Operation Using the ACU
VER LOW 12598 21096
- INPUT
VER LOW NID 0x0003
- INPUT
HOR LOW 12523 21096
- INPUT
HOR LOW NID 0x0003
- INPUT
VER HIGH 12598 21096
- INPUT
VER HIGH NID 0x0003
- INPUT
HOR HIGH 12523 21096
- INPUT
8. Input the tracking frequency (MHz) and symbol
rate (KHz) for vertical low band.
+
9. Input the network ID (NID) for vertical low band.
+
10. Input the tracking frequency (MHz) and symbol
rate (KHz) for horizontal low band.
+
11. Input the network ID (NID) for horizontal low band.
+
12. Input the tracking frequency (MHz) and symbol
rate (KHz) for vertical high band.
+
13. Input the network ID (NID) for vertical high band.
+
14. Input the tracking frequency (MHz) and symbol
rate (KHz) for horizontal high band.
+
