R7008SB CH Mode

The R7008SB receiver is a very versatile unit.
It has 8 PWM outputs, S.Bus and S.Bus2 outputs.
Additionally the PWM outputs can be changed
from channels 1-8 to channels 9-16. If you only
desire to use it as an 8 channel receiver (without
S.Bus), it can be used without any setting changes.
The T18MZ has the ability to link to two
R7008SB receivers. One of them outputting
channels 1-8 and the other outputting channels
9-16 giving you 16 PWM channels. Instructions
for this configuration and S.Bus operation follow.
Receiver connector
1
2
3
4
5
6
7/B
8/SB
Red LED blink
26 <Before Use>
R7008SB CH MODE TABLE
Setting channel
Mode A Mode B
1 ～ 8CH 1 ～ 7CH
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 S.BUS
1time 2time
[How to change the R7008SB Channel mode.]
1. Press and hold down the Link/Mode button
on the R7008SB receiver.
2. Turn the receiver on while holding down the
Link/Mode button. when the LED begins to
blink green/red the button may be released.
3. The LED should now be blinking red in one of
the patterns described by the chart below.
4 . E a c h p r e s s o f t h e M o d e / L i n k b u t t o n
advances the receiver to the next mode.
5. When you reach the mode that you wish to
operate in, press and hold the Mode/Link
button for more than 2 seconds.
6. Once locked into the correct mode the LED
will change to a solid color.
7. Please cycle the receiver(s) power off and
back on again after changing the Channel
Mode.
Mode C
9 ～ 16CH
9
10
11
12
13
14
15
16
3time
Mode D
9 ～ 15CH
9
10
11
12
13
14
15
S.BUS
4time
