Sharp LC-42XL2S Service Manual page 41

LC-42XL2E/S/RU, LC-46XL2E/S/RU, LC-46X20E/S/RU, LC-52XL2E/S/RU, LC-52X20E/S/RU
20.Remove all the connectors from PWBs.
To Main PWB
To Main PWB
Wire "US"
Wire "HM"
Wire
Wire
Wire "US"
Wire
Wire "VD"
Wire "RA","US","KM" to WH
Wire "HM"
Wire "HM" to WH
Wire "LW"
#Shape Wire "US"
like this
Wire "KM"
Wire "RA"
Wire "LW"
#No shape Wire "LA1" to WH
Wire "LA1"
2 – 24
Wire "LW"
#Don't make mistake Wire "VD" and "RA"
Wire "RA"
Wire "VD"
Wire "VD" to WH
Wire "RA","US","KM","VD" to WH
To LED PWB
To LCD Control PWB
Wire "LA1"
