ALL02800N 300M Wireless-N Accesspoint
ALL02800N
300M Wireless-N Accesspoint
Manual
1


Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ALL02800N and is the answer not in the manual?

Questions and answers

Related Manuals for Allnet ALL02800N

Summary of Contents for Allnet ALL02800N

  • Page 1 ALL02800N 300M Wireless-N Accesspoint ALL02800N 300M Wireless-N Accesspoint Manual 1   ...
  • Page 2 Copyright of the whole product as integration, including its accessories and software, belongs to ALLNET GmbH Without the permission of ALLNET GmbH, any individual or party is not allowed to copy, plagiarize, imitate or translate it into other languages.

  • Page 3: Table Of Contents

    ALL02800N 300M Wireless-N Accesspoint Content Content.............3 Chapter 1 Product Overview......5 1.1 Features..........6 1.2 Package Contents......7 1.3 LED Indicator and Panel Description..8 Chapter 2 Hardware Installation....12 Chapter 3 Web Configuration......14 3.1 Web Login........14 3.2 Wizard...........15 3.3 Running Status.......17 3.4 LAN Settings........18 Chapter 4 Wireless Settings......20...
  • Page 4 ALL02800N 300M Wireless-N Accesspoint 4.2 Advanced Settings......58 4.3 WPS Settings........60 4.4 Access Control........62 4.5 Connection Status......64 4.6 PING..........65 Chapter 5 SNMP Setting......67 5.1 SNMP Introduction......67 5.2 SNMP Setting.........68 Chapter 6 System Tools......69 6.1 Password Change......69 6.2 Restore to Factory......70 6.3 Backup/Restore......71 6.4 Time Settings.........72...

  • Page 5: Chapter 1 Product Overview

    ALL02800N 300M Wireless-N Accesspoint Chapter 1 Product Overview ALL02800N is an IEEE802.11n (Draft 2.0)-compliant wireless access point with one Gigabit LAN switch port, which utilizes the latest MIMO technology and provides up to 300Mbps stable transmission rate from wireless radio to wired network. With backward compatible with IEEE802.11b/g device, it is suitable...

  • Page 6: Features

    ALL02800N 300M Wireless-N Accesspoint 1.1 Features  Complies with IEEE802.11n (Draft 2.0), IEEE802.11b and IEEE802.11g standards  Supports five working modes: wireless AP, Repeater, P2P, P2MP and wireless client  Provides 300Mbps receiving rate and 300Mbps sending rate  MIMO technology utilizes reflection signal to increase 8 times transmission distance of original 802.11g...

  • Page 7: Package Contents

    (Access Point) will provide wireless communication service for users around. 1.2 Package Contents Please unpack the package and find the following items:  One ALL02800N Wireless AP  One Power Adapter  One Quick Installation Guide  One CD-ROM 7 ...

  • Page 8: Led Indicator And Panel Description

    ALL02800N 300M Wireless-N Accesspoint If any of listed items are missing or damaged, please contact the ALLNET reseller from whom you purchased for replacement immediately. 1.3 LED Indicator and Panel Description LED indicator description on front panel  (from L to R)
  • Page 9 ALL02800N 300M Wireless-N Accesspoint When turns green, blinking indicates the system runs well. WLAN Wireless signal LED indicator. When turns green, Always ON indicates the wireless function is enabled; blinking indicates the device is transmitting and/or receiving data. Wired local network LED indicator. Always ON indicates it is connected with Ethernet device;...
  • Page 10 ALL02800N 300M Wireless-N Accesspoint Rear Panel：（From L to R）  POWER The jack is for power adapter connection. Please use the included 12V DC power adapter. The Gigabit Ethernet port is for computers NIC or switch connection. It also can be used as PoE interface.
  • Page 11 ALL02800N 300M Wireless-N Accesspoint factory default settings. When you press for 1 second, the WPS function will be enabled. Antenna The detachable antenna is for wireless radio transmitting and receiving. Don not detach these antennas fear wireless performance. 11   ...

  • Page 12: Chapter 2 Hardware Installation

    1. Connect one end of the network cable to your Ethernet broadband router, switch or PC, and the other end to the ALL02800N LAN port. 2. Connect the power adapter to the APs Power jack. Then plug the power adapter into an electrical outlet.
  • Page 13 ALL02800N 300M Wireless-N Accesspoint The topology plan of AP mode connection 13   ...

  • Page 14: Chapter 3 Web Configuration

    ALL02800N 300M Wireless-N Accesspoint Chapter 3 Web Configuration 3.1 Web Login Connect to ALL02800N via wired cable and configure 192.168.0.x(x ranges 2-254) as your PCs IP address, and 255.255.255.0 as subnet mask. (Please refer to the Appendix II for details on TCP/IP setting) Launch Internet Explorer or Netscape Navigator.
  • Page 15 ALL02800N 300M Wireless-N Accesspoint Click OK to enter the first web page of the device. 15   ...

  • Page 16: Wizard

    ALL02800N 300M Wireless-N Accesspoint 3.2 Wizard Click “Nex? in the first page and the next page appears. On this page, you can select one from five wireless network modes: Wireless AP, P2P Bridge Mode, P2MP Bridge Mode, Repeater Mode and Client. And to secure your network, you can configure its corresponding security setting.

  • Page 17: Running Status

    ALL02800N 300M Wireless-N Accesspoint 3.3 Running Status This page shows the wireless AP current status, including wireless status, LAN status and system information. Wireless Status  Here shows current working status, including working mode, wireless network mode, SSID, 17   ...

  • Page 18: Lan Settings

    ALL02800N 300M Wireless-N Accesspoint Channel, Encryption mode, etc. LAN Interface information  Here shows LAN IP obtain way, MAC address, IP address, subnet mask, etc. System information  Here shows the devices current software version, hardware version, etc. 3.4 LAN Settings This section mainly deals with LAN?s basic settings.
  • Page 19 ALL02800N 300M Wireless-N Accesspoint address, subnet mask gateway manually for the device. ： Dynamic IP Automatically obtain IP address, subnet mask and gateway from DHCP server. (Unless you have got permission to obtain this information from the uplink connected device, otherwise, it is not recommended to select this way).

  • Page 20: Chapter 4 Wireless Settings

    ALL02800N 300M Wireless-N Accesspoint Chapter 4 Wireless Settings 4.1 Working Mode Select “ireless Setting->Working Mode to enter the following window. From the drop-down menu Working Mode, the device supports five working modes: AP, P2P Bridge, P2MP Bridge, AP Repeater and Client.

  • Page 21: Access Point (Ap) Mode

    ALL02800N 300M Wireless-N Accesspoint 4.1.1 Access Point (AP) Mode The AP mode is the basic mode of the device. When the system is reset to the default factory settings, the operating mode reverts to AP mode. In this mode, the AP will act as a central hub for different wireless LAN clients.
  • Page 22 ALL02800N 300M Wireless-N Accesspoint 4.1.1.2 AP Mode Settings In the working mode, select “AP” to enter the next window. 22   ...
  • Page 23 ALL02800N 300M Wireless-N Accesspoint Basic Wireless Settings   Network Mode：Select one mode from the following. The default is 11b/g/n mode. ： 11b mode Allow the wireless client to connect with the device in 11b mode at the maximum speed of 11Mbps.
  • Page 24 ALL02800N 300M Wireless-N Accesspoint When this feature is enabled, wireless clients connected with the same SSID can not communicate with each other. For example, configure main SSID as AP1, minor SSID as AP2. PC1 and PC2 connect to AP1 via wireless adapter, and configure PC1 and PC2 in the same segment.
  • Page 25 ALL02800N 300M Wireless-N Accesspoint connecting to AP2. After the feature is enabled, two PCs can not communicate share network resource each other. This feature isolate communication of wireless clients connected with different SSID. Tip: If you want to isolate all connected...
  • Page 26 ALL02800N 300M Wireless-N Accesspoint Wireless Security Setting：  It is used to configure the AP networks security setting. Here presents the common ten encryption methods, including Mixed WEP, WPA-personal, WPA-enterprise, WPA2- personal, WPA2- enterprise, etc. 26   ...
  • Page 27 ALL02800N 300M Wireless-N Accesspoint Mixed WEP (Wired Equivalent Privacy), basic encryption method, usually encrypts wireless data using a series of digital keys (64 bits or 128 bits in length). By using the same keys on each of your wireless network devices, you can...
  • Page 28 ALL02800N 300M Wireless-N Accesspoint Setting Explanation ：  Select SSID Select the SSID (main SSID or minor SSID) to configure security setting from the drop-down menu. ：  Security Mode From the drop-down menu select corresponding security encryption modes. ：...
  • Page 29 ALL02800N 300M Wireless-N Accesspoint enter the following window: Setting Explanation ：  Select SSID Select the SSID (main SSID or minor SSID) to configure security setting from the drop-down menu. ：  WPA Algorithms Provides TKIP [Temporal Key Integrity Protocol] or AES [Advanced Encryption Standard].
  • Page 30 ALL02800N 300M Wireless-N Accesspoint 30   ...
  • Page 31 ALL02800N 300M Wireless-N Accesspoint WPA2-PSK WPA2 provides more secure features than WEP and WPA. Select “WA2-PSK?from the drop-down menu to enter the following window: Setting Explanation ：  Select SSID Select the SSID (main SSID or minor SSID) to configure security setting from the drop-down menu.
  • Page 32 ALL02800N 300M Wireless-N Accesspoint ：  Pass Phrase Enter the encrypted characters with 8-63 ASCII characters. ：  Key renewal Interval Set the keys renewal period. This security mode is used when a RADIUS server is connected to the device. Select “WA?from the drop-down menu to enter the...
  • Page 33 ALL02800N 300M Wireless-N Accesspoint [Advanced Encryption Standard]. The default is TKIP mode. ：  Key Renewal Interval Set the keys renewal period. ：  Radius Server Enter the IP address of the Radius server. ：  Radius Server port Enter the authentication port of the Radius server.
  • Page 34 ALL02800N 300M Wireless-N Accesspoint Setting Explanation ：  Select SSID Select the SSID (main SSID or minor SSID) to configure security setting from the drop-down menu. ：  WPA Algorithms Provides TKIP [Temporal Key Integrity Protocol] or AES [Advanced Encryption Standard].
  • Page 35 ALL02800N 300M Wireless-N Accesspoint authentication port of the Radius server. The default is 1812. ：  Shared Key Enter the shared key for authentication server with 8~63 ASCII characters. ：  Session Timeout The authentication interval period between AP and authentication server.
  • Page 36 ALL02800N 300M Wireless-N Accesspoint 802.1x Authentication This security mode is used when a RADIUS server is connected to the device. 802.1x, a kind of Port-based authentication protocol, is an authentication type and strategy for users. The port can be either a physic port or logic port (such as VLAN).
  • Page 37 ALL02800N 300M Wireless-N Accesspoint Setting Explanation ：  Select SSID Select the SSID (main SSID or minor SSID) to configure security setting from the drop-down menu. ：  802.1x WEP Click “Enable/Disable to enable or disable the WEP algorithm. ：...

  • Page 38: P2P (Point To Point) Bridge Mode

    ALL02800N 300M Wireless-N Accesspoint 4.1.2 P2P (Point to Point) Bridge Mode Two wired local networks communicate and share network resource via two ALL02800N?s wireless signals which also can extend the wired network. In this mode, AP can not connect with wireless clients, but serve as wireless bridge.
  • Page 39 ALL02800N 300M Wireless-N Accesspoint Basic wireless Settings   Network Mode：Select one mode from the following. The default is 11b/g/n mode. ：  11b mode Allow the wireless client to connect with the device in 11b mode at the maximum speed of 11Mbps.
  • Page 40 ALL02800N 300M Wireless-N Accesspoint client device to connect with the AP with auto-negotiation speed, and 11n wireless client to connect the device with 11g speed. ：  11b/g/n mode Allow 11b/g/n-compliant client device to connect with the AP with auto- negotiation speed.
  • Page 41 ALL02800N 300M Wireless-N Accesspoint extension channel range is used in 11n mode. Wireless Distribution System (WDS)Setting  ：  Encryption Type Select the data encryption method from WEP, TKIP, AES or NONE. The default is NONE. WEP Encryption Description ：...
  • Page 42 ALL02800N 300M Wireless-N Accesspoint characters with 8-63 ASCII characters. ：  AP MAC Address Input the MAC address of remote access point by manual or scan. ： Open Scan Enable scan to obtain remote AP MAC address, select one and Click “Save to complete this parts setting.

  • Page 43: P2Mp Bridge Mode

    ALL02800N 300M Wireless-N Accesspoint 4.1.3 P2MP Bridge Mode The P2MP Bridge Mode which connects scattered wired network together is more complicated than P2P Bridge mode. P2MP usually transmit wireless signals from one access point, and other access points are in charge of receiving signals so as to share network resource.
  • Page 44 ALL02800N 300M Wireless-N Accesspoint Note: In P2P Bridge and P2MP bridge mode, at least two wireless APs are needed. For better performance, it is recommended to use the AP with same model. 4.1.3.2 P2MP Setting In the working mode, select “P2P Bridge to enter the next screen.
  • Page 45 ALL02800N 300M Wireless-N Accesspoint Basic wireless Settings   Network Mode：Select one mode from the following. The default is 11b/g/n mode. ：  11b mode Allow the wireless client to connect with the device in 11b mode at the maximum speed of 11Mbps.
  • Page 46 ALL02800N 300M Wireless-N Accesspoint ：  BSSID Basic Service Set Identifier of wireless network. In IEEE802.11, BSSID is the MAC address of wireless access point. ：  Channel Specify the effective channel (from 1 to 13\Auto) of the wireless network.
  • Page 47 ALL02800N 300M Wireless-N Accesspoint characters with 8-63 ASCII characters. AES Encryption Description ： Pass Phrase Enter the encrypted  characters with 8-63 ASCII characters. ：  AP MAC Address Input the MAC addresses (no more than four) of remote access points by manual or scan.

  • Page 48: Wireless Repeater Mode

    ALL02800N 300M Wireless-N Accesspoint 4.1.4 Wireless Repeater Mode Repeater Mode can repeat and amplify wireless signals to extend wireless network coverage. In this mode, wireless clients are allowed to connect. 4.1.4.1 Application and Topology Plan When two LAN?s transmission distance is over the...
  • Page 49 ALL02800N 300M Wireless-N Accesspoint Basic wireless Settings  ：Select one mode from the  Network Mode following. The default is 11b/g/n mode. ：  11b mode Allow the wireless client to connect with the device in 11b mode at the maximum speed of 11Mbps.
  • Page 50 ALL02800N 300M Wireless-N Accesspoint maximum speed of 54Mbps. ：  11b/g mode Allow the 11b/g-compliant client device to connect with the AP with auto-negotiation speed, and 11n wireless client to connect the device with 11g speed. ：  11b/g/n mode...
  • Page 51 ALL02800N 300M Wireless-N Accesspoint AP2. PC1 and PC2 connect to AP1 via wireless adapter, and configure PC1 and PC2 in the same segment. After the feature is enabled, two PCs communicate share network resource each other, but they can communicate with wireless clients connected with AP2.
  • Page 52 ALL02800N 300M Wireless-N Accesspoint Tip: If you want to isolate all connected wireless client's communication, please enable MBSSID AP and AP Isolation simultaneously. ：  BSSID Basic Service Set Identifier of wireless network. In IEEE802.11, BSSID is the MAC address of wireless access point.
  • Page 53 ALL02800N 300M Wireless-N Accesspoint ：  Encryption Type Select the data encryption method from WEP, TKIP, AES or NONE. The default is NONE. WEP Encryption Description ：  WEP Key 1~4 Set the WEP key with the format of ASCII and Hex. You can enter ASCII code (5 or 13 ASCII characters.
  • Page 54 ALL02800N 300M Wireless-N Accesspoint ： MAC Address 1 Input AP1 MAC address; ： MAC Address 2 Input AP2 MAC address; ： MAC Address 3 Input AP3 MAC address; ： MAC Address 4 Input AP4 MAC address; ： Open Scan Enable scan to obtain remote AP MAC address, select one and Click “Save”...

  • Page 55: Wireless Client Mode

    ALL02800N 300M Wireless-N Accesspoint 4.1.5 Wireless Client Mode In this mode, connect the devices LAN port to wired network adapter port. In this case, AP is used as a wireless Adapter. When you select this mode, please keep the device and the connecting network in the same segment.
  • Page 56 ALL02800N 300M Wireless-N Accesspoint 4.1.5.2 Client Mode Settings In the working mode, select “Clent” to enter the next window. ：  Security Mode Select wireless encryption method from WEP, WPA-PSK and WPA2- PSK (Note: when you select “ONE?, the security mode is disabled.).
  • Page 57 ALL02800N 300M Wireless-N Accesspoint format of ASCII and Hex. You can enter ASCII code (5 or 13 ASCII characters. Illegal character as „/“ is not allowed.) Or 10/26 hex characters. ：  Default Key Select one key from the four configured keys as the current available one.
  • Page 58 ALL02800N 300M Wireless-N Accesspoint ：  Open Scan Enable scan to obtain remote AP MAC address. Select one and Click “Save” to complete this parts setting. The AP will reboot automatically, and then the setting will go into effect. 58 ...

  • Page 59: Advanced Settings

    ALL02800N 300M Wireless-N Accesspoint 4.2 Advanced Settings This section mainly deals with wireless advanced settings, including Speed, Beacon Interval, Fragment Threshold, etc. Select “Wireless Setting->Advanced Setting to enter the following screen: Setting Explanation： ：  BG Protection Mode For 11b/g wireless client, it is easier to connect with 11n wireless device.
  • Page 60 ALL02800N 300M Wireless-N Accesspoint Basic Data Rates from the drop-down menu. Here, default value is (1-2-5.5-11Mbps?. It is recommended not to modify the default value. ：  Beacon Interval The frequency interval of the beacon, which is a packet broadcast by an AP to synchronize a wireless network.

  • Page 61: Wps Settings

    ALL02800N 300M Wireless-N Accesspoint 4.3 WPS Settings WPS (Wi-Fi Protected Setting) can be easy and quick to establish the connection between the wireless network clients and the device through encrypted contents. The users only enter the PIN code or the...
  • Page 62 ALL02800N 300M Wireless-N Accesspoint ：  WPS mode Provide two ways: PBC (Push-Button Configuration) and PIN code. ：  PBC Select the PBC or press the WPS button on the front panel of the device for about one second (Press the button for about one second and WPS indicator will be blinking for 2 minutes, which means the WPS is enabled.

  • Page 63: Access Control

    ALL02800N 300M Wireless-N Accesspoint 4.4 Access Control To secure your wireless LAN, the wireless access control is actually based on the MAC address management. Select “Wireless Setting->Access Control to display the following screen: Setting Explanation  MAC Address Filter: Enable/disable MAC address filter. Select “close” of MAC Adress Filter;...
  • Page 64 ALL02800N 300M Wireless-N Accesspoint ：  MAC Address Management Input the MAC address to implement the filter policy. Click ?Add? to finish the MAC add operation. ：  MAC list Show the added MAC address. You can add or delete them.

  • Page 65: Connection Status

    ALL02800N 300M Wireless-N Accesspoint 4.5 Connection Status This page shows wireless clients connection status, including MAC address, Channel bandwidth, etc. Select “Wireless Setting->connection status to enter the following screen: Explanation： ：  MAC Address Shows current connecting host?s MAC address.

  • Page 66: Ping

    ALL02800N 300M Wireless-N Accesspoint 4.6 PING Ping is used to check devices connectivity. If the connecting device has established connection with AP, the result will show “connected, otherwise, shows “destination host unreachable. Select “Wireless Setting->Ping to show the following window: Explanation：...

  • Page 67: Chapter 5 Snmp Setting

    ALL02800N 300M Wireless-N Accesspoint Chapter 5 SNMP Setting 5.1 SNMP Introduction Simple Network Management Protocol (SNMP) is a popular protocol for network management. It is widely used in local area networks (LAN) for collecting information, and managing and monitoring, network devices, such as servers, printers, hubs, switches, and routers from a management host.

  • Page 68: Snmp Setting

    ALL02800N 300M Wireless-N Accesspoint 5.2 SNMP Setting This device supports SNMP v1 and SNMP v2c. Please click “SNMP Setting” in the left page to enter the following window: Click “Enable” or “Disable” to enable and disable SNMP management. Setting Explanation：...
  • Page 69 ALL02800N 300M Wireless-N Accesspoint SNMP information. The default is Public.  Read/Write Community: Indicates the community read/write access string to permit reading and re-writing this AP SNMP information. The default is Private. 69   ...

  • Page 70: Chapter 6 System Tools

    ALL02800N 300M Wireless-N Accesspoint Chapter 6 System Tools This section focuses on how to maintain AP, including Restore to Factory Default Setting, Backup/Restore, Firmware Upgrade, Reboot, Password Change, Syslog. 6.1 Password Change This section is to set a new user name and password to better secure your device and network.

  • Page 71: Restore To Factory

    ALL02800N 300M Wireless-N Accesspoint New Password: Enter a new password. Re-enter to Confirm: Re-enter to confirm the new password. NOTE: It is highly recommended to change the password to secure your network and the device. 6.2 Restore to Factory This button is to reset all configurations to the default values.

  • Page 72: Backup/Restore

    ALL02800N 300M Wireless-N Accesspoint 6.3 Backup/Restore The device provides backup/restore settings, so you need set a directory to keep these settings. Backup: Click this button to back up the devices configurations. Browse: Click this button to browse the directory where you backup or save the devices settings.

  • Page 73: Time Settings

    ALL02800N 300M Wireless-N Accesspoint 6.4 Time Settings This section is to select the time zone for your location. You can select your own time or obtain the standard GMT time from Internet. Setting Explanation：  Time Zone: Select your time zone from the drop-down menu.

  • Page 74: Reboot System

    ALL02800N 300M Wireless-N Accesspoint 6.5 Reboot System This page is used to reboot wireless access point. Rebooting the device makes the settings configured go into effect. Reboot: Click this button to reboot the device. 6.6 Firmware Upgrade The device provides the firmware upgrade by clicking the “Upgade”...
  • Page 75 ALL02800N 300M Wireless-N Accesspoint Upgrade Steps： 1. Download the higher firmware version from our website: www.allnet.de 2. Extract the firmware file on your computer. 3. On the Firmware Upgrade screen, enter the location directory of the firmware file in the field provided, or click the Browse button and find the file.

  • Page 76: Syslog

    ALL02800N 300M Wireless-N Accesspoint 6.7 Syslog The section is to view the system log. Click the “refresh” to update the log. Click “Clear” to clear all shown information. If the log is over 150 records, it will clear them automatically.

  • Page 77: Appendix I: Glossary

    ALL02800N 300M Wireless-N Accesspoint Appendix I: Glossary Access Point(AP): Any entity that has station functionality and provides access to the distribution services, via the wireless medium(WM) for associated stations. Channel: An instance of medium use for the purpose of passing protocol data units...
  • Page 78 ALL02800N 300M Wireless-N Accesspoint this setting is the same for all devices in your wireless network. WEP: Wired Equivalent Privacy (WEP) is the method secure wireless data transmission. adds data encryption every single packet transmitted in the wireless network. The 40bit and 64bit encryption are the same because of out 64 bits, 40 bits are private.
  • Page 79 ALL02800N 300M Wireless-N Accesspoint product use different method for key generation, it might not work for different products. Therefore, it is NOT recommend using. WPA/WPA2: A security protocol for wireless networks that builds on the basic foundations of WEP. It secures wireless...

  • Page 80: Appendix Ii: Tcp/Ip Address Setting (Take Winxp As Example)

    ALL02800N 300M Wireless-N Accesspoint Appendix II: TCP/IP Address Setting (Take Winxp as example) Click the “Start” – “Settings” –“Control Panel” (Fig- 1): Click “Network and Internet Connections? the windows as below will appear (Fig- 2): Click the “Network Connections? as Fig-3: 80 ...
  • Page 81 ALL02800N 300M Wireless-N Accesspoint Choose “Local Area Connection? right-click on the icon, choose the “Properties” then the “Local Area Connection Properties windows appear, choose the “Internet Protocol (TCP/IP)?in the “This connection uses the following items? click the “Properties” 81   ...
  • Page 82 ALL02800N 300M Wireless-N Accesspoint Choose the “Use the following IP address? enter the IP address as: 192.168.0.xxx. (xxx ranges 1~253), Subnet mask is: 255.255.255.0(As Showed in Fig- 5) Click “OK” to apply and return to the “Local Area Connection” Properties windows.
  • Page 83 The conformity to the above directive is indicated by the CE sign on the device. The ALLNET ALL02800N conforms to the Council Directives of EC EMC 2004/108/EC with CE marking requirement. This equipment meets the the following conformance standards: This equipment is intended to be operated in all countries.
