Sharp LC-42XL2S Service Manual page 243

LC-42XL2E/S/RU, LC-46XL2E/S/RU, LC-46X20E/S/RU, LC-52XL2E/S/RU, LC-52X20E/S/RU
NO. PARTS CODE
[9] CABINET PARTS (LC-42XL2E/S/RU)
67
PSPAZB613WJKZ
68
PSPAZB614WJKZ
69
XBBS740P08000
70
XBBS830P06000
71
XBPS730P04WS0
72
XJPS730P08WS0
73
GCOVAC356WJ1A
74
LX-BZA170WJF9
75
LX-HZA003WJFN
76
PCOVZA105WJKZ
77
PSHEPA541WJZZ
78
PSHEPA543WJZZ
79
QCNW-G022WJQZ
80
RSP-ZA261WJZZ
81
RSP-ZA262WJZZ
82
TLABZB616WJZZ
82
TLABZB618WJZZ
83
TLABZB672WJZZ
84
XBPS740P10JS0
85
XEBS930P10000
86
XEBS940P16000
87
PSPAHB311WJZZ
88
TLABNC117WJZZ
89
LX-BZA214WJ00
90
LHLDWA164WJKZ
91
LHLDWA186WJKZ
PRICE NEW
PART
RANK MARK
DELIVERY
Sheet (12x12x2.5), x3
N P
Sheet (30x30x1.5)
N P
Screw (for Center Ang), x14
AA J
Screw (Mini Av,Tay,Ctl), x15
AA J
Screw (for Heatsink), x4
AA J
AA J Screw (Mini Av,Shild), x11
Side AV Cover
N P
Screw (for Rear Cabinet), x2
P
Screw (for SP), x2
AC J
CI Card Cover
N P
Terminal Sheet
N P
Sheet for Boss, x2
N P
Connecting Cord (IL:LEDILLU)
N P
Speaker L
AY N P
Speaker R
AY N P
Pop Label A (LC-42XL2E/S)
N P
Pop Label A (LC-42XL2RU)
N P
Pop Label 42
N P
Screw (for Rear Cabinet), x8
P
Screw (for Bottom Cover), x1
AA J
AB J Screw (for Rear Cabinet), x15
N P Spacer
P Model Label
Screw, x1
Wire Holder
Wire Holder
N
31
DESCRIPTION
