in case of incorrect product removal.
-
Page 8: Advice For Saving Power With Refrigeration Appliances
ADVICE FOR SAVING POWER WITH REFRIGERATION APPLIANCES • Install the appliance as specifi ed in the instruction manual. • Do not open the door more often than necessary. • Occasionally make sure air circulation underneath the appliance is unobstructed. • Condenser unit on the rear wall should be kept clean (see chapter Cleaning the appliance). -
Page 9: Appliance Description
APPLIANCE DESCRIPTION A Refrigerator Control unit 2 Led lighting of refrigerator interior 3 IonAir air ionizer (+ on/off switch)* 4 Pull-out glass shelf (height adjustable) 5 Bottle rack 6 ZeroZone drawer 7 CrispZone fruit and vegetables drawer with humidity control 8 SimpleSlide heightadjustable door bin 9 Bottle bin... -
Page 10: Installation And Connection
INSTALLATION AND CONNECTION SELECTING THE ROOM • Do not install the refrigerator where temperatures will be below 55°F or above 110°F, because it will not maintain proper temperatures, and the refrigerator could develop high internal humidity. Warning: Make sure the room where the appliance is installed is large enough. There should be at least 1 m of space per 8 grams of refrigerant. - Page 11 • The appliance may stand alone or it may be placed next to a cupboard or a wall. For most effi cient operation, leave at least 4 of space on either side. Consider the clearance required to fully open the door in order to allow pulling out the drawers and shelves (see installation diagram).
-
Page 12: Changing The Direction Of Door Opening
CHANGING THE DIRECTION OF DOOR OPENING Tools required: socket wrench No. 8, Phillips screwdriver, torx 25, flat screwdriver The procedure to change the direction of door opening should be carried out by at least two persons. 1. Remove the upper hinge cover (A) and the cover from the connector (B1). 2. -
Page 14: Operating The Appliance
OPERATING THE APPLIANCE CONTROL PANEL A Appliance on key and refrigerator compartment off key B Acoustic alarm off key C Super cool on/off key D Refrigerator compartment temperature keys E Refrigerator temperature display F Freezer compartment on key and appliance off key G ECO function on/off key H Super freeze on/off key Freezer compartment temperature keys... - Page 15 SWITCHING THE APPLIANCE ON/OFF Switching the appliance on: Switch on the appliance by briefly pressing the key A. With this model, it is possible to only switch on the freezer compartment while the refrigerator compartment is switched off. This setting can be made in two ways: - briefly press the F key to switch on the freezer compartment only;...
- Page 16 • To set the temperature in the freezer compartment use the keys I: lower temperature ; higher temperature. • Temperature in the freezer compartment can be set from -6°F to +6°F. • After one of the I keys is pressed, the most recent temperature setting will fl...
- Page 17 • With this setting, the compressor will operate continuously and the temperature in the freezer compartment will drop considerably. • If the setting is not deactivated manually (by pressing the H key), it will be deactivated automatically after approximately one day. Freezer compartment temperature will return to the most recent setting.
- Page 18 ECO FUNCTION To activate the Eco function, press the G key. With this function activated, appliance will operate with optimum settings. SAFETY BLOCK (CHILD SAFETY LOCK) Use this function if you do not wish to manually adjust the appliance settings. To activate, press and hold the B key (for three seconds);...
-
Page 19: Appliance Interior Equipment
APPLIANCE INTERIOR EQUIPMENT (* Equipment depends on the model) SHELF • For clarity and easier access to food, the shelves can be partly pulled out. • The shelves may be adjusted to suit your preferences using the guides in the refrigerator interior. - Page 20 CRISPZONE – FRUIT AND VEGETABLE BIN WITH HUMIDITY CONTROL* • The bin at the bottom of the refrigerator is intended for storing fruit and vegetables. It provides humidity and prevents the food from drying out. • Store the foods in suitable packaging to prevent them from emitting or taking on odors. The bin has integrated humidity regulator which allows setting the humidity according to the amount of food stored.
- Page 21 INTERIOR SIDE OF THE REFRIGERATOR DOOR Mounted on the refrigerator door are compartments (shelves or bins) intended for storing cheese, butter, eggs, yoghurt and other smaller packages, tubes, cans, etc. There is a bottle shelf at the lower end of the door. ADJUSTABLE DOOR BINS The height of the door bins can be adjusted without having to remove the bins from...
- Page 22 IONIZER (IONAIR) (certain models only) • Air ionizer placed in the refrigerator compartment removes most bacteria, viruses, gases, and unpleasant odors to make sure the air in the refrigerator is always fresh. The food will remain fresh and tasty longer. Ionizer switched on Ionizer switched off ADAPTIVE INTELLIGENT TECHNOLOGY...
-
Page 23: Recommended Distribution Of Food In The Appliance
RECOMMENDED DISTRIBUTION OF FOOD IN THE APPLIANCE Sections of the refrigerator: - upper part: canned food, bread, wine, pastry etc. - middle part: dairy products, ready-made meals, desserts, soft drinks, beer, cooked food, etc. - ZeroZone drawer: - meat, meat produce, delicatessen - CrispZone drawer: fresh fruit, vegetables, salads, root vegetables, potatoes, onions, garlic, tomatoes, tropical fruit, sauerkraut, turnips etc. -
Page 24: Storing Food In The Refrigerator
STORING FOOD IN THE REFRIGERATOR IMPORTANT WARNINGS REGARDING FOOD STORAGE Correct use of the appliance, appropriate packaging, maintaining the right temperature, and observing the food hygiene standards has a decisive impact on the quality of food storage. Observe the expiry dates for the food, specified on the packaging. -
Page 25: Storing Food In The Zerozone Drawer
STORING FOOD IN THE ZEROZONE DRAWER The ZeroZone compartment allows storing a wide variety of fresh food for up to three times longer than in a conventional refrigerator. The food stays fresh longer, retaining the flavour and nutrients. The temperature in this drawer depends on the temperature settings in the refrigerator compartment, environment temperature, frequency of door opening, and amount of food placed in it. - Page 26 APPROXIMATE STORAGE TIME IN THE ZEROZONE DRAWER* Type of food Time sausages, cold cuts, beef, pork, venison, raw meat up to 7 days Poultry up to 5 days fish up to 4 days seafood up to 3 days Vegetables: cabbage, garlic, carrots up to 180 days celery, herbs up to 30 days...
-
Page 27: Freezing And Storing Frozen Food
FREEZING AND STORING FROZEN FOOD FREEZING PROCESS Maximum amount of fresh food that may be inserted at once is specified on the appliance rating plate. If the amount of food to be frozen exceeds the indicated amount, the quality of freezing will be inferior;... -
Page 28: Important Warnings On Freezing Fresh Food
IMPORTANT WARNINGS ON FREEZING FRESH FOOD Only freeze the food that is suitable for freezing in the freezer. Make sure the food you freeze is of high quality and fresh. Choose appropriate packaging and use the packaging correctly. Packaging should not be permeable to humidity; it should be airtight to prevent the food from drying out and losing vitamins. -
Page 29: Frozen Food Storage Time
FROZEN FOOD STORAGE TIME RECOMMENDED STORAGE TIME IN THE FREEZER Type of food Time fruit, beef from 10 to 12 months vegetables, veal, poultry from 8 to 10 months Venison from 6 to 8 months Pork from 4 to 6 months ground meat 4 months bread, pastry, ready-to-eat meals... -
Page 30: Defrosting The Appliance
DEFROSTING THE APPLIANCE AUTOMATIC REFRIGERATOR DEFROSTING Refrigerator does not need defrosting because the ice on the back interior wall is thawed automatically. Any accumulated ice will melt when the compressor unit is inactive. Drops will flow through an opening in the refrigerator rear wall into a tray fitted above the compressor, from where they will evaporate. -
Page 31: Cleaning The Appliance
CLEANING THE APPLIANCE Before cleaning, unplug the appliance from the power source – switch off the appliance (see chapter Switching the Appliance On/Off) and unplug the power cord from the wall outlet. • Use a soft cloth to clean all surfaces. Cleaners that contain abrasive substances, acids, or solvents are not suitable for cleaning as they may damage the surface. -
Page 32: Troubleshooting
TROUBLESHOOTING Problem: Cause or remedy: Appliance is connected to • Make sure there is voltage in the power outlet and that the power but it does not the appliance is switched on. work. • Too high environment temperature. Cooling system operates •... - Page 33 Problem: Cause or remedy: • If you are trying to open the freezer door after just Door is difficult to open: having closed it, this could be difficult to do. As you open the door, some cool air escapes from the appliance and it is replaced by warm air from the environment.
-
Page 34: Information About Appliance Noise
INFORMATION ABOUT APPLIANCE NOISE Cooling in refrigerator freezers is made possible by a cooling system that also includes a compressor (and a fan with some appliances), which generates some noise. The level of noise depends on installation, proper use, and age of the appliance. •... -
Page 35: Limited Warranty
LIMITED WARRANTY ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts and repair labor to correct defects in materials or workmanship. Service must be provided by a designated service company. - Page 36 COMBI_FS600_SUPERIOR en (09-16)
