Battery Status; Battery Replacement - ADJ LED UV GO User Instructions

LED UV GO

Battery Status:

This function is used to check the life status of the battery.
Plug the fixture in and press the MODE button until "BATT" is
displayed. Use the UP or DOWN buttons to scroll to "STAT" and
press ENTER. The number that is displayed is the remaining
battery life. Please do not let the battery fully die, this sever-
ly shortens the life of the battery.
Example: If "50" is displayed, the battery is at half life. If "25" is
displayed, the battery is at 25% life.
NOTE: When the battery is charging or if the battery life is
below 30% the digital display will flash.
Battery Recharge: To recharge the battery, plug the supplied AC
cord into the AC input on the side of the unit and plug the other
end into a matching power supply.
Press the MODE button until "BATT" is displayed, and press
ENTER.
Use the UP or DOWN buttons to scroll to the menu "CHAR"
then press ENTER.
Use the UP or DOWN buttons to scroll to "ON", and press
ENTER. The after you select "ON" the battery is now being
charged. To stop charging the battery, select "OFF".
If the battery is being charged, and the unit is not being used,
press the MODE button until "BATT" is displayed, and press
ENTER. Use the UP or DOWN buttons to scroll to "LOAD" and
press ENTER. Select "ON" to keep the LED on, or "OFF" to
blackout the unit.
It takes about 6 hours to reach full charge.
Note: When unplugging the unit from charging and then
applying power via battery, there will be a minimal charge
drop.
ADJ Products, LLC - www.adj.com - LED UV GO Instruction Manual Page 10
Battery Status & Charging LED UV GO
Battery replacement is pretty simple. Unscrew the thumbscrew
located on the left side of the unit (front facing you). Carefully slide
the battery out and disconnect the wire as shown below. Connect
the new battery and slide the battery back in. Screw the thumbscrew
back in to secure the battery.
ADJ Products, LLC - www.adj.com - LED UV GO Instruction Manual Page 11

Battery Replacement
