Congratulations! You have just purchased one of the latest in a
long line of exceptional car audio products from Stillwater Designs.
Your KICKER Midbass drivers were designed and engineered by the
same team which created many other international award winning
KICKER products like the Solo-Baric
ers. It contains a number of cutting-edge features to give you out-
standing performance and dependability. Thanks for buying KICKER.
Enjoy.
NEW FOR 2002!
•Ultra Slim Midbass Drivers Gives you real low frequency output from factory loca-
tions.
•CIMP (Curvilinear Injection-Molded Polygraphite) Woofer Cones For smooth
extended frequency response.
•Santoprene Surround Tough, flexible surround with long throw, to control extreme
cone excursions.
•Blackened Motor Structure and Kapton™ Voice Coil Formers For exceptional
thermal power handling capability.
•SSD (Spun Spoke Design) Enhances the cosmetics and provides a solid anti-resonant
foundation for the motor assembly.
•Spring Loaded Nickel Plated Terminals For solid connections with large gauge
speaker wire.
MODEL
Frequency
Response
RMB 6
30-500
RMB 8
30-500
Available in 4 ohm models only.
RMB6 / RMB8
Features
Specifications
Power
Cut Out
Peak / RMS
(in. / cm)
5 5/8 / 14.29
250 / 125
350 / 175
7 1/4 / 18.42
fi
, Comp VR and Resolution driv-
Mounting Depth
(in. / cm)
2 / 5.08
2 1/4 / 5.8
Sensitivity
(1 W / 1 M)
88
89
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Kicker RMB6
Summary of Contents for Kicker RMB6
- Page 1 Congratulations! You have just purchased one of the latest in a long line of exceptional car audio products from Stillwater Designs. Your KICKER Midbass drivers were designed and engineered by the same team which created many other international award winning KICKER products like the Solo-Baric ers.
- Page 2 Installation Instructions Your KICKER drivers are specifically designed for mounting in free-air applica- tions. While the speakers do not require a sealed enclosure for optimum per- formance, it is important to isolate the sound coming off the front of the driver from the sound radiating from the back of the driver.
- Page 3 (OPTIONAL PASSIVE CROSSOVER COMPONENTS) If you have more questions about the installation of your KICKER component, see the Authorized KICKER Dealer where you made your purchase. You may con- tact us via the Technical Services page on www.kicker.com. or call our Technical...
- Page 4 (1) year from date of original purchase from an Authorized Kicker Dealer, unless this product is labeled “B Stock”, in which case it is warranted for ninety (90) days from date of purchase. Should service be necessary under this warranty for any reason due to manufacturing defect or malfunction during the warranty period, Stillwater Designs will replace or repair (at its discretion) the defective merchandise with equivalent merchandise at no charge.
