REFRIGERATOR-FREEZERS
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.
Write Model and Serial Nos. (on lower left
corner of inside cabinet) here:
Model No.: _______________________
Serial No.: _______________________
FROST-FREE
FFRF3070B / FFRF3075W
Models
INSTRUCTION MANUAL
Felix Storch, Inc.
770 Garrison Avenue
Bronx, NY 10474
www.summitappliance.com
Advertisement
Table of Contents
Related Manuals for Summit Professional FFRF3070B
Summary of Contents for Summit Professional FFRF3070B
- Page 1 FROST-FREE REFRIGERATOR-FREEZERS FFRF3070B / FFRF3075W Models INSTRUCTION MANUAL BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS. Write Model and Serial Nos. (on lower left Felix Storch, Inc. corner of inside cabinet) here: 770 Garrison Avenue Model No.: _______________________ Bronx, NY 10474 www.summitappliance.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Appliance Safety Important Safeguards Location of Parts Installation Instructions Before Using Your Appliance Installation of Your Appliance Electrical Connection Extension Cord Installing the Stainless Steel Handles Operating Your Appliance 7-10 Control Panel Sabbath Mode Temperature Memory Function Defrosting Using the Freezer Temperature Alarm / Door Alarm... -
Page 3: Appliance Safety
APPLIANCE SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the Safety Alert Symbol. The symbol alerts you to potential hazards that can kill or injure you and others. - Page 4 In the event of any damage: - Avoid open flames and anything that creates a spark, - Disconnect from the power supply, - Air the room in which the appliance is located for several minutes, and - Contact the Service Department for advice. •...
-
Page 5: Location Of Parts
LOCATION OF PARTS LED Light Digital Control Panel Handle LED Light Left Zone Right Zone (Freezer) (Refrigerator) Wire Shelves (3) Glass Shelves (3) Door Security Lock Ventilation Grille Adjustable Legs... -
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS BEFORE USING YOUR APPLIANCE • Remove the exterior and interior packing. • CAUTION: After unpacking you MUST allow this appliance to stand upright for at least 2 hours to allow the lubricant and refrigerant to drain back into the compressor and stabilize. Failure to do so may adversely affect performance and the lifetime of the unit. -
Page 7: Extension Cord
The appliance should always be plugged into its own individual electrical outlet which has a voltage rating that matches the rating label on the appliance. This provides the best performance and also prevents overloading house wiring circuits that could cause a fire hazard from overheating. Never unplug the appliance by pulling on the power cord. - Page 8 SuperFreeze SuperFreeze is used to freeze fresh food quickly. The function overrides the thermostat control and will make the compressor operate continuously. It is not necessary to adjust the thermostat setting when using this function. When the function is selected, the SuperFreeze indicator will be ON.
-
Page 9: Sabbath Mode
SABBATH MODE Sabbath Mode is available for the observance of certain religious holidays. This mode turns off the displays, interior light and audible alarms and prevents them from turning on again. Normal cooling operations will still take place. To initiate Sabbath Mode, press the POWER and SuperFreeze keys at the same time for at least 5 seconds. -
Page 10: Door Lock
DOOR LOCK Your unit is provided with a lock and key combination. The keys are located inside the plastic bag that contains the Instruction Manual. Insert the key into the lock and turn it counter-clockwise to unlock the door. To lock the door, do the reverse operation, making sure the metal pin is engaged completely. -
Page 11: Care And Maintenance
CARE AND MAINTENANCE CLEANING YOUR APPLIANCE • Turn off the power, unplug the appliance, and remove all items, including shelves. • Wash the inside surfaces with a solution of warm water and baking soda (about 2 tablespoons of baking soda to a quart of water). •... -
Page 12: Troubleshooting
TROUBLESHOOTING You can solve many common problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the servicer. Troubleshooting Guide PROBLEM POSSIBLE CAUSE REMEDY • Appliance is not connected to a power •... - Page 13 • “E0”indicates a communication error for • Call for service. 3-zone models. • “E1” or “E2” indicates that the air Display “E0”, temperature sensor has failed. “E1”. “E2”, • “E3” or “E4”indicates that the defrost “E3”, “E4”, “E5” or “E7”. sensor in the evaporator has failed.
- Page 14 NOTES...
- Page 15 NOTES...
-
Page 16: Limited Warranty
LIMITED WARRANTY ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts and repair labor to correct defects in materials or workmanship. Service must be provided by a designated service company.
