Lombardini 15 LD 225 Workshop Manual

15ld series
Hide thumbs Also See for 15 LD 225:
Table of Contents

Advertisement

Quick Links

COMPILER TECO/ATI
REG. CODE
1-5302-467
WORK SHOP
MANUAL
15LD series engines, p.no. 1-5302-467
15 LD 225
15 LD 315
15 LD 350
15 LD 400
15 LD 440
6
MODEL N°
DATE OF ISSUE
50707
th
Edition
05
REVISION
06-95
DATE
ENDORSED
22.12.2003
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 15 LD 225 and is the answer not in the manual?

Questions and answers

Related Manuals for Lombardini 15 LD 225

Summary of Contents for Lombardini 15 LD 225

  • Page 1 WORK SHOP MANUAL 15LD series engines, p.no. 1-5302-467 15 LD 225 15 LD 315 15 LD 350 15 LD 400 15 LD 440 Edition COMPILER TECO/ATI REG. CODE MODEL N° DATE OF ISSUE DATE ENDORSED REVISION 1-5302-467 50707 06-95 22.12.2003...

  • Page 2: General Service Notes

    FOREWORD We have done all in our power to give up to date and accurate technical information in this manual. Lombardini engines are, however, constantly developing thus the data in this publication may be liable to modification without prior notice.

  • Page 3: Warranty Certificate

    WARRANTY CERTIFICATE WARRANTY CERTIFICATE The products manufactured by Lombardini Srl are warranted to be free from conformity defects for a period of 24 months from the date of delivery to the first end user. For engines fitted to stationary equipment, working at constant load and at constant and/or slightly variable speed within the setting limits, the warranty covers a period up to a limit of 2000 working hours, if the above mentioned period (24 months) is not expired.

  • Page 4: Table Of Contents

    ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Fuel filter for 15 LD 225 - 315 - 350 - 400 - 440 (version with external filter) ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○...
  • Page 5 ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ LUBRICATION SYSTEM Page 15 LD 225 - 315 - 350 LUBRICATION SYSTEM ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○...
  • Page 6 ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ADJUSTMENTS - 15 LD 225 ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○...

  • Page 7: Troubleshooting

    TROUBLE SHOOTING POSSIBLE CAUSES AND TROUBLE SHOOTING The following table contains the possible causes of some failures which may occur during operation. Always perform these simple checks before removing or replacing any part. TROUBLE POSSIBLE CAUSE Clogged pipes Clogged fuel filter Air inside fuel circuit Clogged tank breather hole Faulty fuel pump...

  • Page 8: Safety Decals - Safety Instructions

    SAFETY INSTRUCTIONS • Lombardini Engines are built to supply their performances in a safe and long-lasting way. To obtain these results, it is essential for users to comply with the servicing instructions given in the relative manual along with the safety recommendations listed below.
  • Page 9 • Only check belt tension when the engine is off. • Only use the eyebolts installed by Lombardini to move the engine. These lifting points are not suitable for the entire machine; in this case, the eyebolts installed by the manufacturer should be used.
  • Page 10 NOTE COMPILER TECO/ATI REG. CODE MODEL N° DATE OF ISSUE DATE ENDORSED REVISION 1-5302-467 50707 06-95 22.12.2003...

  • Page 11: Model Number And Identification

    MODEL NUMBER AND IDENTIFICATION MODEL NUMBER ENGINE IDENTIFICATION Displacement (cc) R.P.M. Diesel Customer's code LOMBARDINI Approval code Engine group number Engine Serial Number COMPILER TECO/ATI REG. CODE MODEL N° DATE OF ISSUE DATE ENDORSED REVISION 1-5302-467 50707 06-95 22.12.2003...
  • Page 12 TECHNICAL DATA CHARACTERISTICS 15 LD 225, 15 LD 315, 15 LD 350 TIPO MOTORE 15LD 225 15LD 315 15LD 350 Number of cylinders Bore Stroke Swept volume Compression ratio 21:1 20,3:1 20,3:1 R.P.M. 3600 3600 3600 N 80/1269/EEC-ISO 1585 3,5(4,8)

  • Page 13: Technical Data

    TECHNICAL DATA CHARACTERISTICS 15 LD 400, 15 LD 440 TIPO MOTORE 15LD 400 15LD 440 Number of cylinders Bore Stroke Swept volume Compression ratio 20,3:1 20,3:1 R.P.M. 3600 3600 N 80/1269/EEC-ISO 1585 7,0(9,5) 7,7(10,5) Power kW (HP) NB ISO 3046 - 1 IFN 6,4(8,7) 7,0(9,6) NA ISO 3046 - 1 ICXN...

  • Page 14: Vcharacteristic Curves

    Max. power tolerance is 5%. Power decreases by approximately 1% every 100 m di altitude and by 2% every 5°C above 25°C. Note: Consult LOMBARDINI for power, torque curves and specific consumptions at rates differing from those given above. COMPILER TECO/ATI REG.
  • Page 15 Max. power tolerance is 5%. Power decreases by approximately 1% every 100 m di altitude and by 2% every 5°C above 25°C. Note: Consult LOMBARDINI for power, torque curves and specific consumptions at rates differing from those given above. COMPILER TECO/ATI REG.

  • Page 16: Overall Dimensions

    OVERALL DIMENSIONS COMPILER TECO/ATI REG. CODE MODEL N° DATE OF ISSUE DATE ENDORSED REVISION 1-5302-467 50707 06-95 22.12.2003...
  • Page 17 OVERALL DIMENSIONS 15 LD 400 15 LD 440 COMPILER TECO/ATI REG. CODE MODEL N° DATE OF ISSUE DATE ENDORSED REVISION 1-5302-467 50707 06-95 22.12.2003...

  • Page 18: Maintenance- Recommended Oil Type - Refilling

    The cetane rating of the fuel must be higher than 45 to prevent difficult starting. Do not use dirty diesel fuel or mixtures of diesel fuel and water since this would cause serious engine faults. The capacity of the standard tank is: 15 LD 225 l. 3.0 15 LD 315 l.
  • Page 19 46152 D/E. In the countries where AGIP and ESSO products are not available, use oil API SJ/CF for Diesel engines or oil corresponding to the military specification MIL-L-46152 D/E. SAE 10W OIL SUPPLY ( liters ) 15 LD 225 SAE 20W Standard oil sump SAE 30...

  • Page 20: Disassembly/Reassembly

    Besides disassembly and reassembly operations this chapter also includes checking and setting specifications, dimensions, repair using compressed air, wear eye and operating instructions. Always use original LOMBARDINI spare protection. parts for repair operations. Clean the filtering element with air blast. Air must be blown from inside to outside the cartridge at a distance of at least 15 cm from the paper.

  • Page 21: Dry Air Cleaner For 15Ld 400-440

    DISASSEMBLY/REASSEMBLY VIII Clean the filtering element with air blast. Air must be blown from inside to outside the cartridge at a distance of at least 15 cm from the paper. Lightly and repeatedly tap the element on a hard surface to eliminate all excess dirt.

  • Page 22: Muffler

    VIII DISASSEMBLY/REASSEMBLY Never clean the filtering element 6 using solvents with a low flash point. This could cause an explosion ! Make sure that the retention rings 4 - 5 are in a good condition and replace them if they are damaged. Oil-bath air cleaner (optional) Components: 1 Upper shell...

  • Page 23: Rocker Arm Cover - Breather Ricirculation

    Make sure that oil plug 5 is correctly closed. Refit cover 1 and tighten rocker arm cover to 10 Nm. Valve/rocker arm clearance ( 15 LD 225-315-350 ) Set valve/rocker arm clearance when the engine is cold: bring piston to top dead center on the compression stroke and set clearance at 0.10-0.15 mm using a thickness gauge.

  • Page 24: Hydraulic Tappets 15 Ld 400-440

    VIII DISASSEMBLY/REASSEMBLY Hydraulic tappets 15 LD 400-440 Distribution uses hydraulic tappets for automatic adjustment of valve clearance. The figure shows the tappet used in 15 LD 400 engines. Caption 1- Lock ring 2- Upper collar 3- Oil inlet holes 4- Low-pressure chamber 5- Piston 6- Play-recovery spring 7- Case...

  • Page 25: Fuel Filter 15 Ld 225-400-440 (Version With Internal Filter)

    See page 18 for the frequency with which the fuel filter must be replaced. See fig. 99 for the dimensions. Fuel filter for 15 LD 225 - 315 - 350 - 400 - 440 (version with external filter) Loosen the clamps and disconnect the hoses.

  • Page 26: Flywheel

    VIII DISASSEMBLY/REASSEMBLY Re-coil starting Operation: When pulling handle 10, thanks to the action of friction spring 12, teeth 4 protrude from cap 3. After starting these teeth go back to the initial position because the cap rotates. Rope 9 is re-wound around pulley 6 by means of spring 7.

  • Page 27: Cylinder Head

    Injector projection The end of nozzle A should project 2,5 mm for 15 LD 225-315-350 and 3,0÷3,5 mm for 15 LD 400-440 from the cylinder head plane. Adjust with copper gaskets B with thickness of 0.5, 1 and 1.5 mm COMPILER TECO/ATI REG.

  • Page 28: Valve, Springs

    1 serial N° 7107-1460-047 after having thoroughly lubricated it, then proceed as indicated in the figure. Valve, springs Measure the free length with a caliper. Engine 15 LD 225-315-350 Free length A = 33.72 Engine 15 LD 400-440 Free length A = 34,88 Note: Replace the spring if the free length A is 1 mm less than specified.

  • Page 29: Valves, Characteristics

    Dimensions (mm) for 15 LD 315-350-400-440 A = 40 B = 31 C = 11.000-11.018 D = 11.040-11.055 Dimensions (mm) for 15 LD 225 A = 35 B = 30 C = 10.000-10.020 D = 10.040-10.055 Note: Valve guides with outer diameters increased by 0.5 mm are also available as spares.

  • Page 30: Dimensions And Clearance Between Guides And Valve Stems (Mm)

    After cutting valve seats, lap valve seats with fine lapping compound. The sealing surface S should not exceed 2 mm. Lowering valve for 15 LD 225-315-350 (D = 0.55÷0.85 mm). Lowering valve for 15 LD 400-440 (D = 0.35÷0.65 mm).

  • Page 31: Cylinder

    DISASSEMBLY/REASSEMBLY VIII Cylinder Set a bore gauge to zero with a calibrated ring. Check diameter at 1, 2 and 3; repeat the operation at the same points after turning the bore gauge 90°. If wear exceeds the max. given value by 0.05, bore the cylinder and fit oversize piston and rings.
  • Page 32 VIII DISASSEMBLY/REASSEMBLY COMPILER TECO/ATI REG. CODE MODEL N° DATE OF ISSUE DATE ENDORSED REVISION 1-5302-467 50707 06-95 22.12.2003...

  • Page 33: Piston Rings, Distance Between The Tips (Mm)

    ÷ ÷ l i o ÷ Wear limit 1 mm - for the 2nd piston ring of 15 LD 225 and 15 LD 350 engines, the wear limit is 2.0 mm. COMPILER TECO/ATI REG. CODE MODEL N° DATE OF ISSUE...

  • Page 34: Clearance

    120° to each other. In 15 LD 350 and 15 LD 225 engines, the second piston ring is not torsional, while the first and third piston rings do not have chromium plated zones but are nitrided.

  • Page 35: Piston Protrusion Check

    DISASSEMBLY/REASSEMBLY VIII Piston protrusion check To calculate the right thickness for the gasket, the protrusion between the piston and the cylinder head surface must be measured. Use a dial indicator with base plate. Reset to zero while resting on a surface plate, then position against the cylinder head base plane as shown in the diagram, so that the dial indicator rod rests against the piston.

  • Page 36: Connecting Rod

    When remounting, mount the cap from the same side as in C of the figure. Tighten the 15 LD 225 bolts to a 23 Nm torque value. Tighten the bolts to a 30 Nm torque value for 15 LD 315-350-400-440.

  • Page 37: Drive Shaft Oil Seals

    A warped oil retainer may allow the introduction of air into the engine thus causing crankcase ventilation problems. Use genuine oil retainers with the LOMBARDINI logo (see B). Drive shaft oil seals Oil retainer 1 is located in the gear cover on the timing side while retainer 2 is located in the crankcase on the flywheel side.

  • Page 38: Availability Of Bearings

    VIII DISASSEMBLY/REASSEMBLY Crankshaft - journal diameter (mm) ÷ ÷ ÷ ÷ ÷ ÷ ÷ ÷ ÷ ÷ ÷ ÷ ÷ ÷ ÷ ÷ ÷ ÷ The undersizes for the crankpin and main journal are 0.25, 0.50 and 1 mm. The gears must be mounted with the right tools so that they can be correctly timed.

  • Page 39: Cam Height (Mm)

    DISASSEMBLY/REASSEMBLY VIII Camshaft Components: 1 Journal, gear cover on timing side 2 Gear 3 Exhaust lobe 4 Injection lobe 5 Fuel pump eccentric 6 Intake lobe 7 Journal, crankcase side Camshaft journals and bore Use a comparator for interiors Dimensions of camshaft journals and bore (mm) ÷...

  • Page 40: Camshaft - Antireverse System

    VIII DISASSEMBLY/REASSEMBLY Camshaft timing Fit camshaft by aligning marks' A with mark D on the crankshaft. Camshaft – Antireverse system 15 LD 400-440 it consists of a device on the camshaft which lifts the intake valve in case of a startup in reverse direction with respect to normal rotation.

  • Page 41: Automatic Decompression

    DISASSEMBLY/REASSEMBLY VIII Automatic decompression With the engine at a standstill and up to a rate of about 300 RPM, spring 1, acting on weights 2 and 3 via lever 4 and pin 5, keeps the exhaust valve open during the compression phase also. Once the engine exceeds the 300 RPM rate, weights 1 and 2 keep pin 5 in the hold position owing to the action of the centrifugal force.
  • Page 42 NOTE VIII COMPILER TECO/ATI REG. CODE MODEL N° DATE OF ISSUE DATE ENDORSED REVISION 1-5302-467 50707 06-95 22.12.2003...

  • Page 43: Dinamic Balancer Timing

    VIII DISASSEMBLY/REASSEMBLY Dinamic balancer timing Position crankshaft as shown in the figure. Introduce the dynamic balancer so that timing mark 1 engages between teeth 2 of the crankshaft gear. Valve timing check Remove the tank and conveyor to access the flywheel. Carry out the inspections on the drive shaft.

  • Page 44: Timing Angles For Inspection (0.65-0.70 Valve Play)

    DISASSEMBLY/REASSEMBLY VIII Timing angles for operation (0.15 valve play). For 15 LD 225 α α α α α = 6° before A corresponding to 12 mm β β β β β = 22° after B corresponding to 44 mm γ γ γ γ γ...

  • Page 45: Refitting Gear Cover On Timing Side

    VIII DISASSEMBLY/REASSEMBLY Speed governor Components: 1 Spool spacer 2 Spool 3 Weights 4 Spool guide 5 Gear 6 Oil pump driving shaft 7 Circlip 8 Thrust ring Speed governor removal Spool guide 1 has retainers one end which prevent spool 2 from slipping out.

  • Page 46: Lubrication System

    If contact with the oil is unavoidable, you are advised to wash your hands with soap and water as soon as possible. Dispose of old oil in the correct way as it is highly polluting. 15 LD 225 - 315 - 350 LUBRICATION SYSTEM AND BREATHER RECIRCULATION SYSTEM...

  • Page 47: Ld 400-440 Lubrication System

    LUBRICATION SYSTEM 15 LD 400-440 LUBRICATION SYSTEM AND BREATHER RECIRCULATION SYSTEM Components: 1) Oil fill cap 6) Oil drain plug 11) Oil intake filter 2) Safety valve 7) Metal filter element 12) Pushrods 3) Rod journal 8) Main journal 13) Hydraulic tappets 4) Pressure control valve 9) Oil filter 14) Calibrated union...

  • Page 48: Internal Strainer

    Components for 15 LD 315 and 15 LD 350: 1 Spring 2 Valve 3 Plug Free length A of the spring is 27.50-27.75 mm. Components for 15 LD 225: 4 Ball 5 Spring 6 Plug Free length A of the spring is 23.50-24.50 mm.

  • Page 49: Calibrated

    E = 8.5 Characteristics: Useful filtering area = 75 cm Degree of filtration = 50 µm. The by-pass valve is set at 0.6-0.8 bar. Filter components: 15 LD 225 7 Rubber pad 8 Upper cover 9 Filter element 10 Lower cover Dimension mm: A = 19.0-19.3 B = 12.5...

  • Page 50: Oil Pressure Curve At Full Speed

    LUBRICATION SYSTEM Oil pressure curve at idle speed The curve is obtained at the oil filter port with engine running at a constant speed of 1200 r.p.m. in no-load conditions; pressure is given in bar and temperature in centigrades. The curve represents the minimum pressure value while the maximum value is 5 bar.

  • Page 51: Fuelling/Injection Circuit For 15 Ld 315-350-400-440

    FUEL SYSTEM Fuelling/injection circuit for 15 LD 315-350-400-440 Components: 1 Tank 2 Return tube 3 Fuel filter 4 Injection pump 5 Injector leak-off line 6 Injector 7 High pressure line 8 Return tube Fuelling/injection circuit for 15LD 225 1 Tank 2 Injector leak-off line 3 Injector 4 High pressure line...

  • Page 52: Xfuel System

    FUEL SYSTEM Fuel filter 15 LD 225-315-350-400-440 A = 7.3 B = 3.8 C = 1.5 D = 42 H = 75 Characteristics: Filtering area ≥ 390 cm² Filtration level ≤ 7 µm See page 18 for fuel filter replacement...

  • Page 53: Fuel Pump, Drive Rod Protrusion

    Check while eccentric 4 is at rest (lowest point of travel). Protrusion A of drive rod 3 is 1.5-1.9 mm; it is not adjustable. Drive rod length = 58-58.2 mm for 15 LD 225 Drive rod length = 65.8-66.0 mm for 15 LD 315/350 Drive rod length = 61,4÷61,6 mm for 15 LD 400/440...

  • Page 54: Injection Pump Components And Disassembly

    The volume shifted by delivery valve 5 is 15 mm in the pump of 15 LD 315-350 and 25 mm³ in the pump of 15 LD 225 is 21 mm in the pump of 15 LD 400/440...

  • Page 55: Injection Pump Non-Return Valve

    FUEL SYSTEM Injection pump non-return valve The exhaust union has a non-return valve A. The purpose of this 15 LD valve is to improve the injection phase by expelling the air in the fuel 225-315-350 and preventing it from being sucked in by the pump during the intake phase.

  • Page 56: Injection Pump Delivery Check On Test Bench

    FUEL SYSTEM Injection pump delivery check on test bench 1 Delivery control rack rod 2 Rack rod 1 in stop position 3 Rack rod 1 in max. delivery position A = 18-19 mm (max.rack rod stroke) α α α α α = 66° Static injection timing Disconnect pipe 1 from injection pump and close it, to avoid fuel leakages.

  • Page 57: References On The Flywheel

    FUEL SYSTEM Static injection lead test on flywheel Fill the tank and make sure that the fuel is not more than 10-15 cm above the tester. Set the flow governor lever of the injection pump in the stop position and lock it there. Turn the flywheel in the engine rotation direction.

  • Page 58: Injection Advance Adjustment

    FUEL SYSTEM Injection advance adjustment Injection advance beyond the thickness of gasket A is determined by the thickness of the pad inside the injection tappet. To alter the value of injection advance the pad must be replaced with another of a suitable thickness (see fig. 117-118). To extract pad B, use a rod with a suction cap or magnet at one end.

  • Page 59: Injector Calibration

    FUEL SYSTEM Nozzles The set-up between the needle and the guide must leave the needle free to fall and merely as a result of its own weight, when lifted 7mm from its seat and rotated in different directions, with the nozzle kept at a 45°...
  • Page 60 NOTE COMPILER TECO/ATI REG. CODE MODEL N° DATE OF ISSUE DATE ENDORSED REVISION 1-5302-467 50707 06-95 22.12.2003...
  • Page 61 6 Oil pressure light 7 Key switch 8 Battery charging light Note: The battery, which is not supplied by LOMBARDINI, should have 12V nominal voltage rating and a capacity of not less than 44 Ah / 210 Amp. of fast discharge intensity.
  • Page 62 ELECTRICAL SYSTEM 24V, 9A alternator battery recharging curve 12V, 30A alternator battery recharging curve The test was conducted after heat stabilizing at 20°C. The value of the current delivered in relation to the curve may be subjected to a variation of between +10 % and -5%. Voltage regulator 12V, 12A: for standard alternators with 3 output wires 12V, 30A: for 12V, 20A alternators with 2 output wires...

  • Page 63: Electrical System

    5 Pressure switch 6 Solenoid valve 7 Ignition switch Note: The battery, which is not supplied by LOMBARDINI, should have 12V nominal voltage rating and a capacity of not less than 44 Ah / 210 Amp. of fast discharge intensity.
  • Page 64 ELECTRICAL SYSTEM Diagram of electric starter motor protection with sole self- winding starter - without battery - (optional) Components: 1 Alternator 2 Solenoid valve 3 Pressure switch 4 Thermostat 5 A.c. motor stop device COMPILER TECO/ATI REG. CODE MODEL N° DATE OF ISSUE DATE ENDORSED...
  • Page 65 Starting motor Bosch type DW (L) 12V, 1.1 KW for 15 LD 315-350-400-440 Bosch type DW (L) 12V, 0.9 KW for 15 LD 225 Anti-clockwise rotation direction (viewed from pinion side) A = 17.5-19.5 mm (distance from flywheel rim surface to starter motor flange surface) Note: Contact Bosch service centers for repair operations.
  • Page 66 ELECTRICAL SYSTEM Characteristic curves of Bosch starter motor type DW (L) 12V, 0.9 kW The curves were measured at a temperature of -20°C with a 55 Ah battery. U = Voltage on motor terminals in Volts. n = Motor speed in rpm M = Torque in Nm I (A) = Power draw in Amperes.
  • Page 67 SETTINGS / ADJUSTMENTS ADJUSTMENTS - 15 LD 315-350 Idling speed setting in no-load conditions (standard) After filling with oil and fuel, start the engine and let it warm up for 10 minutes. Adjust idling speed to 1000-1250 rpm by turning set screw 1; then tighten lock nut.
  • Page 68 SETTINGS / ADJUSTMENTS ADJUSTMENTS - 15 LD 225-400-440 No-load idling adjustment (standard) After having filled the engine with oil and fuel, start it and allow it to warm up for 10 minutes. Using adjuster screw 1, regulate the idling rate at 1000-1250 rpm.
  • Page 69 SETTINGS / ADJUSTMENT Injection pump delivery setting 1) Bring engine to idling speed 2) Unscrew delivery limiting device C ( see fig. 145) 3) Bring the engine to the power and rpm required by the manufacturer of the device. 4) Check that fuel consumption falls within the table specifications (see below).
  • Page 70 STORAGE XIII Storage Prepare engines as follows for storage over 30 days Temporary protection (1/6 months) • • • • • Let engine run at idling speed in no-load conditions for 15 minutes. • • • • • Fill crankcase with protection oil MIL-1-644-P9 and let engine run at 3/4 full speed for 5/10 minutes.

  • Page 71: Torque Specifications

    TORQUE SPECIFICATIONS MAIN TORQUE SPECIFICATIONS Reference ( fig. Diam. and pitch Torque Torque ( Nm ) Torque ( Nm ) POSITION N° and page) ( mm ) ( Nm ) 225 315-350 400-440 Re-coil starting fig. 18 - p. 25 Connecting rod 8x1 (315-350) fig.
  • Page 72 TORQUE SPECIFICATIONS STANDARD BOLT TORQUE SPECIFICATIONS STANDARD BOLT TORQUE SPECIFICATIONS DESCRIPTION R ≥ ≥ ≥ ≥ ≥ 1000 N/mm R ≥ ≥ ≥ ≥ ≥ 1200 N/mm R ≥ ≥ ≥ ≥ ≥ 800 N/mm Diameter per pitch (mm) 4x0,70 0,37 0,52 0,62...
  • Page 73 COMPILER TECO/ATI REG. CODE MODEL N° DATE OF ISSUE DATE ENDORSED REVISION 1-5302-467 50707 06-95 22.12.2003...
