Bbq07E Parts List - Traeger BBQ07E Owner's Manual

Item Qty
2 1 Grill Frame Assembly
K 2 Washer .300 x .600 Zinc
20 1 Hopper Burner Assembly
22 1 Burner Box Assembly
30 1 Auger Assembly 070, 07E
35 1 Auger Tube Bushing
36 1 Auger Drive Motor
37 1 Screw 6-32 x .750 Socket Hd
38 1 Nut 6-32 Nylock Zinc
39 1 Screw 8-32 x .375 S-tap
40 1 Firepot Assembly
46 1 Hot Rod (Ignitor)
47 8 Screw #8 x .5 Hex S-Tap
48 1 3/8 x 3/16 Thick Gasket
49 1 Draft Inducer Fan Assy
50 1 Power Cord 8' Nema 120v
51 1 Strain Relief
61 1 Hopper Lid Assembly
66 2 Nut 8-32 K-Lock Zinc
67 2 Screw 8-32 x .25 PPHD Zinc
68 4 Screw 6-32 x .375 S-Tap
69 1 DIGITAL CONTROL W/SDC
70 2 Screw 6-32 x .375 S-Tap
71 1 7" RTD Sensor
80 1 Door Assembly Bronze 07E
91 4 Screw 8-32 x .5 PH Truss Zinc
99 2 Caster Leg 07E, 075
101 2 Square Leg Insert

BBQ07E PARTS LIST

Description
SUB052
HDW271
SUB110
SUB002
SUB005
BRN109
BRN100
HDW116
HDW112
HDW114
FAB310
BAC199
HDW119
BRN900
FAN209
ELE203
ELE210
SUB167
HDW108
HDW079
HDW115
BAC283
HDW115
BAC194
SUB178
HDW117
FAB020
HDW303
P/N Item Qty
102 2
104 2
106 2
107 2
108 2
109 2
112 1
113 1
119 1 Chimney Cap Assembly Bronze
126 1
B 2
F 8
A 8
C 8
G 8
E 16
J 2
140 1
141 1
143 1
147 1
152 1
153 1
D 2
Description
3" Caster W/O Brake
Wheel Leg
6" Vipor Wheel
Shoulder Bolt 3/8-16 Thread
Washer 5/16 Flat Zinc
Nut 3/8-16 Acorn
Grease Bucket
Flue Pipe Assembly
Flue Pipe Gasket
Bolt 1/4-20 x .47 Hex Head
Washer 1/4 Flat Zinc
Bolt 5/16-18 Socket Black
Nut 5/16-18 Hex Black
Washer 5/16 Lock Black
Washer 5/16 Flat Black
Bolt 1/4-20 x .310 Hex Zinc
Heat Baffle
Drain Pan
12" Chrome Handle
Porcelain Grill
Burner Gasket
Hopper Top Level Assembly
Nut 1/4-20 Hex
P/N
HDW301
FAB019
HDW300
HDW131
HDW120
HDW132
HDW152
FAB309
SUB150
INS145
HDW088
HDW130
HDW005
HDW006
HDW008
HDW007
HDW088
BCA012
BCA070
HDW227
HDW195
INS144
SUB177
Hdw123
