Allnet Powerline 802.11g Wireless Access Point User Manual page 2

Configuration your ALL1686 Powerline 802.11g Wireless Access Point
1. Hardware Installation：
Plug the ALL1686 Powerline 802.11g Wireless Access Point into an outlet
2. Connecting a Wireless Device to the Access Point：
Set the wireless device TCP/IP network environment: (for example:)
- IP address: 10.0.0.10
- Subnet Mask: 255.255.255.0.
- SSID: default
- Channel: 11
- WEP: Off
3. set up ALL1686
- open the web browser and type
- enter user name: admin
- enter password: admin
- click LAN Tab
- set up the IP Address within your subnet (for example: 192.168.1.2)
- set up the Subnet Mask to fit you subnet (for example: 255.255.255.0)
- set up the Gateway (Note: usually same as your router's IP)
http://10.0.0.3/
2
