  • Page 1 ALL0558N Wireless N 300Mbit AP-IP55 802.11a/n User´s Manual...

  • Page 2: Table Of Contents

    1.6 U ALL0558N LED NDERSTANDING THE ........................9 2 INSTALLATION ................................10 THIS CHAPTER DESCRIBES HOW TO INSTALL THE ALL0558N................10 2.1 P INSTALLATION UIDELINES ............................ 10 SELECT THE OPTIMAL LOCATIONS FOR THE EQUIPMENT USING THE FOLLOWING GUIDELINES: ....10 2.2 I...
  • Page 3 ALL0558N User’s Manual 7 WIRELESS CONFIGURATION ............................30 7.1 W IRELESS ETTINGS ..............................30 7.1.1 Access Point Mode ............................30 7.1.2 Client Bridge Mode ............................33 7.1.3 WDS Bridge Mode ............................35 7.1.4 Client Router Mode ............................37 ....................................37 7.2 W...
  • Page 4 ALL0558N User’s Manual 10.6 T ETTINGS ................................71 10.7 L ..................................72 10.8 D IAGNOSTICS ................................73 11 NETWORK CONFIGURATION EXAMPLES ....................... 74 11.1 A CCESS OINT ................................74 11.2 C LIENT RIDGE ............................... 75 11.3 WDS B RIDGE ..............................76 11.4 C...

  • Page 5: About This Document

    ALL0558N User’s Manual About This Document This document is written by ALLNET Inc. ALLNET Inc. the reserves the right to change this document without notice and all rights are reserved. This document can only be used for the configuration of ALLNET products.

  • Page 6: Product Overview

    RSSI indication. The ALL0558N fully supports wireless encryption including Wi-Fi Protected Access (WPA-PSK/WPA2-PSK), (64/128/152)-bit WEP Encryption, and IEEE 802.1x with RADIUS. Additionally, the ALL0558N is an ideal choice to pair with the ALL0558N in a Access Point – Client Bridge or WDS Bridge – WDS Bridge topology.

  • Page 7: Access Point

    Users can select the best signal to connect with AP efficiently Indicator (CB mode) Flexible Access Point locations and cost savings (Note: The Power-over-Ethernet ALL0558N includes a proprietary PoE adapter.) Support Multi-SSID Allow clients to access different networks through a single function (4 SSID) in...

  • Page 8: Benefits

    Clients connect wirelessly to an AP and transmit data through AP to access the Internet. Multiple SSIDs ALL0558N supports up to 4 SSIDs on your access point. The following options can be set to each SSID: Public or private SSID...

  • Page 9: Package Contents

     (1) Mounting Kit with Mast-Mount Strap Special Screw Set  (1) QIG  (1) CD (User Manual) Using a power adapter other than the one included with the ALL0558N may cause damage to the device. 1.4 System Requirement The following conditions are the minimum system requirements.

  • Page 10: Understanding The All0558N Leds

    ALL0558N User’s Manual 1.6 Understanding the ALL0558N LEDs The rear of the ALL0558N has two groups of LEDs. One group, labeled INDICATORS, shows the status of the device. The second group, LINK QUALITY, shows the strength of the link between the ALL0558N and the network. The following table describes the ALL0558N LEDs.

  • Page 11: Installation

    2.2 Installing the ALL0558N To install the ALL0558N, use the following procedure to mount the device on a pole and refer to the figure below. 1. The bottom of the ALL0558N is a removable cover. Grab the cover and push down slightly while pulling it backward to remove the cover.
  • Page 12 ALL0558N User’s Manual 6. Turn over the ALL0558N. Then insert the mast strap through the middle hole of the ALL0558N. Use a screwdriver to unlock the pole-mounting ring putting it through the ALL0558N. 7. Mount the ALL0558N securely to the pole by locking the strap tightly.

  • Page 13: Wireless Network Modes

    SSID and Security Password to associate while within range. The most suitable topology for this mode is to have one ALL0558N as an AP and the second one as a Client-Bridge – when necessary a third Client-Bridge can be place within the directional antenna’s path. One advantage of using the ALL0558N to create point-to-point outdoor wireless links is when the environment is prone to radio interference on 2.4GHz band.

  • Page 14: Access Point With Wds Function Mode

    Please note that this mode is rarely used due to the nature of directional antennae. Consequently, the wireless clients need to be located in the path of the ALL0558N’s directional antenna and be within in the range to send signal back to the ALL0558N.

  • Page 15: Client Bridge Mode

    ALL0558N User’s Manual 3.3 Client Bridge Mode In the Client Bridge Mode, the ALL0558N functions like a wireless client, connecting to an Access Point wirelessly and enabling Internet connectivity wherever you want. Use Site Survey function to scan all of the Access Points within range and configure the SSID and Security Password to associate with it.

  • Page 16: Wds Bridge Mode

    ALL0558N User’s Manual 3.4 WDS Bridge Mode In the WDS Bridge Mode, the ALL0558N can wirelessly connect different local area networks by configuring each device’s MAC address and security settings. The WDS Bridge Mode can bridge up to four local wired networks together as one logical network. Every computer on this logical network can see each other, sharing files as if they are in the same location.

  • Page 17: Client Router Mode

    ALL0558N User’s Manual 3.5 Client Router Mode In Client Router Mode, the ALL0558N provides two functions: 1) acting as a wireless-Ethernet Bridge in order to relay signal from the access point; 2) acting as an active DHCP server that allows WLAN clients to share the same wireless network connection. Ideally, have clients wirelessly connect to an AP/WISP and connect to LANs via Ethernet.

  • Page 18: Configuring Your Computer For Tcp/Ip

    This chapter describes how to configure the TCP/IP settings on a computer that will be used to configure the ALL0558N. Because the default operating mode is Client Bridge, an IP address will not be assigned to the computer/notebook. Therefore, follow the steps below to assign an IP address to a client’s Ethernet adapter.
  • Page 19 Static TCP/IP. Enter an IP address (i.e. 192.168.1.10), the subnet mask of the ALL0558N, and the default gateway which is the ALL0558N’s IP address, 192.168.1.1. Note: the subnet mask must match that of the ALL0558N and the IP address must be on that subnet.

  • Page 20: Configuring Microsoft Windows Vista

    ALL0558N User’s Manual 4.2 Configuring Microsoft Windows Vista Use the following procedure to configure a computer running Microsoft Windows Vista with the default Windows interface. On the Windows taskbar, click Start, click Control Panel, and then select the Network and Internet icon.
  • Page 21 Static TCP/IP. Enter an IP address (i.e. 192.168.1.10), the subnet mask of the ALL0558N, and the default gateway which is the ALL0558N’s IP address, 192.168.1.1. Note: the subnet mask must match that of the ALL0558N and the IP address must be on that subnet.

  • Page 22: Configuring Microsoft Windows Xp

    Static TCP/IP. Enter an IP address (i.e. 192.168.1.10), the subnet mask of the ALL0558N, and the default gateway which is the ALL0558N’s IP address, 192.168.1.1. Note: the subnet mask must match that of the ALL0558N and the IP address must be on that subnet.

  • Page 23: Configuring Apple Mac Os X

    4. Click Apply Now to apply your settings and close the TCP/IP dialog box. 5. Enter an IP address (i.e. 192.168.1.10), the subnet mask of the ALL0558N, and the Router which is the ALL0558N’s IP address, 192.168.1.1. Note: the subnet mask must match that of the ALL0558N and the IP address must be on that subnet.

  • Page 24: Logging Into The All0558N

    Open your web browser. Enter IP 192.168.1.1 into your address bar. If you have changed the ALL0558N LAN IP address, make sure you enter the correct IP Address. After successfully connecting to the ALL0558N, a browser pop-up with a Windows Security notice will appear.

  • Page 25: Status

    ALL0558N User’s Manual 5 Status The Status section is on the navigation drop-down menu. Selecting it, you will then see three options: Main, Wireless Client List, and System Log. Each option is described in detail below. 5.1 Save / Load This page allows viewing of the modified settings.

  • Page 26: Main

    ALL0558N User’s Manual 5.2 Main Click on the Main link under the Status drop-down menu or click Home from the top-right of the webpage. The status that is displayed corresponds with the operating mode that is selected. Information such as operating mode, system up-time, firmware version, serial number, kernel version, and application version are displayed in the System section.

  • Page 27: Wireless Client List

    Click on the Wireless Client List link under the Status drop-down menu. This page displays the list of Clients that are associated to the ALL0558N. The MAC addresses and signal strength for each client is displayed. Click on the Refresh button to refresh the client list.

  • Page 28: Connection Status

    ALL0558N User’s Manual 5.5 Connection Status Click on the Connection Status link under the Status drop-down menu. This page displays the current status of the network, including Network Type, SSID, BSSID, Connection Status, Wireless Mode, Current Channel, Security, Data Rate, Current noise level, and Signal strength.

  • Page 29: Dhcp Client Table

    Click on the DHCP Client List link under the Status drop-down menu. This page displays the list of Clients that are associated to the ALL0558N through DHCP. The MAC addresses and signal strength for each client is displayed. Click on the Refresh button to refresh the client...

  • Page 30: System

    6 System 6.1 Switching the Operation Mode The ALL0558N supports 4 modes: Access Point, Client Bridge, WDS Bridge, and Client Router. In order to switch between the operating modes, please go to System -> Operation mode. To begin, click System Properties under System Section.

  • Page 31: Wireless Configuration

    ALL0558N User’s Manual 7 Wireless Configuration This section will guide you through all of the wireless settings. Please read the instructions carefully. Inappropriate settings could lower the performance or affect the stability of your network. Before continuing, please make sure you have chosen the correct operating mode.
  • Page 32 ALL0558N User’s Manual Wireless Mode The wireless mode supports 802.11a/n mixed operation. It is compatible with the most common wireless bands. Channel HT Mode The default channel bandwidth is 40 MHz. A larger channel can provide better transmit quality and speed.
  • Page 33 ALL0558N User’s Manual SSID Specify the SSID for current profile. VLAN ID Specify the VLAN tag for current profile. Suppressed SSID Place a check to hide the SSID. Clients will not be able to see the broadcast SSID in Site Survey.

  • Page 34: Client Bridge Mode

    ALL0558N User’s Manual 7.1.2 Client Bridge Mode Wireless Mode The wireless mode supports 802.11a/n mixed operation. It is compatible with the most common known wireless bands. SSID Specify the SSID if known. The SSID text box will be automatically filled in when an AP in the Site Survey is selected.
  • Page 35 ALL0558N User’s Manual Profile After Site Survey, the webpage will display all of the nearby Access Points. Click the BSSID if you would like to connect with it. Wireless Security Please refer to the Wireless Security section. Refresh Press Refresh to scan again.

  • Page 36: Wds Bridge Mode

    ALL0558N User’s Manual 7.1.3 WDS Bridge Mode Wireless Mode The wireless mode supports 802.11a/n mixed modes. It is compatible with the most common wireless bands. Channel HT Mode The default channel bandwidth is 40 MHz. A larger channel can provide better transmit quality and speed.
  • Page 37 ALL0558N User’s Manual MAC Address Enter the Access Point’s MAC address that you would like to extend the wireless coverage of into the MAC address filter. Mode Select Disable or Enable from the drop down list. Accept / Cancel Press Accept to confirm the changes or Cancel to return to the previous settings.

  • Page 38: Client Router Mode

    ALL0558N User’s Manual 7.1.4 Client Router Mode Wireless Mode The wireless mode supports 802.11a/n mixed operation. It is compatible with the most common wireless bands. SSID Specify the SSID, if known. The SSID text box will be automatically filled in if an AP in the Site Survey is selected.
  • Page 39 ALL0558N User’s Manual Profile After Site Survey, the webpage will display all nearby Access Points. Click the BSSID if you would like to connect with an AP. Wireless Security Please refer to the Wireless Security section. Refresh Press Refresh to scan again.

  • Page 40: Wireless Security Settings

    ALL0558N User’s Manual 7.2 Wireless Security Settings Wireless Security Settings section will guide you through the Security configurations: WEP, WPA-PSK, WPA2-PSK, WPA-PSK Mixed, WPA, WPA2, and WPA Mixed. We strongly recommend the use of WPA2-PSK as your security setting. 7.2.1 WEP Security Mode Select WEP from the drop down list.

  • Page 41: Wpa-Psk

    ALL0558N User’s Manual wireless transmit mode will drop from 802.11n to 802.11a. 7.2.2 WPA-PSK Security Mode Select WPA-PSK from the drop down list. Encryption Select Both, TKIP or AES for encryption type. Passphrase Specify the security password. Group Key Update Specify Group Key Update Interval time.

  • Page 42: Wpa2-Psk

    ALL0558N User’s Manual 7.2.3 WPA2-PSK Security Mode Select WPA2-PSK from the drop down list. Encryption Select Both, TKIP or AES for encryption type. Passphrase Specify the security password. Group Key Update Specify Group Key Update Interval time. Interval The IEEE 802.11n standard does not include WEP/WPA-PSK/WPA-PSK TKIP security mode.

  • Page 43: Wpa-Psk Mixed

    ALL0558N User’s Manual 7.2.4 WPA-PSK Mixed Security Mode Select WPA-PSK Mixed from the drop down list. Encryption Select Both, TKIP or AES for encryption type. Passphrase Specify the security password. Group Key Update Specify Group Key Update Interval time. Interval Using WPA-PSK Mixed can allow multiple security modes at the same time.

  • Page 44: Wpa

    ALL0558N User’s Manual 7.2.5 WPA Security Mode Select WPA from the drop down list. Encryption Select Both, TKIP or AES for Encryption type. Radius Server Specify Radius Server IP address. Radius Port Specify Radius Port number, the default port is 1812.

  • Page 45: Wpa2

    ALL0558N User’s Manual 7.2.6 WPA2 Security Mode Select WPA2 from the drop down list. Encryption Select Both, TKIP or AES for encryption type. Radius Server Specify Radius Server IP Address. Radius Port Specify Radius Port number, the default port is 1812.

  • Page 46: Wpa Mixed

    ALL0558N User’s Manual 7.2.7 WPA Mixed Security Mode Select WPA Mixed from the drop down list. Encryption Select Both, TKIP or AES for encryption type. Radius Server Specify Radius Server IP Address. Radius Port Specify Radius Port number, the default port is 1812.

  • Page 47: Wireless Advanced Settings

    ALL0558N User’s Manual 7.3 Wireless Advanced Settings Data Rate Select Data Rate from the drop down list. Data rate will affect the efficiency of the throughput. A lower data rate will allow for transmissions to travel longer distances. Transmit Power Select Transmit Power to increase or decrease the transmit power.
  • Page 48 ALL0558N User’s Manual increase performance by 10% during the data transmission. For example, if the 802.11a/g’s GI is 800μs, the short GI will be 400μs. The shorter guard interval results in a higher packet collision rate when the delay-spread of the channel exceeds the guard interval or if timing synchronization between the transmitter and receiver is not precise.

  • Page 49: Wireless Mac Filter

    ALL0558N User’s Manual 7.4 Wireless MAC Filter Wireless MAC Filter is used to Allow or Deny wireless clients, by their MAC addresses, from accessing the network. You can manually add a MAC address to restrict the access permission’s of the client. The default setting is Disable Wireless MAC Filters.

  • Page 50: Wds Link Settings

    ALL0558N User’s Manual 7.5 WDS Link Settings WDS Link Settings is used to establish a connection between Access Points without forgoing Access Point functionality. APs with WDS functionality can extend the wireless coverage and allow LANs to communicate with each other.

  • Page 51: Lan Setup

    Please make note of the following: 1. Obtain an IP address automatically is not a DHCP server. This setting allows the ALL0558N to automatically request an IP address when it is connected to a device which has a DHCP server.

  • Page 52: Spanning Tree Settings

    ALL0558N User’s Manual 2. Changing LAN IP Address will change LAN Interface IP address. The webpage will automatically redirect to the new IP address after Apply is selected. 8.2 Spanning Tree Settings Spanning Tree Status Select the Radio button to On or Off to toggle the Spanning Tree function.

  • Page 53: Router Settings

    ALL0558N User’s Manual 9 Router Settings This section is only available for Client Router Mode. 9.1 WAN Settings There are four different types of WAN connections: Static IP, DHCP, PPPoE, and PPTP. Please contact your ISP to determine the connection type.
  • Page 54 Account Name Specify Account Name that is provided by ISP. Domain Name Specify Domain Name that is provided by ISP. Specify the Maximum Transmit Unit size. ALLNET recommends that it remains in Auto. IP Address Specify WAN port IP address.

  • Page 55: Dhcp (Dynamic Ip)

    Specify Account Name which is provided by ISP. Domain Name Specify Domain Name which is provided by ISP. Specify the Maximum Transmit Unit size. ALLNET recommends that it remains in Auto. Get Automatically From Select the Radio button for the DNS servers to be obtained...
  • Page 56 ALL0558N User’s Manual automatically from the DHCP server. Use These DNS Servers Select the Radio button to setup the Primary DNS and Secondary DNS servers manually. Discard Ping on WAN Place a check to Enable or Disable ping from WAN.

  • Page 57: Pppoe (Point-To-Point Protocol Over Ethernet)

    Select PPPoE as your WAN connection type if your ISP provides a Username and Password. If the PPPoE is a DSL service, please remove the PPPoE software from your computer as the software is not necessary with the use of the ALL0558N. Internet Connection Select PPPoE to begin configuration of the PPPoE connection.
  • Page 58 ALL0558N User’s Manual Service Name Specify the Service Name that is given by your ISP. Connect on Demand Select the Radio button to specify the maximum idle time. The Internet will disconnect when it reaches the maximum idle time; however, it will automatically connect when a client tries to access the network.

  • Page 59: Pptp (Point-To-Point Tunneling Protocol)

    ALL0558N User’s Manual 9.1.4 PPTP (Point-to-Point Tunneling Protocol) Select PPTP as your WAN connection type if your ISP provides information regarding: IP Address, Subnet Mask, Default Gateway (Optional), DNS (Optional), Server IP, Username, and Password.
  • Page 60 ALL0558N User’s Manual Internet Connection Select PPTP to begin configuration of the PPTP connection. Type Specify the Maximum Transmit Unit size. ALLNET recommends that it remains in Auto. IP Address Specify WAN port IP address. IP Subnet Mask Specify WAN IP Subnet Mask.

  • Page 61: Lan Settings (Router Mode)

    ALL0558N User’s Manual 9.2 LAN Settings (Router Mode) IP Address Specify LAN port IP address. IP Subnet Mask Specify LAN IP Subnet Mask. WINS Server IP Specify WINS Server IP. Use Router As DHCP Place a check to enable the DHCP server.

  • Page 62: Vpn Pass Through

    ALL0558N User’s Manual 9.3 VPN Pass Through VPN Pass Through is used to allow certain protocols to be tunneled through an IP network such as PPTP and L2TP, or to implement a secure exchange of packets at the IP Layer such as IPSec.

  • Page 63: Port Forwarding

    ALL0558N User’s Manual 9.4 Port Forwarding Port Forwarding is used to allow public services such as Web Server, Mail Server, or FTP server to be set up. For example: Set up a Web Server on your computer with port number 8080. A visitor on the Internet can access your Web Server by entering WAN Port IP with port number 8080.

  • Page 64: Dmz

    ALL0558N User’s Manual settings. 9.5 DMZ Enabling DMZ will expose the computer which is in the DMZ to the Internet. This feature may be used in scenarios such as Internet Gaming or Video Conferencing. DMZ will forward all the ports to one PC simultaneously. This PC will be vulnerable to any incoming traffic, including unsolicited or malicious traffic, because DMZ opens all of the ports.
  • Page 65 ALL0558N User’s Manual Accept does not apply the changes – you must go to Status -> Save / Load to apply the new settings. Please refer to Chapter 4.1 for more information.

  • Page 66: Management Settings

    ALL0558N User’s Manual 10 Management Settings The Management section is on the navigation drop-down menu. You will see seven options: Administration, Management VLAN, SNMP Settings, Backup / Restore Settings, Firmware Upgrade, Time Settings, and Log. Each option is described below.

  • Page 67: Management Vlan

    ALL0558N User’s Manual Remote Upgrade Select the Radio button to Enable or Disable Remote Upgrade. Remote Management Specify the Port number for Remote Management. For example: Port if you specify the Port number is 8080, then you will need to enter the following http://IP address:8080 to access the web interface.
  • Page 68 ALL0558N User’s Manual ALL0558N. Verify the DHCP server can support the reconfigured VLAN ID, and then re-connect to the new IP address.

  • Page 69: Snmp Settings

    ALL0558N User’s Manual 10.3 SNMP Settings Click on the SNMP Settings link under the Management menu. This is a networking management protocol used to monitor network-attached devices. SNMP allows messages [called protocol data units] to be sent to various parts of a network. Upon receiving these messages, SNMP-compatible devices [called agents] return data stored in their Management Information Databases.

  • Page 70: Backup/Restore Settings

    Save A Copy of Click on Backup to save current configured settings. Current Settings Restore Saved Settings ALL0558N can restore a previous setting that has been saved. from a File Click on Browse to select the file and Restore. Revert to Factory...
  • Page 71 ALL0558N User’s Manual The upgrade process may take few minutes. Please do not power off the device as this may cause the device to crash or become unusable. The ALL0558N will restart automatically once the upgrade is complete.

  • Page 72: Time Settings

    ALL0558N User’s Manual 10.6 Time Settings Click on the Time Settings link under the Management menu. This page allows you to configure the time on the device. You may do this manually or by connecting to a NTP server. Manually Set Date and Manually setup the date and time.
  • Page 73 ALL0558N User’s Manual 10.7 Log Click on the Log link under the Management menu. This page displays a list of events that are triggered on the Ethernet and Wireless interface. This log can be referred to when an error occurs on the system or when a report needs to be sent to the technical support department for debugging purposes.

  • Page 74: D Iagnostics

    ALL0558N User’s Manual 10.8 Diagnostics Click on the Diagnostics link under the Management menu. This function allows you to detect connection quality and trace the routing table to the target. Target IP Specify the IP address you would like to search.

  • Page 75: Network Configuration Examples

    ALL0558N User’s Manual 11 Network Configuration Examples This chapter describes the role of the ALL0558N with 4 modes. The Access Point mode’s default configuration is a central unit of the wireless network or as a root device of the wired environment.

  • Page 76: Client Bridge Mode

    ALL0558N User’s Manual Step 4 Select the correct authentication type and password. The ALL0558N’s Access Point Mode does not provide a DHCP server so the Wireless Client IP address must be configured manually in Local Area Network Settings. 11.2 Client Bridge Mode Client Bridge Mode functions like a wireless dongle.
  • Page 77 ALL0558N’s running on WDS Bridge Mode, which are connected to a main ALL0558N that is providing Internet access, also running on WDS Bridge Mode. This is a bridged network; therefore, all nodes on the network can be in the same network IP block.

  • Page 78: Client Router Mode

    ALL0558N User’s Manual 11.4 Client Router Mode In the Client Router Mode, the ALL0558N has a DHCP Server that allows multiple devices to share the same Internet connection. Connect to an AP/WISP wirelessly and connect to LANs via wired. Client Router Mode is functionally opposite to the AP Router Mode.

  • Page 79: Appendix A - Troubleshooting

    ALL0558N User’s Manual Appendix A – Troubleshooting This appendix provides problem-solving information you may find useful in case you need to troubleshoot your ALL0558N. It also includes information about contacting technical support. A.1 Problem Solving Question Answer How do I reset the ALL0558N? There are two ways to reset the ALL0558N, a hardware method and a software method.
  • Page 80 The date when you received the product  A brief description about the issue and the attempts you tried to resolve it  To contact ALLNET Customer Service office in the United States, please use either of the following methods: Homepage: www.service.allnet.de ...

  • Page 81: Appendix B - Specifications

    - Proprietary PoE design - Power Adapter 24VAC / 1.0A Antenna: - Internal Directional 13dBi with dual polarization Package Contents: - Wireless Long Range 11N AP/CB (ALL0558N) - PoE Injector (EPE-24R) - Power Adaptor - CD with User’s Manual - QIG...
  • Page 82 ALL0558N User’s Manual 6 Mbps: 9 Mbps: 12 Mbps: 18 Mbps: 24 Mbps: 36 Mbps: 48 Mbps: 54 Mbps: 802.11n (5.18 ~ 5.825 GHz) MCS0 / MCS8: MCS1 / MCS9: MCS2 / MCS10: MCS3 / MCS11: MCS4 / MCS12: MCS5 / MCS13:...

  • Page 83: Appendix C - Glossary

    ALL0558N User’s Manual Appendix C – Glossary Access Point A base station in a WLAN that act as a central transmitter and receiver of WLAN radio signals. Ad Hoc Network A short-term WLAN framework created between two or more WLAN adapters, without going through an Access Point.
  • Page 84 A protocol that assigns temporary IP addresses automatically to client stations logging onto an IP network, so the IP addresses do not have to be assigned manually. The ALL0558N contains an internal DHCP server that automatically allocates IP address using a user-defined range of IP addresses.
  • Page 85 ALL0558N User’s Manual architecture. HT mode In the 802.11n system, two new formats, called High Throughput (HT), are defined for the Physical Layer, Mixed Mode, and Green Field. If a system runs 40 HT, two adjacent 20 MHz channels are used. The larger 40 MHz bandwidth can provide better transmit quality and speed.
  • Page 86 ALL0558N User’s Manual Quality of Service (QoS) A network’s ability to deliver data with minimum delay. QoS also refers to the networking methods used to provide bandwidth for real-time multimedia applications. Remote Authentication Dial-In User Service (RADIUS) Networking protocol that provides centralized authentication, authorization, and accounting management for computers to connect and use a network service.
  • Page 87 ALL0558N User’s Manual Protocol (EAP) to authenticate wireless clients using an external RADIUS database. WPA uses Temporal Key Integrity Protocol (TKIP), Message Integrity Check (MIC), and IEEE 802.1x to encrypt data. See also WPA-PSK (WPA -Pre-Shared Key). Wi-Fi MultiMedia (WMM) Part of the IEEE 802.11e QoS enhancement to the Wi-Fi standard that ensures quality of...
  • Page 88 The conformity to the above directive is indicated by the CE sign on the device. The ALLNET ALL0558N conforms to the Council EMC Directives of 2006/95/EC and R&TTE Directive 2004/108/EC. This equipment meets the following conformance standards: EN 60950-1:2006 +A11:2009 + A1:2010 + A12:2011 This equipment is intended to be operated in all countries.
