OUTDOOR/FROST-FREE REFRIGERATOR
and FROST-FREE FREEZER
Model Nos. FF1538B / SPR315OS / SPR626OS
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.
Write Serial No. (on lower left corner of
inside cabinet) here:
________________________________
SCFF1537B / SCFF51OS / SCF51OSWH
INSTRUCTION MANUAL
Felix Storch, Inc.
770 Garrison Avenue
Bronx, NY 10474
www.summitappliance.com
Advertisement
Table of Contents
Related Manuals for Summit Professional FF1538B
Summary of Contents for Summit Professional FF1538B
- Page 1 OUTDOOR/FROST-FREE REFRIGERATOR and FROST-FREE FREEZER Model Nos. FF1538B / SPR315OS / SPR626OS SCFF1537B / SCFF51OS / SCF51OSWH INSTRUCTION MANUAL BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS. Felix Storch, Inc. Write Serial No. (on lower left corner of...
-
Page 2: Table Of Contents
Installation of Your Appliance Electrical Connection Extension Cord Reversing the Door Swing of Your Appliance Installing the Stainless Steel Handle Operating Your Appliance 9-12 Control Panel for FF1538B/SPR315OS/SPR626OS 9-10 Control Panel for SCFF1537B/SCFF51OS/SCFF51OSWH 10-11 Sabbath Mode Temperature Memory Function Defrosting... -
Page 3: Appliance Safety
APPLIANCE SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the Safety Alert Symbol. The symbol alerts you to potential hazards that can kill or injure you and others. - Page 4 FOLLOW WARNING CALLOUTS BELOW ONLY WHEN APPLICABLE TO YOUR MODEL • Use two or more people to move and install appliance. Failure to do so can result in back or other injury. • To ensure proper ventilation for your appliance, the front of the unit must be completely unobstructed. Choose a well-ventilated area with temperatures above 44°F (7°C) and below 90°F (32°C).
-
Page 5: Location Of Parts
LOCATION OF PARTS MODEL SPR626OS – OUTDOOR REFRIGERATOR Digital Control Panel Stainless Steel Door LED Light Stainless Steel Handle Shelves (3) Bottom Grille Security Lock Adjustable Legs MODEL SCFF51OS/SCFF51OSWH – FROST-FREE FREEZER LED Light Door Handle Shelves (3) Bottom Grille Security Lock Adjustable Legs Digital Control Panel... - Page 6 MODEL SPR315OS – OUTDOOR REFRIGERATOR MODEL FF1538B – FROST-FREE REFRIGERATOR MODEL SCFF1537B – FROST-FREE FREEZER LED Light Door Handle Shelves (3) Bottom Grille Security Lock Adjustable Legs Digital Control Panel...
-
Page 7: Installation Instructions
INSTALLATION OF YOUR APPLIANCE • The appliance is designed for built-in or recessed or free standing installation for indoor use for models FF1538B, SCFF1537B & SCFF51OSWH and outdoor use for SPR315OS, SPR626OS & SCFF51OS. • CAUTION This appliance is not designed for the storage of medicine or other medical products. -
Page 8: Extension Cord
The appliance should always be plugged into its own individual electrical outlet which has a voltage rating that matches the rating label on the appliance. This provides the best performance and also prevents overloading house wiring circuits that could cause a fire hazard from overheating. Never unplug the appliance by pulling on the power cord. -
Page 9: Installing The Stainless Steel Handle
For example, placing your unit in extreme cold or hot conditions may cause interior temperatures to fluctuate. The operating temperature range may not be reached. CONTROL PANEL for FF1538B/SPR315OS/SPR626OS ON/OFF Power To turn the appliance ON or OFF, touch the symbol and hold for 5 seconds. -
Page 10: Control Panel For Scff1537B/Scff51Os/Scff51Oswh
ºF/ºC Selector Select the temperature display in Fahrenheit or Celsius degrees. To change the temperature from Fahrenheit to Celsius or from Celsius to Fahrenheit, press and hold the LIGHT key for 5 seconds. Setting the Temperature Control • You can set the temperature by touching the UP and DOWN symbols. When you push either of the two buttons for the first time, the LED readout will show the original temperature set previously. -
Page 11: Sabbath Mode
To initiate Sabbath mode, press the POWER and LIGHT keys at the same time for at least 5 seconds for FF1538B/SPR315OS/SPR626OS or press the POWER and SUPERFREEZE keys at the same time for at least 5 seconds for SCFF1537B/SCFF51OS/SCFF51OSWH. The indicator light will flash four times and confirm the Sabbath mode is ON. -
Page 12: Using The Freezer
• The evaporator behind the rear wall of the unit defrosts automatically. The condensate collects in the drainage channel behind the rear wall of the unit, and flows through the drainage hole into the drip tray by the compressor where it evaporates. •... -
Page 13: Care And Maintenance
CARE AND MAINTENANCE CLEANING YOUR APPLIANCE • Turn off the power, unplug the appliance, and remove all items, including shelves. • Wash the inside surfaces with a solution of warm water and baking soda (about 2 tablespoons of baking soda to a quart of water). •... -
Page 14: Troubleshooting
TROUBLESHOOTING You can solve many common problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the servicer. Troubleshooting Guide PROBLEM POSSIBLE CAUSE REMEDY • Appliance is not connected to a power •... - Page 15 • A large amount of bottles have been been reached. added to the unit. • The display temperature is out of range. • Only temperatures within the range 0~99°F/-9~37°C for FF1538B / The icon “--” is SPR315OS / SPR625OS and the lit and flashing range -49~99°F/-45~37°C for...
-
Page 16: Limited Warranty
LIMITED WARRANTY ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts and repair labor to correct defects in materials or workmanship. Service must be provided by a designated service company.
