Summary of Contents for SamplexPower SSW-350-12A

  • Page 1 Pure Sine Wave owner's Please read this manual before Power Inverter Manual installing your SSW-350-12A inverter SSW-600-12A SSW-1000-12A SSW-1500-12A SSW-2000-12A...
  • Page 2: Table Of Contents

    Owner's Manual | Index SectIon 1 Important Safety Instructions ..........3 SectIon 2 Design Features and Principle of Operation ......5 SectIon 3 Layout and Dimensions ............7 SectIon 4 Installation ................ 10 SectIon 5 Operation ................ 15 SectIon 6 Protections .................
  • Page 3: Important Safety Instructions

    These areas may include spaces containing gasoline-powered machinery, fuel tanks, battery compartments and engine compartments. 3. In SSW-350-12A and SSW-600-12A, the Neutral terminal of the two NeMA5-12r outlets is electrically isolated from its Ground terminal and also from the metal chassis of the inverter.
  • Page 4 4. This inverter will not operate high wattage appliances that exceed the output power limit or the surge power limit. 5. Grounding the Neutral terminal of the AC outlet in SSW-350-12A and SSW-600-12A will shut down the inverter. Similarly, grounding the Neutral terminal of the GfCI outlet in SSW-1000, 1500 & 2000 will trip the GfCI.
  • Page 5: Design Features And Principle Of Operation

    • Low Idle current • Soft Start Technology • LCD remote Control Model SSW-r1-12b (SSW-1000-12A, SSW-1500-12A and SSW-2000-12A only) • USb Charging Port, 5V, 500mA (SSW-350-12A and SSW-600-12A only) 2.3 PoWeR RAtInGS The continuous power ratings of the models are as follows: • SSW-350-12A...
  • Page 6 Section 2 | Design Features and Principle of operation 2.5 tHe oUtPUt WAVeFoRM The AC output waveform of the SSW-series inverter is known as “Pure Sine Wave” or “True Sine Wave”. It is a waveform that has characteristics same as the sine wave shape of utility power (See fig 2.1). Modified Sine Wave is also shown for comparison.
  • Page 7: Layout And Dimensions

    Wire sizes: (i) AWG #12 for SSW-350-12A and (ii) AWG #8 for SSW-600-12A 10(b). flat, rectangular terminal lugs on the cable set 10(a) for connection to DC input terminals on the inverter earth Ground symbol.
  • Page 8 Section 3 | Layout and Dimensions 3.1.2 SSW-1000-12A, SSW-1500-12A and SSW-2000-12A 1(a) 1(b) 9(a) 9(a) 9(b) Fig 3.2.1 Front of the unit Fig 3.2.2 Back of the unit Legend for Fig 3.2.1 and 3.2.2 1(a). AC outlets: NeMA5-20r Duplex GfCI receptacles 1(b).
  • Page 9 155 x 225 x 59 155 x 255 x 59 • NOT TO SCALE • NOT TO SCALE • DIMENSIONS ARE IN MM • DIMENSIONS ARE IN MM Fig. 3.3 Dimensions: SSW-350-12A Fig. 4 Dimensions: SSW-600-12A SSW-1000-12A SSW-1500-12A & SSW-2000-12A HEIGHT: 89 HEIGHT: 89...
  • Page 10: Installation

    Section 4 | installation warnInG! 1. before commencing installation, please read the safety instructions explained in Section 1 titled “Important Safety Instructions”. 2. It is recommended that the installation should be undertaken by a qualified, licensed / certified electrician. 3. Various recommendations made in this manual on installation will be superseded by the National / Local electrical Codes related to the location of the unit and the specific application.
  • Page 11 Section 4 | installation 4.2 MoUntInG Please refer to figs 3.3 to 3.6 for dimensions and mounting details. The inverter has four mounting slots that allow the unit to be fastened against a bulkhead, floor, wall or other flat surface. Ideally, the mounting surface should be cool to the touch. It is more electrically efficient to use longer Ac wiring than Dc wiring, so install the inverter as close as possible to the 12 VDc power source.
  • Page 12 Section 4 | installation for normal operation of the inverter, the DC power source must provide >11.0 ± 0.3V and < 15.3 ± 0.3V and the required current. This DC power source must be a well-regulated DC power supply or alternator and deep cycle battery system typically found in vehicles and marine crafts.
  • Page 13: Dc Input Terminals

    4.6 cABLe teRMInAtIon FoR Dc InPUt connectoRS SSW-350-12A and SSW-600-12A SSW-350-12A: The inverter side of the DC input cable has to be terminated with a customized, flat rectangular Terminal Lug (10b, fig 3.1.2). The terminal lug fits in the rectangular slot in the DC input terminal (7, 8 in fig 3.1.2) and is tightened using M4 Thumb Screw.
  • Page 14 2 sets of 3 ft, 105°C rated battery cables have been provided (10a in fig 3.1.2): For SSW-350-12A: AWG# 12 cable with flat rectangular Terminal Lug (10b in fig 3.1.2) for inverter side and battery Clamps for battery side For SSW-600-12A: AWG# 8 cable with flat rectangular Terminal Lug (10b in fig 3.1.2) for inverter...
  • Page 15: Operation

    (ii) continuous running of the cooling fan(s) at slow speed. 4.10 USB cHARGInG PoRt Models SSW-350-12A and SSW-600-12A are provided with USb Charging Port (3, fig 3.1.1). This port can be used for charging batteries in USb compatible personal devices like cell phones, etc. The port is rated at 5V, 500mA.
  • Page 16: Section 6

    Section 5 | operation warnInG! Do not connect directly to AC distribution wiring. This inverter is NoT grid interactive. 5.3 oPeRAtInG enVIRonMent for best operating results, the inverter should be placed on flat surface, such as the ground, car floor, or other solid surface.
  • Page 17: Determining Battery Size

    Section 5 | operation Table 5.1 lists some common loads that require high surge power on start up. A “Sizing factor” has been recommended against each which is a Multiplication factor to be applied to the rated running Watt rating of the load to arrive at the continuous power rating of the inverter (Multiply the running Watts of the device / appliance by the Sizing factor).
  • Page 18: Protections

    Section 5 | operation To get an estimate of the current (in Amps) that the battery is delivering to power a particular AC side load, divide the load's AC consumption power (in Watts) by (10). Keep in mind that most appliances are not operating for long periods of time. for example, a typical home-use coffee maker draws 500 Watts during its brew time of 5 minutes, but it maintains the temperature of the pot at about 100 Watts.
  • Page 19: Section 7

    Section 6 | Protections 6.4 oVeRLoAD PRotectIon The inverter will automatically shut down when the continuous draw exceeds rated Watts. It will be latched in shut down condition and will require manual reset by switching off the oN/off Switch (2, figs 3.1.1 and 3.2.1), waiting for 3 minutes and switching oN again (internal latching circuit does not de-energize immediately after Switching off).
  • Page 20: Troubleshooting Guide

    • Yellow LED on the front panel is OFF and will require a manual reset at the inverter 2. In Models SSW-350-12A and SSW-600-12A, • There is no buzzer alarm by switching off and then switching oN. this shut down could also be due to ground Switch off the inverter.
  • Page 21 Section 7 | troubleshooting Guide tRoUBLe / SYMPtoMS PoSSIBLe cAUSe(S) SUGGeSteD ReMeDIeS Ac oUtPUt IS AVAILABLe Intermittent buzzer alarm due to 1. Use thicker wires between the battery and intermittent high Ac loads the inverter and tighten all DC input circuit On the Inverter connections 1.
  • Page 22: Fuse Replacement

    Section 7 | troubleshooting Guide tRoUBLe / SYMPtoMS PoSSIBLe cAUSe(S) SUGGeSteD ReMeDIeS no Ac oUtPUt Shutdown due to high Dc input voltage 1. Switch off the AC load and the inverter. DC input voltage has risen to High DC Input 2.
  • Page 23: Specifications

    Section 9 | SPeciFicAtionS Model No. SSW-350-12A SSW-600-12A SSW-1000-12A SSW-1500-12A SSW-2000-12A dC INPUT VolTAGe RANGe 10.5 - 15.3 VDC (± 0.3 VDC) dC INPUT CURReNT 100A 150A 200A INPUT AT RATed loAd dC INPUT CURReNT < 0.5A < 0.7A < 0.9A <...
  • Page 24: Warranty

    WARRAntY 2 YeAR LIMIteD WARRAntY SSW-350-12A, SSW-600-12A, SSW-1000-12A, SSW-1500-12A AND SSW-2000-12A are manufactured by Samlex America, Inc. (the “Warrantor“) are warranted to be free from defects in workmanship and materials under normal use and service. The warranty period is 2 years for the United States and Canada, and is in effect from the date of purchase by the user (the “Purchaser“).
  • Page 25 nOtes:...
  • Page 26 Contact Information Toll Free Numbers Ph: 1 800 561 5885 Fax: 1 888 814 5210 Local Numbers Ph: 604 525 3836 Fax: 604 525 5221 Website www.samlexamerica.com USA Shipping Warehouses Kent, WA Plymouth, MI Canadian Shipping Warehouse Delta BC Email purchase orders to orders@samlexamerica.com 11002-SSW-350-600-1000-1500-2000-12A-0117-EN...
