- Page 1 Viking Installation Guide ® Viking Range Corporation 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-VIKING1 (845-4641) or visit the Viking Web site at vikingrange.com Professional & Designer Freestanding 30” Electric Range F20508K EN (060712)
-
Page 2: Table Of Contents
Table of Contents IMPORTANT – Read and Follow! Your safety and the safety of others is Warnings & Important Safety Instructions _______________________________________________3 • Before beginning, please read these very important. Dimensions _________________________________________________________________________6 instructions completely and carefully. We have provided many important safety Specifications _______________________________________________________________________7 messages in this manual and on your Clearance Dimensions (Proximity to Cabinets) ___________________________________________8... - Page 3 To avoid risk of electrical shock, • Viking Range Corporation will NOT warranty any problems resulting from GFI outlets which personal injury or death; verify are not installed properly or do not meet the requirements below.
-
Page 4: Dimensions
Dimensions Specifications VESC/DSCE Electric 30” Range Description VESC530-4B DSCE130-4B - 7 / ( 7 5 8 ” Overall width 29-7/8” (75.9 cm) Overall height To top of glass frame 35-7/8” (91.1 cm) min. 37” (94.0 cm) max. Legs adjust 1-1/8” (2.9 cm) Overall depth from To end of side panel—24-5/16”... -
Page 5: Clearance Dimensions (Proximity To Cabinets)
Clearance Dimensions Clearance Dimensions (Proximity to Cabinets) (Wood/Composite Overlay) • This range may be installed directly CAUTION adjacent to existing 36” (91.4 cm) high To prevent possible damage to cabinets The bottom of a standard hood should be base cabinets. and cabinet finishes, use only materials 30”... -
Page 6: Electrical Requirements
Electrical Requirements General Information Electrical Requirements • Viking Range Corporation will NOT This product is manufactured with the warranty any problems resulting from GFI READ AND FOLLOW ALL WARNING outlets which are not installed properly or neutral terminal connected to the cabinet. -
Page 7: Installation
DANGER Leg Installation Installation CAUTION To avoid risk of personal injury or product damages, DO NOT use the handle or oven door to lift the oven. Remove door before installation to ensure that it is not used to lift the unit. DO NOT lift or carry the door by the handle. -
Page 8: Electrical Connection (3-Wire)
Electrical Connection (3-wire) Note: If you have a 4-wire connection, see following section for 4-wire connection instructions. WARNING WARNING Electrical shock hazard. Electrical shock hazard. To avoid risk or electrical To avoid risk of electrical shock, shock, personal injury or death; personal injury or death;... -
Page 9: Electrical Connection (4-Wire)
Electrical Connection (4-wire) WARNING WARNING Electrical shock hazard. Electrical shock hazard. To avoid risk or electrical To avoid risk of electrical shock, shock, personal injury or death; personal injury or death; verify grounding product to the frame your appliance has been of the unit may or may not be permitted properly grounded in accordance with through your local codes. -
Page 10: Leveling/Adjustments/Alignment
Leveling/Adjustments/Alignment Measure the four corners in cutout area to For uneven or sloped floors, level unit with Set the high corner of range so that the top of side trim is verify if flooring is level. metal shims only, as the adjustment required may 3/8”... -
Page 11: Final Installation
Anti-tip Device Installation Door Replacement and Adjustment (cont.) Reattach door to range. Open door completely. Reattach hinge trim. Attach bracket with mounting hardware provided. Final Installation Note: Refer to range electrical requirements section for proper installation information. Remove pins from hole in hinges. Close door. -
Page 12: Final Preparation
DO NOT use If buildup occurs, DO NOT use steel wool, a metal knife, spatula, or any other Contact Viking Range Corporation, 1-888-VIKING1 (845-4641), for the nearest service parts abrasive cloths, cleansers, or powders! material tool to scrape stainless steel!
