PREMIER RAPIDFIRE™ LOG SPLITTER
SAFETY & OPERATING INSTRUCTIONS
Serial No.
Order No.
Read and understand this manual and all instructions before operating the DR PREMIER RAPIDFIRE LOG SPLITTER.
Original Language
DR Power Equipment
Toll-free phone: 1-800-DR-OWNER (376-9637)
Fax: 1-802-877-1213
Website: www.DRpower.com
Advertisement
Related Manuals for DR PREMIER RAPIDFIRE
Summary of Contents for DR PREMIER RAPIDFIRE
- Page 1 PREMIER RAPIDFIRE™ LOG SPLITTER SAFETY & OPERATING INSTRUCTIONS DR Power Equipment Toll-free phone: 1-800-DR-OWNER (376-9637) Serial No. Fax: 1-802-877-1213 Original Language Order No. Website: www.DRpower.com Read and understand this manual and all instructions before operating the DR PREMIER RAPIDFIRE LOG SPLITTER.
-
Page 2: Table Of Contents
Additional Information and Potential Changes DR Power Equipment reserves the right to discontinue, change, and improve its products at any time without notice or obligation to the purchaser. The descriptions and specifications contained in this manual were in effect at printing. Equipment described within this manual may be optional. -
Page 3: Chapter 1: General Safety Rules
Labels Your DR PREMIER RAPIDFIRE LOG SPLITTER carries prominent labels as reminders for its proper and safe use. Shown below are copies of all the Safety and Information labels that appear on the equipment. Take a moment to study them and make a note of their location on your LOG SPLITTER as you set up and before you operate the unit. - Page 4 Allow the engine to cool completely before storing in any enclosure. Never store a machine that has gas in the tank, or a fuel container, near an open flame or spark such as a water heater, space heater, clothes dryer or furnace. ® PREMIER RAPIDFIRE™ LOG SPLITTER...
- Page 5 Never open the switch box or motor cover. Never attempt any electrical repairs yourself. If in doubt, consult a qualified electrician, visit our website at www.DRpower.com or contact DR Power Equipment for toll-free support at: 1-800-dr-owner (376-9637) for help or information.
- Page 6 Under California law, and the laws of some other states, you are not permitted to operate an internal combustion engine using hydrocarbon fuels without an engine spark arrester. This also applies to operation on US Forest Lands. All DR PREMIER RAPIDFIRE LOG SPLITTERS shipped to California, New Mexico and Washington State are provided with spark arresters.
-
Page 7: Chapter 2: Setting Up The Dr Premier Rapidfire Log Splitter
Chapter 2: Setting Up The DR PREMIER RAPIDFIRE LOG SPLITTER It may be helpful to familiarize yourself with the controls and features of your DR PREMIER RAPIDFIRE LOG SPLITTER as shown in Figure 1 before beginning these procedures. If you have any questions at all, please feel free to contact us at www.DRpower.com. - Page 8 *The diameter listed is indicative of the maximum suggested size - a small log can be difficult to split when it contains knots or a particularly tough fiber. On the other hand, it may not be difficult to split logs with regular fibers even if its diameter exceeds the maximum indicated above. Assembling the DR PREMIER RAPIDFIRE LOG SPLITTER Tools needed: ...
- Page 9 1. Support the Beam with a Jack Stand or equivalent so the front of the Beam is Carriage Bolt high enough to install the Frame Stand (Figure 3). and Locknut 2. Secure the Support Leg to the Beam with four Carriage Bolts and Locknuts Beam using a 9/16"...
- Page 10 4. Install the Table to the Tray Mounts with four Carriage Bolts and Locknuts using a 9/16" Wrench (Figure 9). Bolts and Locknuts Carriage Bolt and Locknut Tray Mount Figure 7 Tray Mounts Table Beam Figure 9 Bolt, Lock Washer and Flat Washer Figure 8 ® PREMIER RAPIDFIRE™ LOG SPLITTER...
- Page 11 5. Install the Tray Bracket to the Frame Stand with four Carriage Bolts and Locknuts using two 9/16" Wrenches (Figure 10). 6. Install the Frame Stand onto the Tray with four Bolts, Flat Washers and Locknuts (Figure 11). Adding Oil and Gasoline (gas engine model) Tray Bracket Engine Oil See Engine Manual for specific Engine capacities and...
- Page 12 3. If the pressure is too low, add air through the Valve Stem with an air hose. Protective 4. Replace the Valve Stem Protective Cap when finished. Figure 14 Do not over inflate the tires. Inflate to the manufacturers recommended pressure found on the tires. ® PREMIER RAPIDFIRE™ LOG SPLITTER...
-
Page 13: Chapter 3: Operating The Dr Premier Rapidfire Log Splitter
Read and understand all instructions, safety precautions, and/or warnings listed in “Chapter 1 General Safety Rules” before operating this DR PREMIER RAPIDFIRE LOG SPLITTER. If any doubt or question arises about the correct or safe method of performing anything found in this manual, please contact our Customer Service Representatives at our toll free number: 1-800-DR-OWNER (376-9637). - Page 14 Make sure both ends of the log you are splitting are cut as square as possible. This will prevent the log from sliding out of position while under pressure (Figure 20). Figure 19 Figure 20 ® PREMIER RAPIDFIRE™ LOG SPLITTER...
- Page 15 1. Place the log on the Log Splitter. Grasp the log on the sides near the middle of the block (Figure 21). Center the log, side-to-side, on the rail of the Log Hands Splitter, making sure that one end is against the Splitting Wedge. on Sides of Wood ...
-
Page 16: Chapter 4: Maintaining The Dr Premier Rapidfire Log Splitter
Chapter 4: Maintaining The DR PREMIER RAPIDFIRE LOG SPLITTER Regular maintenance is the way to ensure the best performance and long life of your machine. Please refer to this manual and the engine manufacturer's owner's manual for maintenance procedures. Service intervals listed in the checklist below supersede those listed in the engine manufacturer's owner's manual. - Page 17 Short Flange Bolts 3. Remove the four short Flange Bolts and Locknuts that secure the right side Guard to the Frame using a 9/16" Socket and Ratchet to remove the right side Guard from the Splitter (Figure 24). 4. Grease the Engagement Lever Grease Fittings from the front of the machine with a few pumps of All Purpose Grease (Figure 25).
- Page 18 5. Pivot the Mount up slightly and remove the Belt (Figure 33). Left Side Guard Short Long Flange Flange Bolts Bolt Figure 31 Loosen Belt Flywheel Belt Pulley Figure 33 Engine Tighten Angle Mount Belt Setting Pivot Bolts Bolts Figure 32 ® PREMIER RAPIDFIRE™ LOG SPLITTER...
- Page 19 Note: The weight of the Engine should be enough to tension the Belts properly but Safety Interlock Lever Short depending on hardware looseness and cleanliness of Engine Mount pivot Flange area, you may need to push down slightly to aid in proper tension. The Belt Bolts performs best with a slight amount of slack to allow for some slippage when the Wedge encounters a tough log.
- Page 20 Splitter. Short Flange Bolts Figure 39 Vertical Position Over Center Forward Stop Position Adjustment Handle Yoke Steel Bushing Jam Nuts Pinion Rack Stop Bolts Back of Yoke Figure 40 Figure 41 ® PREMIER RAPIDFIRE™ LOG SPLITTER...
- Page 21 When using the Splitter for the first time after this adjustment, split smaller diameter logs with no knots to verify that the adjustments are correct before trying larger diameter tougher logs. If you have any questions please contact us at www.DRpower.com or call 1-800-DR-OWNER (376-9637) for assistance. Replacing the Wheels Tools and Supplies needed: ...
-
Page 22: Chapter 5: Troubleshooting
Most problems are easy to fix. Consult the Troubleshooting Table below for common problems and their solutions. If you continue to experience problems, contact us at www.DRpower.com or call toll-free 1-800-DR-OWNER (376-9637) for support. Before performing any maintenance procedure or inspection, stop the engine, wait five minutes to allow all parts to cool. - Page 23 If the above causes are not the problem, a circuit breaker might need to be reset; Reset Circuit Breaker. If the Motor still does not run, visit our website at www.DRPower.com or call 1-800-DR- OWNER (376-9637) for assistance.
-
Page 24: Chapter 6: Parts Lists And Schematic Diagrams
Chapter 6: Parts Lists and Schematic Diagrams Parts List – FRAME STAND AND GUARD ASSEMBLY NOTE: Part numbers listed are available through DR Power Equipment. Ref# Part# Description Ref# Part# Description 34497 Stand, Frame 34496 Cradle 35178 Guard, RH, With Labels 33350 Bolt, Hex, Flange, 3/8-16 X 2"... - Page 25 Schematic – FRAME STAND AND GUARD ASSEMBLY CONTACT US AT www.DRpower.com...
- Page 26 Parts List – DRIVE ASSEMBLY NOTE: Part numbers listed are available through DR Power Equipment. Ref# Part# Description Ref# Part# Description 34493 Mount, Engine 32122 Washer, 5/16" ID, 2.0" OD, 0.13" t 34500 Guard, Belt 34491 Gear, Pinion 34507 Engine, 3.5tq, 100cc, Rato, Ms, W/ 29494 Key, Square, 3/8"...
- Page 27 Schematic – DRIVE ASSEMBLY CONTACT US AT www.DRpower.com...
- Page 28 Parts List – FRAME AND AXLE ASSEMBLY NOTE: Part numbers listed are available through DR Power Equipment. Ref# Part# Description Ref# Part# Description 35176 Frame, Main, With Labels 33349 Bolt, Hex, Flange, 1/2-13 X 5" 34494 Axle 34511 Bolt, Hex, Flange, 1/2-13 X 3", GR5, ZP...
- Page 29 Schematic – FRAME AND AXLE ASSEMBLY CONTACT US AT www.DRpower.com...
- Page 30 Parts List – TRAY KIT ASSEMBLY NOTE: Part numbers listed are available through DR Power Equipment. Ref# Part# Description Ref# Part# Description 31363 Table, Log 32104 Bolt, Carriage, 3/8-16 X 1", GR5, ZP 34503 Bracket, Log Table 15043 Bolt, HHCS, 3/8-16 X 1-1/4", GR5...
- Page 31 Notes: CONTACT US AT www.DRpower.com...
- Page 32 If your DR PREMIER RAPIDFIRE LOG SPLITTER will be idle for more than 30 days, we recommend using a gas stabilizer. This will prevent sediment from gumming up the Carburetor. If there is dirt or moisture in the gas or Tank, remove it by draining the Tank.
