CNR-SW2 Manual v1.0
Canyon NavMaster
Features
Altimeter
Altitude Measuring Range : -500 to 9000 meter or -1,600 to
29500 feet
Resolution of 0.5 meter or 1 feet
Total Altitude Gain
Trip timer : 9 hr 59 min 59 sec
Current ascending or descending Speed
Average ascending or descending Speed
Electronic Compass
3-mode display showing a compass arrow direction, numeric
and cardinal readouts
with highly accuracy of +-5 degree and a resolution of 1
degree
a magnetic distortion alerts "Err" when external magnetic
interference occurs
automatic shut-off
Thermo Alarm Clock
Perpetual calendar with day of week
Snooze Alarm clock
Thermometer (-10 degree
to + 50 degree
12/24 hr,
selectable
Max/Min memory for Thermometer
Battery Installation
Computer Watch
Remove the back cover of the computer with a screwdriver, install
the 3.0V-battery with the positive(+) pole facing up and replace the
cover. Remove the battery and reinsert it if the LCD displays
irregular figures. This will clear and restart the computer's
microprocessor.
3V-Battery CR2032
Display Icons & Keys Illustration
)
Icons:
Heading Direction
Time mode
Alarm ON / OFF
Afternoon
Alarm Snooze
Temperature in Celsius
Battery Low
Temperature in Fahrenheit
Compass mode
Maximum memory
Altimeter mode
Minimum memory
To wake Up and set your computer
Press and hold both button A and C until all segments on.
Meter / Feet Selection
Right after all segments on, the "M" digit will start to flicker.
To select M (Meter) or Ft (Feet), press button C and then press
button A to confirm.
Selection
Right after Meter/Feet selection, the Celsius digit will then
start to flicker
To select
or , press button C and then press button A to
confirm.
Clock Setting
Right after
selection, the "24H" digits will then start to
flicker, press button C to select 12H or 24H hour format
Press button A to confirm and then the hour digits will start to
flicker.
Advertisement
Table of Contents
Related Manuals for Canyon NavMaster CNR-SW2
Summary of Contents for Canyon NavMaster CNR-SW2
- Page 1 Battery Installation Icons: CNR-SW2 Manual v1.0 Computer Watch Heading Direction Time mode Canyon NavMaster Remove the back cover of the computer with a screwdriver, install Alarm ON / OFF Afternoon Features Alarm Snooze Temperature in Celsius the 3.0V-battery with the positive(+) pole facing up and replace the...
- Page 2 To set hour, press button C to adjust the hour digits to Back Light desired value and then press button A to confirm. Right after Press button B to turn on. Snooze Alarm the confirmation, the minute digits will start to flicker. To set minutes, press button C to adjust the minute digits to To set alarm time, in Clock mode, press and hold button A until Maximum and minimum...
- Page 3 Current average (2). Precise direction of North ( ), South ( always points to the north, and the icon as the “TAIL” of ascending speed or East ( ) and West ( ) by the ring. the needle, which always points to the south. No matter what the descending speed For Power Saving, the compass will automatically stop current compass’s orientation is, the NORTH and SOUTH can...
- Page 4 Failure to do a correct calibration can result in inaccurate headings. Perform a new calibration City Declination Angle City Declination Angle again if a heading is suspected. Anchorage Calgary Atlanta Chicago Bombay Denver Boston Jerusalem London Rio De Janeiro Little Rock San Francisco Important notes Livingston, MT...
