HORIZONTAL-VERTICAL LOG SPLITTER
SAFETY & OPERATING INSTRUCTIONS
Model:
Premier 25T
Pro 28T
Pro XL 34T
Serial No.
Order No.
READ AND SAVE THIS MANUAL. This manual contains important safety precautions which should be read and understood before operating the product. Failure to
do so could result in serious injury. This manual should remain with the product.
Specifications, descriptions, and illustrations in this manual are as accurate as known at the time of publication, but are subject to change without notice.
DR Power Equipment
Toll-free phone: 1-800-DR-OWNER (376-
9637)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Premier 25T and is the answer not in the manual?

Questions and answers

Related Manuals for DR Premier 25T

Summary of Contents for DR Premier 25T

  • Page 1 Pro 28T Pro XL 34T DR Power Equipment Serial No. Toll-free phone: 1-800-DR-OWNER (376- Order No. 9637) READ AND SAVE THIS MANUAL. This manual contains important safety precautions which should be read and understood before operating the product. Failure to do so could result in serious injury.

  • Page 2: Table Of Contents

    LOG SPLITTER TABLE OF CONTENTS TABLE OF CONTENTS Maintenance .......... 22 Cleaning the Log splitter ..........22 Introduction ..........3 Changing the Engine Oil ..........22 Safety Definitions ........3 Cleaning and Adjusting the Spark Plug(s) ....... 22 Cleaning the Air Filter ............. 23 Important Safety Instructions ....

  • Page 3: Introduction

    We want you to continue to use NOTICE and be satisfied with your DR product for years to come. NOTICE indicates information considered important, but not hazard-related (e.g., messages relating to property damage).

  • Page 4: Important Safety Instructions

    LOG SPLITTER IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS WARNING ⚠ CALIFORNIA WARNING Operation of this equipment may create sparks that can start fires around dry vegetation. Can expose you to benzene, a carcinogen and reproductive A spark arrestor may be required. The operator should contact toxicant –...
  • Page 5 IMPORTANT SAFETY INSTRUCTIONS LOG SPLITTER WARNING CAUTION Before removing the pin installed into the front support leg Improper treatment or use of the log splitter can damage it, make sure hitch is installed onto vehicle. Releasing the pin shorten its life and void your warranty. before will cause support leg to slide up and possibly cause Use the log splitter only for intended uses.

  • Page 6: Fuel Safety

    LOG SPLITTER IMPORTANT SAFETY INSTRUCTIONS Fuel Safety When transporting or servicing the log splitter: Make certain that the fuel valve is in the OFF position, the gasoline DANGER tank is empty. Disconnect the spark plug wire. GASOLINE AND GASOLINE VAPORS ARE HIGHLY FLAMMABLE AND EXPLOSIVE.

  • Page 7: Preparation

    IMPORTANT SAFETY INSTRUCTIONS LOG SPLITTER 8. Keep the operator zone and adjacent area clear for safe, 3. Never leave the machine unattended with the power source secure footing. operating. 9. If your log splitter is equipped with an internal-combustion 4. Never operate the machine when under the influence of engine and intended for use near any unimproved forest, alcohol, drugs, or medication.
  • Page 8 LOG SPLITTER IMPORTANT SAFETY INSTRUCTIONS 2018-L-OP-A Starting the Engine Stopping the Engine DANGER In an emergency, turn the engine switch to the “OFF” position. move log splitter outside and far away from windows, Under normal operation: doors and intake ventilation covers. 1.

  • Page 9: Controls And Features

    CONTROLS AND FEATURES LOG SPLITTER CONTROLS AND FEATURES Read this operator’s manual before operating your log splitter. Familiarize yourself with the location and function of the controls and features. Save this manual for future reference. Log Splitter 1. 2 in. (5.1 cm) Ball Coupler – For towing the log splitter 7.

  • Page 10: Engine

    LOG SPLITTER CONTROLS AND FEATURES Engine 1. Muffler 6. Engine Switch – Used to STOP the engine. (may be in a different location on your machine) 2. Air Filter – Protects the engine by filtering dust and 7. Oil Drain Bolt – Used to drain the oil from the engine. debris from the intake air.

  • Page 11: Parts Included

    CONTROLS AND FEATURES LOG SPLITTER Parts Included Hardware Needed Tool Needed Part Part Qty. Qty. Premier and Pro Pro XL Premier and Pro Pro XL Castle Nut Castle Nut 30mm open-end wrench 30mm open-end wrench Wheels Cotter Pin Ø4 × 36 Cotter Pin Ø4 ×...

  • Page 12: Assembly

    ASSEMBLY LOG SPLITTER ASSEMBLY Repeat with second fender (46) on opposite side. If your log splitter is already assembled, skip the assembly 3) Install the Wheels instructions in this manual. Remove the two plastic shipping caps from each wheel If unassembled, please read and follow these instructions. hub.

  • Page 13: Install The Support Leg

    ASSEMBLY LOG SPLITTER 4) Install The Support Leg 3. Unplug the pin (78). Pivot the beam to the horizontal position Unplug the pin (78), rotate the support leg (82) down insert the pin (78) back. put it right, insert the pin (78) back. WARNING 5) Install the Beam The beam is extremely heavy and should only be handled...

  • Page 14: Install The Hoses

    ASSEMBLY LOG SPLITTER 7) Install the Hoses Suction hose 2. Using the provided 32 hose clamps, connect one end of CAUTION the suction hose (73) to the port on the hydraulic oil tank (C) next to the hydraulic filter and the other end to the pump Red shipping plugs must be removed from hydraulic pump inlet on the side of the pump (D).

  • Page 15: Add Engine Oil

    ASSEMBLY LOG SPLITTER Add Engine Oil 2. Place M10 flat washers (4) and M10 lock washers (3) onto the four M10 x 20 bolts (2) and thread them through the holes CAUTION on the log catcher (1) and into the holes on the splitter beam and tighten securely.

  • Page 16: Add Fuel

    ASSEMBLY LOG SPLITTER CAUTION The engine is equipped with a low oil shut-off and will stop when the oil level in the crankcase falls below the threshold level. NOTICE We consider the first 5 hours of run time to be the break- in period for the engine.

  • Page 17: Add Hydraulic Oil

    ASSEMBLY LOG SPLITTER If your log splitter was delivered unassembled, follow these NOTICE instructions: Our engines work well with 10% or less ethanol blend 1. Make sure the log splitter is on a flat, level surface. gasoline. When using ethanol-gasoline blends there are some 2.

  • Page 18: Before Each Use Inspect The Log Splitter

    ASSEMBLY LOG SPLITTER NOTICE When the outdoor temperature is below 32˚F, Dexron III transmission fluid can be used. Do not mix hydraulic oil and transmission fluid. Drain all oil or fluid before adding the other one. See hydraulic oil system specifications section for more details.

  • Page 19: Log Splitter Location

    OPERATION LOG SPLITTER Log Splitter Location WARNING This log splitter must have at least seven feet of clearance from ALWAYS use the log splitter for its intended use. The log combustible material. Leave at least three feet of clearance on all splitter should only be used to split wood logs, length wise sides of the log splitter to allow for adequate cooling, with the grain.

  • Page 20: Stopping The Engine

    OPERATION LOG SPLITTER 4. Move the fuel valve to the “ON” position. NOTICE If the engine starts but does not run make certain that the log Fuel Shutoff splitter is on a flat, level surface. The engine is equipped with a low oil sensor that will prevent the engine from running when the oil level falls below a critical threshold.

  • Page 21: Log Splitter Operation

    OPERATION LOG SPLITTER Log Splitter Operation NOTICE 1. ALWAYS wear ear and eye protection, protective clothing and The cylinder stroke is designed so the wedge stops safety gear. approximately 1.5 in. (3.8 cm) from the end plate. 2. Block tires and ensure support leg is secure to prevent unintended movement of the log splitter during operation.

  • Page 22: Maintenance

    MAINTENANCE LOG SPLITTER MAINTENANCE Changing the Engine Oil Change oil when the engine is warm. Refer to the oil specification Make certain that the log splitter is kept clean and stored to select the proper grade for your operating environment. properly.

  • Page 23: Cleaning The Air Filter

    MAINTENANCE LOG SPLITTER Cleaning the Air Filter 1. Begin with the cylinder retracted and the engine fuel valve in the “OFF” position. 1. Remove the wing nut from the filter cover and 2. Release any stored pressure by moving the valve lever remove the cover.

  • Page 24: Maintenance Schedule

    MAINTENANCE LOG SPLITTER Maintenance Schedule – Using a large wrench, unscrew the fitting from the tank to expose the internal tank filter. Follow the service intervals indicated in the following maintenance – Check for any debris on the screen. Using a clean schedule.

  • Page 25: Storage

    STORAGE LOG SPLITTER STORAGE Refer to the Maintenance section for proper cleaning instructions. Log Splitter Storage 1. The log splitter needs to be cool for at least 5 minutes before storing. 2. Clean the log splitter before storage according to the Maintenance section.

  • Page 26: Specifications

    SPECIFICATIONS LOG SPLITTER SPECIFICATIONS Hydraulic Oil System Log Splitter Specifications Capacity ....... 4.5, 4.5, 6.0 gal. (17, 17, 23 L) Ram Force ............25, 28, 34 Ton For year round use in warmer Cycle Time, No Load ........12, 12, 18 seconds climates (always ABOVE 32˚F/ 0˚C): Hydraulic Tank Capacity .....

  • Page 27: Troubleshooting

    TROUBLESHOOTING LOG SPLITTER TROUBLESHOOTING Problem Cause Solution No fuel. Add fuel. Engine will not start. Faulty spark plug. Replace spark plug. Unit loaded during start up. Remove load from unit. Fill crankcase to the proper level. Low oil level. Place log splitter on a flat, level surface. Engine will not start;...
  • Page 28 PARTS LIST and SCHEMATIC LOG SPLITTER Notes:...

  • Page 29: Parts List And Schematic

    PARTS LIST and SCHEMATIC LOG SPLITTER Parts List – Horizontal-Vertical Log Splitter Note: Part numbers listed are available through DR Power Equipment. Ref# Part# Description Machine Specific A0002308619 Catcher, Log G051756 Screw, HHC, M10-1.5 X 20, C8.8 A0002308660 Washer, Spring, M10...
  • Page 30 A0002325720 Hose, Hydraulic, High Pressure WH3 A0002869169 Cover-Hose High Press WH3 A0002325725 Fitting, Gear Pump WH3 Premier 25T, Pro 28T A0001346725 Bolt, HCS, 5/16-24 X 1″, GR5, ZP Premier 25T, Pro 28T A0002325723 Mount, Gear Pump WH3 Premier 25T, Pro 28T...
  • Page 31 Warranty LOG SPLITTER Schematic – Horizontal-Vertical Log Splitter...
  • Page 32 LOG SPLITTER Schematic – Engine and Pump Components (Pro XL 34T Splitter Only)

  • Page 33: Year Limited Warranty

    HORIZONTAL-VERTICAL LOG SPLITTER is fit for ordinary purposes for  which a product of this type is used. DR Power Equipment, however, limits the implied warranties of merchantability and fitness in duration to a period of two (2) years in consumer use, ninety (90) days for any other use.
  • Page 34 LOG SPLITTER 800 Hinesburg Road, South Burlington, Vermont 05403 ©2022 DR Power Equipment. All rights reserved A0002311990_C...

This manual is also suitable for:

Pro 28tPro xl 34t
