Warranty Registration; Installation - ADJ 5P HEX/5P HEX PEARL User Instructions

5P Hex/5P Hex Pearl
Unpacking: Thank you for purchasing the 5P Hex/5P Hex Pearl by ADJ
Products, LLC. Every 5P Hex/5P Hex Pearl has been thoroughly tested
and has been shipped in perfect operating condition. Carefully check
the shipping carton for damage that may have occurred during ship-
ping. If the carton appears to be damaged, carefully inspect your fix-
ture for any damage and be sure all accessories necessary to operate
the unit has arrived intact. In the case damage has been found or parts
are missing, please contact our toll free customer support number for
further instructions. Do not return this unit to your dealer without first
contacting customer support.
Introduction: The 5P Hex/5P Hex Pearl is a DMX intelligent, LED par
fixture. This fixture can be used in a stand alone mode or connected
in a Master/Slave configuration. This par has five operating modes:
Sound Active mode, Program mode, RGBWA + UV dimmer mode,
Static Color mode, and DMX control mode. The 5P has 4 DMX channel
modes; 6, 7, 8, & 12.
Customer Support: ADJ Products, LLC provides a customer support
line, to provide set up help and to answer any question should you
encounter problems during your set up or initial operation. You may
also visit us on the web at www.adj.com for any comments or sugges-
tions. Service Hours are Monday through Friday 8:00 a.m. to 4:30 p.m.
Pacific Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2941
E-mail: support@americandj.com
Warning!
To prevent or reduce the risk of electrical shock or fire, do
not expose this unit to rain or moisture.
Caution!
There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
ADJ Products, LLC.
PLEASE recycle the shipping carton when ever possible.
ADJ Products, LLC - www.adj.com - 5P Hex/5P Hex Pearl User Manual Page 2
Introduction 5P Hex/5P Hex Pearl
• Multi-Colors
• Five Operating Modes
• Electronic Dimming 0-100%
• 5 Dimmer Curves
• Built in Microphone
• DMX-512 protocol
• 3-Pin DMX Connection
• 4 DMX Modes: 6 Channel Mode, 7 Channel Mode, 8 Channel
Mode, & 12 Channel Mode.
• Dotz Par RF compatiable (Not Included)
• Power Cord Daisy Chain (See page 12)
5P Hex/5P Hex Pearl
The 5P Hex/5P Hex Pearl carries a 2 year limited warranty. Please fill
out the enclosed warranty card to validate your purchase. All returned
service items whether under warranty or not, must be freight pre-paid
and accompany a return authorization (R.A.) number. The R.A. number
must be clearly written on the outside of the return package. A brief
description of the problem as well as the R.A. number must also be
written down on a piece of paper included in the shipping carton. If
the unit is under warranty, you must provide a copy of your proof of
purchase invoice. You may obtain a R.A. number by contacting our
customer support team on our customer support number. All pack-
ages returned to the service department not displaying a R.A. number
on the outside of the package will be returned to the shipper.
5P Hex/5P Hex Pearl
The unit should be mounted using a mounting clamp (not provided),
affixing it to the mounting bracket that is provided with the unit.
Always ensure that the unit is firmly fixed to avoid vibration and slip-
ping while operating. Always ensure that the structure to which you
are attaching the unit is secure and is able to support a weight of 10
times the unit's weight. Also, always use a safety cable that can hold
12 times the weight of the unit when installing the fixture.
The equipment must be installed by a professional, and it must be
installed in a place where it is out of the reach of people's grasp.
ADJ Products, LLC - www.adj.com - 5P Hex/5P Hex Pearl User Manual Page 3
Features

Warranty Registration

Installation
