SamplexPower SA-150-112 User Manual

Sa-150, sa-300 series pure sine wave inverter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SA-150, SA-300 Series
Pure Sine Wave Inverter
User's Manual

Advertisement

Table of Contents
loading

Related Manuals for SamplexPower SA-150-112

Summary of Contents for SamplexPower SA-150-112

  • Page 1 SA-150, SA-300 Series Pure Sine Wave Inverter User’s Manual...

  • Page 2: Table Of Contents

    List of contents 1. IMPORTANT safety Information…………………………………………... General Safety Precautions………………………………………….. Battery Precautions…………………………………………………… 2. Features………………………………………………………………………. Electrical Performance 150W……………………………………….. Electrical Performance 300W……………………………………….. Mechanical Drawing 150W………………………………………….. Mechanical Drawing 300W………………………………………….. 3. Instructions………………………………………………………………….. Front Panel Operation……………………………………………….. Rear Panel Operation………………………………………………... AC Safety Grounding………………………………………………… Installation…………………………………………………………….. DC Input (Outlet sockets available)………………………………… AC Output (Outlet sockets available)……………………………….

  • Page 3: Important Safety Information

    1. Important Safety Information WARNING! Before installing and using the Inverter, you need to read following safety information carefully. 1-1. General Safety Precautions 1-1-1. Do not expose the Inverter to water, mist, snow, or dust. To reduce the risk of hazard, do not cover or obstruct the ventilation shaft. Do not install the Inverter in a zero-clearance compartment.

  • Page 4: Features

    2. Features 2-1. Electrical Performance 150W Model No. Specification Item SA-150-112 SA-150-124 Continuous Output Power 150W Surge Rating 200W Input voltage Input voltage Range 10.5 – 15.0 21.0 – 30.0 ±5% 110VAC Output Voltage ±0.3% Frequency 50 / 60Hz Max. Efficiency No Load Current Draw <0.3A...

  • Page 5: Electrical Performance 300W

    2-2. Electrical Performance 300W Model No. Specification Item SA-300-112 SA-300-124 Continuous Output Power 300W Surge Rating 400W Input voltage Input voltage Range 10.5 – 15.0 21.0 – 30.0 ±5% Output Voltage 110VAC ±0.3% Frequency 50 / 60Hz Max. Efficiency No Load Current Draw <0.35A Output Waveform Pure Sine Wave ( THD 6.0% Typical )

  • Page 6: Mechanical Drawing 150W

    2-3. Mechanical Drawing...

  • Page 7: Mechanical Drawing 300W

    2-4. Mechanical Drawing...

  • Page 8: Instructions

    3. Instructions SA-150 and SA-300 series are very reliable, portable, and fully protected. These pure sine inverters are used in a wide range of applications such as mobiles, office equipments, home entertainment, electronic appliances, etc. To get the most effective power inverter, it must be installed and used properly. Please read the instructions of this manual before you install and operate this model.

  • Page 9: Ac Safety Grounding

    WARNING！ Do not combine the 12V model with 24V battery or the unit will be destroyed immediately. Operate with the inverter without a proper ground connection may cause an electrical safety hazard. Damage caused by reversed polarity is not covered by the warranty.

  • Page 10: Installation

    3-4. Installation Before connecting your applications to the inverter, always check the power draw of your appliances. The inverter can supply surge power for a short time so as to start up the electrical equipment such as motors, pumps… that need more power while starting up.

  • Page 11: Dc Input (Outlet Sockets Available)

    3-5. DC Input (Outlet sockets available)： CIGARETTE CLAMP POWER CLAW STRIPPED WIRE PP45 3-6. AC output (Outlet Sockets available)： North America (GFCI) NEMA 5-20R Continental European NEMA 5-15R Australia / New Zealand United Kingdom Universal IEC-1 HARD WIRE IEC-2...

  • Page 12: On / Off / Remote Main Switch

    3-7. ON / OFF / REMOTE Main Switch. 3-7-1. Before installing the inverter, make sure the main switch must be “OFF”. 3-7-2. Before using the remote unit, make sure the main switch must be “ REMOTE”. 3-7-3. Ensure the remote control contact is off. 3-7-4.

  • Page 13: Troubleshooting

    4. Troubleshooting WARNING！ Do not open or disassemble the Inverter. Attempting to service the unit yourself may cause the risk of electrical shock or fire. Problems and Symptoms Possible Cause Solutions No output voltage, the LED glows Red light. a. Power status light is Over input voltage.

  • Page 14: Maintenance

    5. Maintenance Very little maintenance is required to keep your inverter operating properly. You should clean the exterior of the unit periodically with a damp cloth to pre vent accumulation of dust and dirt. At the same time, tighten the screws on the DC input terminals.
  • Page 15 Samlex America Inc. 110-17 Fawcett Road, Coquitlam, BC, V3K 6V2 Canada Toll free phone: 1-800-561-5885 Toll free fax: 1-888-814-5210 General Inquiries: samlex@samlexamerica.com WWW: http://www.samlexamerica.com 034_2009_SA-150_SA-300_Manual_Dec2009...

This manual is also suitable for:

Sa-150-124
