Page 1: Instruction Manual
5” B&W Rear View Safety System Monitor Instruction Manual English Version 1.0 MODEL: MO453 www.lorexcctv.com © Copyright 2007 LOREX Technology Inc. - Page 2 Thank you for purchasing the Lorex 5” Black & White Rear View Safety Monitor. This monitor (when installed with MO453 Cameras) helps to prevent backing-up and parking accidents by allowing you to view or check on the traffic behind your vehicle, or when rounding corners (blind spot prevention).
-
Page 3: Fcc Class B Notice
4. Keep enough space around the unit for ventilation. Slots and openings in the storage cabinet should not be blocked 5. During lightning storms, or when the unit is not used for a long time, disconnect the power supply, antenna, and cables to protect the unit from electrical surge LOREX TECHNOLOGY INC. http://www.lorexcctv.com... -
Page 4: Table Of Contents
Connecting the Monitor Power ..............9 Full Connection Diagram ................9 System Specifications - Appendix #1 ............10 Lorex CVA453 Accessory Cables - Appendix #2........11 MO453 FEATURES • Automatic activation of camera when gear is shifted into reverse. • Built-in 2 Camera input. -
Page 5: Getting Started
Getting Started Getting Started The MO453 Rearview System comes with the following components: 5” B&W CRT Monitor Mounting Hardware and Brackets for Monitor and Camera Power cable and Harness Sunshade for Monitor CHECK YOUR PACKAGE TO CONFIRM THAT YOU HAVE RECEIVED THE COMPLETE SYSTEM, INCLUDING ALL COMPONENTS SHOWN ABOVE. -
Page 6: Mo453 - Front
RVMO453 - Front RVMO453 - Front 1. POWER SWITCH - Turns the monitor ON/OFF: • Press the power switch to turn the monitor ON. The green LED indicator will illuminate. • Press the power switch again to turn the monitor OFF (STANDBY MODE).The green LED indicator will extinguish. -
Page 7: Mo453 - Back
MO453 - Back MO453 - Back 1. CAMERA 1 / CAMERA 2 INPUTS - Allows 2 Cameras (4-Pin) to connect to the system. • Connect the provided camera to the first channel (C1). • An additional camera can be connected to C2 (not included). -
Page 8: Monitor Overview
Monitor Overview Monitor Overview Monitor Installation 1. Determine the location to mount the monitor. Install the monitor mounting bracket by placing the screw into the center hole. Rotate and adjust the bracket by turning it left and right for the best placement. -
Page 9: Connecting The Monitor Power
Connecting the Monitor Power Connecting the Monitor Power The diagram below outlines the connections for the power cable: NOTE: The Red wire with the fuse holder should be connected to vehicle ACC Terminal; the Brown wire to reverse gear relay; and the Black wire to the chassis ground. -
Page 10: System Specifications - Appendix #1
System Specifications - Appendix #1 System Specifications - Appendix #1 Picture Tube Black and White 7” Picture (measured diagonally) ° Deflection angle Picture Image Factory preset to reverse image Picture Resolution 600 TV Lines Power Connector Red: Positive 12V~32V Input Brown: Reverse Gear 12V ~ 32V input Black: Ground White: Dimmer... -
Page 11: Lorex Cva453 Accessory Cables - Appendix #2
Lorex CVA453 Accessory Cables - Appendix #2 Lorex CVA453 Accessory Cables - Appendix #2 Additional adapter cables are available for backward compatibility between the Lorex 452 Series and the Sentinel CCTV 452 Series Rear view systems. Adaptor Cable #1 - CA452 (Camera... - Page 12 It’s all on the web Product Information Specification Sheets User Manuals Software Upgrades Quick Start Guides Firmware Upgrades VISIT www.lorexcctv.com wwwlorexcctv.com Lorex Technology Inc.
