User's Manual of HPOE-1200G / HPOE2400G
User's Manual
HPOE-1200G
HPOE-2400G
IEEE 802.3at
12 / 24-Port Gigabit Power over Ethernet
Managed Injector Hub
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HPOE-2400G and is the answer not in the manual?

Questions and answers

Summary of Contents for Planet HPOE-2400G

  • Page 1 User’s Manual of HPOE-1200G / HPOE2400G User’s Manual HPOE-1200G HPOE-2400G IEEE 802.3at 12 / 24-Port Gigabit Power over Ethernet Managed Injector Hub...
  • Page 2 PLANET. PLANET assumes no responsibility for any inaccuracies that may be contained in this User’s Manual. PLANET makes no commitment to update or keep current the information in this User’s Manual, and reserves the right to make improvements to this User’s Manual and/or to the products described in this User’s Manual, at any time without notice.
  • Page 3: Table Of Contents

    VERVIEW 3.2 R ............................18 EQUIREMENTS 3.3 M ..........................19 ANAGEMENT ETHOD 3.3.1 Web Management..........................19 3.3.2 PLANET Smart Discovery Utility...................... 20 4 WEB CONFIGURATION ....................22 4.1 M ............................22 ANIN 4.2 W ............................. 23 ANEL 4.3 S ..............................23 YSTEM 4.3.1 System Information ..........................
  • Page 4 User’s Manual of HPOE-1200G / HPOE2400G 4.4.1 SNMP Management......................... 37 4.5 P ........................... 39 OWER OVER THERNET 4.5.1 PoE Configuration ..........................40 4.5.2 PoE Schedule profile........................42 4.5.3 PoE Schedule ..........................44 4.5.4 PoE Schedule Profile configuration example................... 45 5. Power OVER Ethernet Overview ................49 6.
  • Page 5: Introduction

    In the following section, the term “PoE Injector Hub” means the two Gigabit PoE Injector Hub devices, i.e. HPOE-1200G, HPOE-2400G. Terms with lower case “injector” means any IEEE 802.3at / 802.3af power injectors. “PD” means the abbreviated from IEEE 802.3at / 802.3af powered device.
  • Page 6 For the places hard to find the power outlet, the PoE Injector Hub provides the easiest way to power your Ethernet devices such as PLANET Internet Cameras and outdoor Wireless Access Point installed on the top of the building. To control the power system of your networking devices, the Gigabit PoE Injector Hub can directly co-work with PoE IP Phone to build VoIP telephony network in the office.
  • Page 7: How To Use This Manual

    User’s Manual of HPOE-1200G / HPOE2400G 1.3 How to Use This Manual This User Manual is structured as follows: Section 2, Installation It explains the functions of PoE Injector Hub and how to physically install the PoE Injector Hub. Section 3, Management It contains information about the software function of the PoE Injector Hub.
  • Page 8: Product Features

    PoE power Usage Threshold Management Web interface for remote management Supports Network Time Protocol (NTP) Firmware upgrade through Web interface PLANET Smart Discovery utility automatically finds PLANET devices on the network SNMP Trap for alarm notification of events System Log / Remote Syslog...
  • Page 9 User’s Manual of HPOE-1200G / HPOE2400G Hardware 19-inch rack mountable; 1U height Reset button for reset to default setting and system reboot LED indicators for PoE ready and PoE activity LED indicators for Power Alert and Fan Alert FCC Part 15 Class A, CE Standard Compliance IEEE 802.3 10Base-T IEEE 802.3u 100Base-TX...
  • Page 10: Product Specifications

    Number of 802.3at PD Class 1, 2, 3 can be powered Number of 802.3at PD Class 0, 4 can be powered Management Web, PLANET Smart Discovery Lite Management Interface Power Limit by Priority and Total Limit Per port power schedule Per port power enable/disable...
  • Page 11 User’s Manual of HPOE-1200G / HPOE2400G Total power consumption System / Management functions setup Web firmware upgrade Management Feature SNMP Trap for alarm notification of events Standards Conformance IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100Base-TX Fast Ethernet IEEE 802.3ab 1000Base-T Gigabit Ethernet Standards Compliance Pre-standard IEEE 802.3at Power over Ethernet IEEE 802.3af Power over Ethernet...
  • Page 12: Installation

    Figure 2-1-1: HPOE-1200G front panel Front Panel of HPOE-2400G Figure 2-1-2: HPOE-2400G front panel ■ Reset button At the left of front panel, the reset button is designed for reboot the PoE Injector Hub without turn off and on the power.
  • Page 13: Led Indicators

    Lights to indicate FAN2 have been stop. (Only for HPOE-2400G) FAN2 Fail Green Lights to indicate one of power supply 1 has failure. Power1 Fail Green Lights to indicate one of power supply 2 has failure. (Only for HPOE-2400G) Power2 Fail Green Lights to indicate power on. Power Green Lights to indicate that the port is in use and supplying 48V DC power.
  • Page 14: Installing The Poe Injector Hub

    This section describes how to install your PoE Injector Hub and make connections to the PoE Injector Hub. Please read the following topics and perform the procedures in the order being presented. PLANET PoE Injector Hub do not need software configuration.
  • Page 15 User’s Manual of HPOE-1200G / HPOE2400G Figure 2-2-1: Brackets attaching to the PoE Injector Hub You must use the screws supplied with the mounting brackets. Damage caused to the parts by using incorrect screws would invalidate the warranty. Step3: Secure the brackets tightly. Step4: Follow the same steps to attach the second bracket to the opposite side.
  • Page 16: Network Application Installation

    User’s Manual of HPOE-1200G / HPOE2400G 2.2.3 Network Application Installation The PoE Injector Hub is not equipment with data switching function between data ports. To inject PoE power and transmit data packets to PDs, the PoE Injector Hub is usually link to an Ethernet switch. Typically, the Mid-Span Injector is installed between regular Ethernet switch and PDs, and mostly it is located close to the Ethernet switch side.
  • Page 17: Power Over Ethernet Powered Device

    User’s Manual of HPOE-1200G / HPOE2400G 2.2.4 Power over Ethernet Powered Device Voice over IP phones Enterprise can install POE VoIP Phone, A Ethernet/non-Ethernet end-devices to the UPS is installed for un-interrupt power syst control system. Wireless LAN Access Points...
  • Page 18: Management

    User’s Manual of HPOE-1200G / HPOE2400G 3 MANAGEMENT This chapter describes how to manage the PoE Injector Hub. Topics include: - Overview - Management method - Logging on to the PoE injector Hub 3.1 Overview The PoE injector Hub provides a user-friendly, Web interface. Using this interface, you can perform various device configuration and management activities, including: System Power over Ethernet...
  • Page 19: Management Method

    User’s Manual of HPOE-1200G / HPOE2400G 3.3 Management Method User can manage the PoE injector Hub by Web Management via a network connection. 3.3.1 Web Management The PoE Injector Hub can be configured through an Ethernet connection, the factory default IP address is 192.168.0.100 with subnet mask 255.255.255.0, so please make sure the manager PC must be set on the same IP subnet address.
  • Page 20: Planet Smart Discovery Utility

    2. Only accept command in lowercase letter under Web interface. 3.3.2 PLANET Smart Discovery Utility For easily list the PoE Injector Hub in your Ethernet environment, the Planet Smart Discovery Utility from user’s manual CD-ROM is an ideal solution. The following install instructions guiding you for run the Planet Smart Discovery Utility.
  • Page 21 To click the “Control Packet Force Broadcast” function, it can allow assign new setting value to the PoE Injector Hub under different IP subnet address. Press “Connect to Device” button the n the Web login screen appears in Figure 3-1-2. Press “Exit” button to shutdown the Planet Smart Discovery Utility.
  • Page 22: Web Configuration

    PoE Injector Hub from the local LAN. This section indicates how to configure the PoE Injector Hub to enable its smart function. The following screen based on HPOE-2400G, for HPOE-1200G the display will be the same with HPOE-2400G, except HPOE-1200G has 12 ports only.
  • Page 23: Web Panel

    User’s Manual of HPOE-1200G / HPOE2400G 4.2 Web Panel At the top of the Web management page, the active panel displays the link status of management port and PoE ports. Figure 4-2-1: Web panel screen Green lit is the network data send or receiver. Orange lit is the PoE in use.
  • Page 24: System Information

    User’s Manual of HPOE-1200G / HPOE2400G Allow to backup or restore system configuration. Explained in section 4.3.6. • Configuration Setting Allow to reset system to factory default setting. Explained in section 4.3.7. • Factory Default Allow to enable system log and to record system log. Explained in section •...
  • Page 25: Ip Configuration

    User’s Manual of HPOE-1200G / HPOE2400G 4.3.2 IP Configuration This section provides the IP Configuration of PoE Injector Hub, the screen in Figure 4-3-2 appears and Table 4-3-2 describes the IP Configuration object of PoE Injector Hub. Figure 4-3-2: IP Configuration Web page screen Object Description •...
  • Page 26: Ntp Configuration

    User’s Manual of HPOE-1200G / HPOE2400G 4.3.3 NTP Configuration This section provides the NTP Configuration of PoE Injector Hub, the screen in Figure 4-3-3 appears and Table 4-3-3 describes the NTP Configuration object of PoE Injector Hub. Figure4-3-3: NTP Configuration Web page screen Object Description •...
  • Page 27: Password Setting

    User’s Manual of HPOE-1200G / HPOE2400G 4.3.4 Password Setting This section provide the Password Setting of PoE Injector Hub, the screen in Figure 4-3-4 appears and Table 4-3-4 describes the Password Setting object of PoE Injector Hub. Figure 4-3-4: Password Setting Web page screen Object Description •...
  • Page 28: Firmware Upgrade

    User’s Manual of HPOE-1200G / HPOE2400G 4.3.5 Firmware Upgrade This section provides the firmware upgrade of PoE Injector Hub, the screen in Figure 4-3-5 appears. Figure 4-3-5: Firmware Upgrade Web page screen Please press “Browse” to locate the latest firmware of PoE Injector Hub that deposit in your PC. The screen in Figure 4-3-6 appears.
  • Page 29: Configuration Setting

    User’s Manual of HPOE-1200G / HPOE2400G 4.3.6 Configuration Setting This function allows output the current PoE Injector Hub configuration as a file, and upload it to other PoE injector Hub for quick multi-devices setting. The description of the procedure and screens in following appears. The screen in Figure 4-3-8 appears and Table 4-3-5...
  • Page 30 User’s Manual of HPOE-1200G / HPOE2400G Figure 4-3-10: File save screen Figure 4-3-11: File save screen Configuration Upload ■ Click the “Browse” button of the Configuration Setting Web page, the system would pop up the file selection screen to choose saved configuration. The screen in Figure 4-3-12 appears.
  • Page 31 User’s Manual of HPOE-1200G / HPOE2400G Figure 4-3-12: Windows file selection screen Select on the configuration file then click “Upload”. After system had done to upload, screen in Figure 4-3-13 appears. Figure 4-3-13: Configuration upload finished screen When configuration had done to upload please re-login in system again. Figure 4-3-14: System Login screen...
  • Page 32: Factory Default

    User’s Manual of HPOE-1200G / HPOE2400G 4.3.7 Factory Default This section provides reset the PoE Injector Hub to factory default mode, the screen appears in Figure 4-3-15. Figure 4-3-15: Factory Default Web page screen Please press “Reset” button to take effect and the “Do you really want to reset the current settings to default?” pop window appears, please press “OK”...
  • Page 33 User’s Manual of HPOE-1200G / HPOE2400G The pop window with “Wait for 30 seconds while rebooting” appears, the screen in Figure 4-3-18 appears. Figure 4-3-18: Factory Default Web page screen After 30 second press “OK” button then the main menu Web page screen appears in Figure4-3-19. Figure 4-3-19: Main Web page screen...
  • Page 34: System Log

    User’s Manual of HPOE-1200G / HPOE2400G 4.3.8 System Log This section provides the system log setting and information display of PoE Injector Hub, the screen in Figure 4-3-20 appears and Table 4-3-6 describes the system log setting object of PoE Injector Hub. Figure 4-3-20: System Log Web page screen Object Description...
  • Page 35: System Reboot

    User’s Manual of HPOE-1200G / HPOE2400G 4.3.9 System Reboot This section provides the system reboot function of PoE Injector Hub, the screen in Figure 4-3-21 appears. Figure 4-3-21: System Reboot Web page screen Press “Reboot” button to reboot the PoE Injector Hub, the screen in Figure 4-3-22 appears Figure 4-3-22: System Reboot Web page screen...
  • Page 36 User’s Manual of HPOE-1200G / HPOE2400G Please input the password for enters into Web main menu screen of PoE Injector Hub, the screen in Figure 4-3-25 appears. Figure 4-3-25: Main Web page screen...
  • Page 37: Snmp

    User’s Manual of HPOE-1200G / HPOE2400G 4.4 SNMP The Simple Network Management Protocol (SNMP) is an application layer protocol that facilitates the exchange of management information between network devices. It is part of the Transmission Control Protocol/Internet Protocol (TCP/IP) protocol suit. SNMP enables network administrations to manage network performance, find and solve network problems, and plan for network growth.
  • Page 38 User’s Manual of HPOE-1200G / HPOE2400G Object Description • SNMP Agent Provide disable or enable the SNMP Agent function of PoE Injector Hub. Allow input characters for SNMP Read Community of PoE Injector Hub, the • SNMP Read Community maximum length is 30 characters. Allow input characters for SNMP Write Community of PoE Injector Hub, the •...
  • Page 39: Power Over Ethernet

    User’s Manual of HPOE-1200G / HPOE2400G 4.5 Power over Ethernet Power Management: In a power over Ethernet system, operating power is applied from a power source (PSU-power supply unit) over the LAN infrastructure to powered devices (PDs), which are connected to ports. Under some conditions, the total output power required by PDs can exceed the maximum available power provided by the PSU.
  • Page 40: Poe Configuration

    User’s Manual of HPOE-1200G / HPOE2400G 4.5.1 PoE Configuration This section provides PoE (Power over Ethernet) Configuration and PoE output status of PoE Injector Hub, screen in Figure 4-5-2 appears and Table 4-5-2 describes the PoE Configuration object of PoE Injector Hub. Figure 4-5-2: PoE Configuration Web page screen Object Description...
  • Page 41 User’s Manual of HPOE-1200G / HPOE2400G PoE Unit Temperature PoE Power Budget 460 watts 450 watts 440 watts 430 watts Allows user to set a temperature for alerting system log and syslog once PoE unit temperature over temperature threshold. • Temperature Threshold Also, the threshold offers a standard for Over Temperature protection to function.
  • Page 42: Poe Schedule Profile

    User’s Manual of HPOE-1200G / HPOE2400G PD Classifications A PD may be classified by the PSE based on the classification information provided by the PD. The intent of PD classification is to provide information about the maximum power required by the PD during operation. Class 0 is the default for PDs.
  • Page 43 User’s Manual of HPOE-1200G / HPOE2400G Figure 4-5-3: PoE Configuration Web page screen The page includes the following information: Object Description • Power Profile This PoE hub offers totally 24 profiles for user configure PoE schedule. • Function Allows user to enable or disable the profile. Provides user to select which PoE port want to apply to the profile.
  • Page 44: Poe Schedule

    User’s Manual of HPOE-1200G / HPOE2400G 4.5.3 PoE Schedule PoE Schedule user can configure a duration time for PoE port. As default value is not provide power. Screen in Figure 4-5-4 Table 4-5-5. Figure 4-5-4: PoE Schedule Web page screen The page includes the following information: Object Description...
  • Page 45: Poe Schedule Profile Configuration Example

    User’s Manual of HPOE-1200G / HPOE2400G 4.5.4 PoE Schedule Profile configuration example Please enable NTP and correct PoE hub system time first and make sure System PoE Admin Mode is enabled, otherwise you can not configure PoE Schedule profile, you may see an error message as a screen shot as following. Screen in Figure 4-5-5.
  • Page 46 User’s Manual of HPOE-1200G / HPOE2400G Press Next >> button to set profile1 of PoE schedule. Screen in Figure 4-5-7. Figure 4-5-7: PoE Schedule Profile Configuration Please use mouse to click on the block about what time you want to supply power for PoE port, then press Apply button to save configuration.
  • Page 47 User’s Manual of HPOE-1200G / HPOE2400G Please use mouse to click on the block about what time you want to supply power for PoE port, then press Apply button to save configuration. Please press << Profile button back to PoE schedule profile configuration page to go on next profile setting.
  • Page 48 User’s Manual of HPOE-1200G / HPOE2400G Figure 4-5-12: PoE Schedule of PoE camera Configuration User can press Show button to display current PoE schedule setting. Figure 4-5-13: PoE Schedule screen [END]...
  • Page 49: Power Over Ethernet Overview

    User’s Manual of HPOE-1200G / HPOE2400G 5. POWER OVER ETHERNET OVERVIEW What is PoE? Based on the global standard IEEE 802.3af, PoE is a technology for wired Ethernet, the most widely installed local area network technology adopted today. PoE allows the electrical power necessary for the operation of each end-device to be carried by data cables rather than by separate power cords.
  • Page 50 User’s Manual of HPOE-1200G / HPOE2400G The data pairs are used. Since Ethernet pairs are transformer coupled at each end, it is possible to apply DC power to the center tap of the isolation transformer without upsetting the data transfer. In this mode of operation the pair on pins 3 and 6 and the pair on pins 1 and 2 can be of either polarity.
  • Page 51 User’s Manual of HPOE-1200G / HPOE2400G References: IEEE Std 802.3af-2003 (Amendment to IEEE Std 802.3-2002, including IEEE Std 802.3ae-2002), 2003 Page(s):0_1-121 White Paper on Power over Ethernet (IEEE802.3af) http://www.poweroverethernet.com/articles.php?article_id=52 Microsemi /PowerDsine http://www.microsemi.com/PowerDsine/ Linear Tech http://www.linear.com/...
  • Page 52: The Poe Provision Process

    User’s Manual of HPOE-1200G / HPOE2400G 6. THE POE PROVISION PROCESS While adding PoE support to networked devices is relatively painless, it should be realized that power cannot simply be transferred over existing CAT-5e cables. Without proper preparation, doing so may result in damage to devices that are not designed to support provision of power over their network interfaces.
  • Page 53: Start-Up

    User’s Manual of HPOE-1200G / HPOE2400G Classifying a PD according to its power consumption may assist a PoE system in optimizing its power distribution. Such a system typically suffers from lack of power resources, so that efficient power management based on classification results may reduce total system costs.
  • Page 54 User’s Manual of HPOE-1200G / HPOE2400G AC Disconnect This method is based on the fact that when a valid PD is connected to a port, the AC impedance measured on its terminals is significantly lower than in the case of an open port (disconnected PD). AC Disconnect detection involves the induction of low AC signal in addition to the 52 VDC operating voltage.
  • Page 55: Mdi Settings

    User’s Manual of HPOE-1200G / HPOE2400G APPENDIX A A.1 MDI Settings The Medium-Dependant Interface (MDI or RJ-45) serves as the data/power interface between Ethernet elements. As such, it has two optional connection methods, to carry the power. Named Alternative A & B. Table 1 details the two power feeding alternatives.
  • Page 56: Data Out Poe Injector Rj-45 Port Pin Assignments

    User’s Manual of HPOE-1200G / HPOE2400G A.3 DATA OUT PoE Injector RJ-45 Port Pin Assignments PIN NO RJ-45 SIGNAL ASSIGNMENT Output Transmit Data + Output Transmit Data - Receive Data + Power + Power + Receive Data - Power - Power - A.4 RJ-45 pin assignment of non-802.3af / 802.3at standard PD with PD with Mid-Spain POE Mid-Span RJ-45 assignment...
  • Page 57: Ec Declaration Of Conformity

    EC Declaration of Conformity For the following equipment: *Type of Product: 12-Port Gigabit IEEE 802.3at High Power Injector Hub (340 Watts) 24-Port Gigabit IEEE 802.3at High Power Injector Hub (460 Watts) HPOE-1200G / HPOE-2400G *Model Number: * Produced by: Manufacturer‘s Name : PLANET Technology Corp.
