- Page 1 Viking Installation Guide Viking Range Corporation 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-VIKING1 (845-4641) or visit the Viking Web site at vikingrange.com Electric Ranges/Rangetops F1485L EN (021808J)
-
Page 2: General Information
• Before beginning, please read these instructions completely and carefully. • Do not remove permanently affixed labels, warnings, or plates from product. This may void the warranty. Description VERT301-4B DERT301-4B DERT361-5B • Please observe all local and national codes and ordinances. -
Page 3: Proximity To Side Cabinet Installation
SPECIFICATIONS - ELECTRIC RANGE PROXIMITY TO SIDE CABINET INSTALLATION 1. This rangetop may be installed directly adjacent to existing 36” (91.4 cm) high base cabinets. IMPORTANT: The Description VESC306-4B top grate support MUST be 3/8” (.95 cm) above the adjacent base cabinet countertop. Overall Width 29 7/8”... -
Page 4: Wood/Composite Overlay Installation
ELECTRICAL CONNECTION WOOD/COMPOSITE OVERLAY INSTALLATION (Including Custom Ventilator Installation) With the rangetop positioned in front of the cabinet opening, connect the wire leads extending from the conduit to the junction box, making sure the neutral The bottom of a standard hood should be 30” (76.2 cm) min to 36” (91.4 cm) max above the ceramic glass surface. (white) wire is connected to the appropriate terminal. -
Page 5: Range Installation
RANGE INSTALLATION PROXIMITY TO SIDE CABINET INSTALLATION 1. This range may be installed directly adjacent to existing 36” (91.4 cm) high base cabinets. IMPORTANT: The top Legs grate support MUST be 3/8” (.95 cm) above the adjacent base cabinet countertop. This may be accomplished by 1. -
Page 6: Wall Installation
WOOD/COMPOSITE OVERLAY INSTALLATION ELECTRICAL CONNECTION The bottom of a standard hood should 30” (76.2 cm) min to 36” (91.4 cm) max above the ceramic glass surface. This Use a 3-wire power supply cord kit rated for 60 amps - would typically result in the bottom of the hood being 66” (167.6 cm) to 72” (182.9 cm) above the floor. Refer to the 125/250 volts with closed loop terminals and marked for use rangehood installation instructions for additional information. - Page 7 When adjustments are required, contact your dealer/installer for corrections. If assistance is not available, contact 4. Feed line #1 (red 12 AWG/600v copper conductor), line #2 Viking Range Corporation Preferred Service for the nearest authorized service agent at (888) 845-4641. All corrections (black 12 AWG/600v copper conductor), neutral (white 14 to installation are the responsibility of the dealer/installer or end user.
-
Page 8: Performance Checklist
PERFORMANCE CHECKLIST The installer should carry out the following performance checks. Refer to instructions below. 1. Check top surface elements - glow red when turned on. 2. Check hot surface indicator lights - glow red when corresponding element is on. 3.
