SOFTWARE ADJUSTMENT (continued)
ADJUSTMENT
VOR OFF 1
(IC-A24 only)
[ ]
VOR PHASE 1
(IC-A24 only)
[ ]
Finished. Turn off the radio.
*This output level of a standard signal generator (SSG) is indicated as SSG's open circuit.
ADJUSTMENT CONDITION
• Operating frequency: 108.000 MHz
• Connect a VOR tester to the antenna connector and set
as:
Level : –90 dBm* (7.1 µV)
Modulation : 9960 Hz, 10%
30 Hz, 30%
Bearing : 0°
• Receiving
• Operating frequency: 108.000 MHz
• Connect a VOR tester to the antenna connector and set
as:
Level : –60 dBm* (220 µV)
Modulation : 9960 Hz, 30%
30 Hz, 30%
Bearing : 0°
• Receiving
• Push [ENT] key.
• Push [ENT] key.
