21.5” LED TOUCH MONITOR Instruction Manual English Version 1.0 RETAIL INDUSTRY BUSINESS HOME BUSINESS OUTDOOR L22LET10B www.lorextechnology.com Copyright © 2012 Lorex Technology Inc. - Page 2 Thank you for purchasing this Lorex product. This manual refers to the following models: • L22LET10B To learn more about this product and to learn about our complete range of accessory products, please visit our website at: www.lorextechnology.com CAUTION...
-
Page 3: Need Help
Customer Care (for warranty and accessory sales) customerservice@lorexcorp.com Customer Feedback info@lorexcorp.com By Phone: North America: Customer Service: 1-888-425-6739 (1-888-42-LOREX) Tech Support: 1-877-755-6739 (1-877-75-LOREX) Mexico: 1-800-514-6739 International: +800-425-6739-0 (Example: From the UK, dial 00 instead of +) M a y 5 201 1 - R11... -
Page 4: Necesita Ayuda
NO DEVUELVA ESTE PRODUCTO A LA TIENDA NE RETOURNEZ PAS CE PRODUIT AU MAGASIN Cerciórese de por favor colocar su producto en www. Veuillez veiller à enregistrer votre produit à www.lorex- lorexcctv.com/registration para recibir actualizacio- cctv.com/registration pour recevoir des mises à jour et nes y la información del producto... - Page 5 B E F O R E Y O U S TA R T THIS PRODUCT MAY REQUIRE PROFESSIONAL INSTALLATION LOREX IS COMMITTED TO FULFILLING YOUR SECURITY NEEDS • We have developed user friendly products and documentation. Please read the Quick Start Guide and User Manual before you install this product.
- Page 6 ESTE PRODUCTO PUEDE EXIGIR UNA CE PRODUIT POURRAIT EXIGER UNE INSTALACIÓN PROFESIONAL INSTALLATION PROFESSIONNELLE LOREX S’ENGAGE À SATISFAIRE LOREX SE COMPROMETE A SATISFACER VOS BESOINS SÉCURITAIRES SUS NECESIDADES EN SEGURIDAD • Favor de leer la guía de instalación rápida y la •...
-
Page 7: Important Safeguards
Important Safeguards In addition to the careful attention devoted to quality standards in the manufacture process of your product, safety is a major factor in the design of every instrument. However, safety is your responsibility too. This sheet lists important information that will help to ensure your enjoyment and proper use of the product and accessory equipment. - Page 8 Installation (Continued) Service Ventilation Servicing - Slots and openings in the case are - Do not attempt to service this product provided for ventilation to ensure reliable operation of yourself, as opening or removing covers may expose the product and to protect it from overheating. These you to dangerous voltage or other hazards.
- Page 9 NOTICES FCC/IC Notice: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction, may cause harmful interference to radio communications.
- Page 10 viii...
-
Page 11: Table Of Contents
Table of Contents 1. Getting Started ....... . . 1 2. -
Page 13: Getting Started
Getting Started 1. Getting Started The system comes with the following components: 1 X MONITOR 1 X MONITOR STAND 1 X MONITOR STAND SCREW 1 X VGA CABLE 1 X POWER ADAPTER 1 X HDMI CABLE 1 X RCA CABLE 1 X USB CABLE INSTRUCTION MANUAL CHECK YOUR PACKAGE TO CONFIRM THAT YOU HAVE RECEIVED THE COMPLETE SYSTEM,... -
Page 14: Installing The Monitor Stand
Installing the Monitor Stand 2. Installing the Monitor Stand ATTENTION: Install the monitor stand before using the monitor. To install the monitor stand: Lay the monitor face on a clean, soft surface. Align the monitor stand to the base of the monitor. Tighten the monitor stand screw clockwise to secure the monitor stand. -
Page 15: Connecting The Monitor
3. Connecting the Monitor ATTENTION: To use the touch-screen features of this monitor, you must connect the included USB cable from the USB port on the monitor to a USB port on your Lorex touch-compatible DVR or PC. PCs must have Windows 7® to use the touch-screen features of this monitor. -
Page 16: Monitor Overview
Monitor Overview 4. Monitor Overview AUTO button: Press to automatically adjust the screen display settings. In the Menu, press to return to previous menu or exit the Menu. UP button: In the Menu, press to scroll up / left. DOWN button: In the Menu, press to scroll down / right. + button: Press to increase the volume of the built-in speakers. -
Page 17: Using The Menu
Using the Menu 5. Using the Menu Press the MENU button to open the Menu. The Menu opens to the sub-menu selection screen. Sub-menu selection screen • Press UP and DOWN to scroll through sub-menus and setting options. • Press MENU to select sub-menus and setting options. •... -
Page 18: Tracking
Using the Menu 5.3 Tracking Horizontal When the monitor is connected using VGA, press + to move the screen display area to the right or - to move left. Vertical When the monitor is connected using VGA, press + to move the screen display area up or - to move down. -
Page 19: Using The Vesa Mount Holes
This monitor features mounting holes for a 100mm x 100mm VESA mount and an independent stand. This allows you to mount a Lorex VESA-mountable DVR to the back of the monitor or to mount the monitor to a wall or ceiling using a compatible mounting bracket (not included). -
Page 20: Maintenance
524mm (L) x 365mm (W) X 191mm (D) Weight (approx.) 8.6lbs / 3.9kg As our products are subject to continuous improvement, Lorex Technology Inc. and its subsidiaries reserve the right to modify product design, specifications, and prices without notice and without incurring any obligation. E&OE... - Page 24 Enhance your security with genuine Lorex products and accessories. Order whatever you need at www.lorextechnology.com or call 1-888-42-LOREX (1-888-425-6739) Special offer Coupon: MLLLLDCG-CM-OOJICORN Parking Lot Office Restaurant Drive Way LBC6050 LNZ4001 LDC6050 CVC6950B PROTECT EVERYTHING Home Home Office THAT MATTERS Add wired or wireless cameras to expand the “Envelope of Protection”...
